POSBank Anyshop II Installation Manual

The one that creates a new trend
AnyShop II
Precaution
e
Warranty
We guarantee our POS terminal product and its parts against defects in materials
and workmanship under proper use for a standard period of 2 years from the date of
original purchase.
During this period, we will repair or replace defected and/or faulty products or parts
without imposing a charge for spare and labor to the purchaser.
The 1st year includes servicing and new or refurbished replacement parts free of
charge, with one-way shipping cost born by the seller; the customer shall be
responsible for return delivery charge.
The 2nd year also includes free of charge servicing and parts, but a limited warranty
requires the entire shipping cost be borne by the customer.
Products out of the warranty period or scope shall be diagnosed at customer's
expense. We will charge for repair and delivery in the case of damage as a result of
the customer's mistake, abnormal usage, carelessness or natural disasters .
e
Notice for safety
1. We recommend using proper power voltage as a precaution against fire and
electrical shock.
2. Avoid exposing the product to direct sunlight and do not use the product near areas
of high moisture ; this may cause low reliability and/or operational malfunction .
3. Be aware of electro-static on PCB of system with anti-static appliance; This is a
possible cause of low reliability and short life term .
4. Place a product away from highly static areas; this may lead to low performance
and a reduced life cycle.
5. Do not disturb metal material or obstacle in product in danger of fire and electric
shock.
6. Use product in simple power cord plug-in circumstance in caution of fire, electric
shock and system disorder on electricity.
7. Be careful of other electronics with possible high frequency, electronic and
magnetic affects lEx. Audio, Electronic-range, etc]; there is a strong possibility this
will lead to the product becoming out-of-order or system error.
8. Risk of explosion if battery is replaced incorrectly; dispose of used batteries
according to the instructions.
9. Only use adapter supplied .
If an incorrect adapter is not used, the product's performance may decrease and
there is an increased risk of fire or electric shock.
1. Package contents
The following items are included when you purchase this product.
If any of these items are damaged or missing, contact your dealer
for assistance.
A nyS hop II
2. Configuration
[Front View]
ch LCD & lou
panel displ
LAN LED
HOD LED
Power LE
ay
D
Dual sp eaker o----
[Side View]
[1/0 View]
I T I
§
I
~
...
----------""
O<>
Dr ivers CD Use r" s ma nua l
Adapte r Powe r co rd
~ ~I
Dallas !-button reader
II
IH
"'
~
•
~ M
~ 5
~;;.'
agnetic stripe reader
(MSR)
mart card reader
(SCR)
Power switch
~~~---------
Step 1. Raise the main display unit.
Step 2. Pull the bottom and lift up the
1/0
port cover.
[1/0 port ; Q]
*
1/0
ports may differ according to product model or options.
1
2
3
4
~
o\' "
-----c ® =---...Jo
@)
LPT
Description
LPT port
Cash drawer port (option)
Power connector
PS/2 connector
[1/0 port ; 025]
Description
1 Cash drawer port (option)
2 Powe r co nn ec tor
3 PS/2 connector
4 USB 2 port
3. Power on
@)
o(IDo
o(IDo ~ ~.:0
oooo
oooo[~J
C®J::
COM2 VGA
Description
5
COM1. COM2. COM3 port
6 VGA port
7 LAN port
8
USB 2 port
o(IDo o( ® )o l(?5l a
COM1 COM3
~
o(IDo o( ®
)o
~ ::
COM2 VGA
Description
5 COM1. COM2. COM3 port
6
VGA port
7 LAN port
The power switch is located right hand side of the main body under the
display unit.
When connected to power source, the POWER LED will be lighted-on
automatically. The unit's status can be determined by each LED lamp.
-
~
'
...
... "!" ... --~'
a=l h
ll:-i
Indicator modes are as follows;
~~:;iE§§~~~~
When co nn ected LAN : LAN LED is bli nking [Yellow]
Ope ra ti on mo de: HOD LED is blinking [Red]
POWER LED is lit [Gree n]
4. Option devices
Connect the hinge and COP or 2nd display monitor, after connecting
the main body and cable .
Turn off power, and then turn on again to boot up . Check if the start
-up screen appears normally. [Connect the COP to COM4.)
Caution:
Completely remove the power cord before removing or installing a COP
or a 2nd display monitor.
[Customer display]
Step 1. Separating LCD monitor module.
Step 2. Separating Back cover.
[2nd Display]
0 0 0 0
~- ~
j
l
\. ~··
......................................................
· ·~
Step 3. Remove the 2 screws used
for clamping COP.
Step 4. Separate the COP Bracket
after removing 2 screws.
The assembling method of the 2nd Display is equal for all the products.
[10.1, 12.1,15 inch]
Step 1. Lay the main body on the
side in order to place the hinge on
the correct position .
Step 2. Fasten the 4 screws onto
second monitor hinge, and then
connect it to Main body unit.
Step 3. Put the main body back,
and assemble the hinge until you
see it coming out of the BACK
COVER COP window.
Step 4. Put Back cover and Main
body unit together by tightening up
the 2 screws.
