REMOTE CONTROL

Maximum
distance: 8m
Human activity
sensor and
indicator
Sunlight sensor and remote control receiver
Remote
Control display
8
3
7
6
Indicator
(Green)
POWER
(Orange)
TIMER
(Green)
ECONAVI
(Green)
AUTO COMFORT
(Blue)
NANOE-G
(Orange/
POWERFUL/QUIET
Green)
Press the remote control's button
TO TURN ON OR OFF THE UNIT
1
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
TO SET TEMPERATURE
2
• For heat, cool and dry modes, the range of temperature
for selection is 16°C ~ 30°C.
• Operating the unit within the recommended temperature
could induce energy saving.
HEAT mode : 20˚C ~ 24˚C.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
TO SELECT OPERATION MODE
3
AUTO mode - For your convenience
• Unit selects the operation mode according to the room
temperature.
• Once auto mode is selected, the unit will operate at the
standard setting temperature.
Room
temperature
23˚C & above
Below 23˚C
Below 20˚C
• Press
for "HI" to +2˚C or
standard setting temperature.
HEAT mode - To enjoy warm air
• Unit takes a while to warm up. The power indicator blinks
during this operation.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
1
TO SELECT FAN SPEED (3 OPTIONS)
6
4
4
FAN SPEED
2
5
• For AUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
Standard setting
Operation mode
temperature
Cool
25˚C
Dry
22˚C
Heat
21˚C
for "LO" to -2˚C to the
POWER
