INDOOR UNIT

• Switch off the power supply and unplug before cleaning.
• Do not touch the aluminium fi n, sharp parts may cause injury.
CAUTION
CLEANING INSTRUCTIONS
CLEANING INSTRUCTIONS
• Do not use benzene, thinner or scouring powder.
• Use only soap ( pH7) or neutral household detergent.
• Do not use water hotter than 40°C.
4
2
5
7
6
INDOOR UNIT
1
• Wipe the unit gently with a soft, dry cloth.
FRONT PANEL
2
Remove Front Panel
• Raise and pull to remove the front panel.
• Wash gently and dry.
Close Front Panel
• Press down both ends of the front panel to close it
securely.
REMOTE CONTROL RECEIVER
3
ALUMINIUM FIN
4
HUMAN ACTIVITY SENSOR
5
HORIZONTAL AIRFLOW DIRECTION LOUVER
6
• Manually adjustable.
HINT
HINT
• To ensure optimal performance of the unit, cleaning
maintenance has to be carried out at regular intervals.
Please consult authorized dealer.
HUMAN ACTIVITY SENSOR
1
5
8
• Do not hit or violently press the sensor or
poke it with a sharp object. This can lead to
damage and malfunction.
• Do not place large objects near the sensor
9
and keep away heating units or humidifi ers
from the sensor's detection area. This may
lead to sensor malfunction.
nanoe-G GENERATOR
10
3
• Do not touch during operation.
VERTICAL AIRFLOW DIRECTION LOUVER
7
• Do not adjust by hand.
AUTO OFF/ON BUTTON
8
• Use when remote control is misplaced or a malfunction
occurs.
Action
Press once.
Press and hold until 1 beep is heard,
then release.
Press the button to turn off.
AIR FILTERS
9
• Air fi lter cleaning is required every two weeks.
• Wash/rinse the fi lters gently with water to avoid damage
to the fi lter surface.
• Dry the fi lters thoroughly under shade, away from fi re or
direct sunlight.
• Replace any damaged fi lters.
10 nanoe-G GENERATOR
Clean with dry cotton bud.
• nanoe-G generator cleaning is
recommended every 6 months.
Mode
Auto
Cooling
9
