ANYSHOP e2_D25_UM_eng_PBUM_E(Rev002;20140926)
Point-of-sale system
ANYSHOP e2 D25
Use'r manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANYSHOP e2 D25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POSBank ANYSHOP e2 D25

Summary of Contents for POSBank ANYSHOP e2 D25

  • Page 1 ANYSHOP e2_D25_UM_eng_PBUM_E(Rev002;20140926) Point-of-sale system ANYSHOP e2 D25 Use’r manual...

  • Page 2: Table Of Contents

    -Table of Contents- POSBANK USER’S MANUAL REVISION HISTORY ............................... 3 SPECIFICATION ........................................4 (1) SPECIFICATION - OUTSIDE SIZE ..................................5 PREFACE ..........................................6 SYMBOL; MARK ........................................7 COPYRIGHT ........................................... 8 WARRANTY..........................................9 SAFETY INSTRUCTIONS....................................... 10 NOTICE ..........................................11 LIABILITY LIMITATION ......................................12 INSTALLATION RECOMMENDATIONS ..................................

  • Page 3: Posbank User's Manual Revision History

    POSBANK Use’r manual Revision History Changes to the ANYSHOP e2 D25 Use’r manual are listed below. Rev No. Revision History Date /author ANYSHOP 2014.01.03 e2_D25_UM_eng_PBUM_026E(Rev001;140103) ANYSHOP 2014.09.26 e2_D25_UM_eng_PBUM_026E(Rev002;140926)

  • Page 4: Specification

    Specification ANYSHOP e2 D25 Intel Atom processor D2550 (1MB Cache, 1.86 GHz, Dual Core for Cedarview-D) Chipset Intel NM10 SATA2(3Gb/s) 2.5 inch HDD or HDD (Max. 2 Optional) Storage Support AHCI Memory DDR3-1066M Hz SODIMM 2GB (MAX. 4GB) Graphic Integrated Intel GMA HD 3650 Resolution 15"...

  • Page 5: Specification - Outside Size

    Specification – Outside size...

  • Page 6: Preface

    Preface This User's Guide gives information about main unit/IO port layout, basic setup, component installation, and board layout for point of sale system "ANYSHOP e2 D25" Intended Audience The User's Guide is intended for technically qualified personnel. It is not intended for general audiences.

  • Page 7: Symbol; Mark

    SYMBOL; MARK CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 8: Copyright

    Neither this manual, nor any of the material contained herein, may be reproduced without express written consent of the author. ANYSHOP e2 D25 and POSBANK are trademarks of POSBANK Co., Ltd. in the United States and other countries. * Other names and brands may be claimed as the property of others.

  • Page 9: Warranty

    Warranty We guarantee our POS terminal product and its parts against defects in materials and workmanship, under proper use, for a standard period of 2 years from the original date of purchase. During this period, we will repair or replace defective and/or faulty products or parts without charge to the customer for parts and labor.

  • Page 10: Safety Instructions

    Safety Instructions To disconnect the machine from the electrical power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.

  • Page 11: Notice

    Notice Always ensure that the correct power voltage is used as a precaution against fire and electrical shock. 2. Avoid exposing product to direct sunlight. Do not use product in areas of high humidity. Doing so may cause low reliability and/or operational malfunction. Be careful of static electricity on PCB of system with anti-static appliances.

  • Page 12: Liability Limitation

    This product is qualified by FCC, CE and KC compliances, and is thus governed by these qualifications’ safety regulations. However, the product can affect and be affected by other high frequencies generated around it. As such, POSBANK does not consider liability for any system error or disorder due to this issue.

  • Page 13: Installation Recommendations

    Installation Recommendations Avoid installing during thunderstorms. (Possibility of dangerous exposure to electricity.) Install away from damp spaces or water-leaks. Beware of static occurrence during installation. Use only ground connected and quality certified power cords and cables. Keep out of direct sun-light, extremely high or low temperatures, or high humidity areas. Install product away from areas prone to shocks or vibration.

  • Page 14: Product Overview

    2. The POS terminal main unit, power cable, user manual and driver CD are included in the package. If any items are missing or damaged, please contact your dealer for assistance. » All user manuals and drivers are available for download on our website: www.posbank.com ANYSHOP e2 D25 Main unit Adapter / Power cord Installation guide Drivers CD...
  • Page 15 Optional Devices: 2 LCD monitor 12.1” Optional Devices: 2 LCD monitor 10”...

  • Page 16: Pre-Installation Preparation

    Remove protective film from touch-screen to prevent possible operating difficulties. 2. Attach all optional parts before setting up the main POS unit. (3) Product Outline • Each part of product may differ depending on the specific POS model. • Model-specific data sheets are provided on our website at www.posbank.com...

  • Page 17: Configuration

    (4) Configuration Refer to following diagram to identify the components on this side of the system. Front view LCD & Touch panel display LAN LED Storage(Default: HDD) LED Power LED Magnetic stripe reader(MSR); Option Dallas I-button reader; Option Smart card reader(SCR); Option Dual speaker Power switch...
  • Page 18 Side view I/O port cover USB port (option) Customer display; Option Storage (Default: HDD)

  • Page 19: I/O Port: Details

    (5) I/O port: Details * I/O ports may differ according to product model or options. I/O view Raise the main display unit. Pull the bottom and lift up the I/O port cover.
  • Page 20 Standard I/O port...

  • Page 21: Setting Up: Keyboard & Mouse Connection

    (6) Setting up: Keyboard & Mouse Connection Connecting the keyboard to the PS/2 port on the bottom panel. or connecting the USB type keyboard and mouse to the USB port on the bottom panel.

  • Page 22: Setting Up: Connection Usb Port

    (7) Setting up: Connection USB Port USB ports are provided in the POS unit, two at the rear I/O and four at the side, all of which support the standard USB 2.0. Some USB devices (optional devices) are only functional with specific driver software installed. If multiple USB devices are used together, this may result in abnormal functionality.

  • Page 23: Setting Up: Connection Via Ethernet Port (Lan)

    (8) Setting up: Connection via Ethernet Port (LAN) The Ethernet port located at the rear I/O supports 10/100/1000Mbps using an RJ45 connector cable. When connected properly, the LAN LED light will be switched on. Through a network hub. Refer to the table below for the LAN port LED indications. LINK/ACT LED LINK / ACT LED SPEED LED...

  • Page 24: Setting Up: Line-Out, Mic-In, Line-In Connection

    (9) Setting up: Audio-out, Mic-in connection • Audio out port (lime): This port connects a headphone or a speaker.In4-channel, 6-channel and 8-channel configuration, the function of this port becomes Front Speaker Out. • Microphone port (pink): This port connects a microphone.

  • Page 25: Setting Up: Printer Connection

    (10) Setting up: Printer Connection Connect printer cable to either Serial &USB port as required.

  • Page 26: Setting Up: Power Cable Connection

    (11) Setting up: Power Cable Connection The ‘ANYSHOP e2 D25’ POS system is equipped with a 12V/ 5A power adapter. Connect the cable to the DC-IN port on system IO panel. CAUTION : Do not pull on the adaptor cable! Disconnect cable with pulling the plug cap.

  • Page 27: Switching On Pos

    (12) Switching On POS Press POWER button on the POS unit. (POWER LED will light up.) The power switch is located right hand side of the main body under the display unit. 2. Confirm that Windows loads correctly.

  • Page 28: Shutting Down Pos

    (13) Shutting Down POS * For product stability, we recommend closing Windows from the O/S. Please make sure that you have closed all applications before closing Windows. Click ‘Start’ and select ‘Turn off Computer’ 2. Click ‘Shut Down’ to close Windows. (ex: POSReady2009 or Windows XP)

  • Page 29: System Drivers

    (14) System Drivers Please visit our website: www.posbank.com for the latest driver updates. Supported devices: Cash drawer, CDP (Customer Display Panel), MSR (Magnetic Stripe Reader) and printer. Driver installation ● Installation method : Driver will automatically install by clicking SETUP.EXE in your driver CD.

  • Page 30: Anyshop E2 Module Pos System Replacement

    2. ANYSHOP e2 Module POS System Replacement (1) Separating LCD monitor module * Warning: Completely remove power cable when opening main unit or installing optional devices. LCD monitor module Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 31 LCD monitor module Step3. Lift up the LCD monitor. Step4. Turn the 2 hand-screws to “open” direction. Step5. Remove the monitor cable.
  • Page 32 LCD monitor module Step6 Lift up the LCD monitor module and detach from the main body. Step7. Separate LCD monitor module. Step8. LCD monitor module is now Replacement.

  • Page 33: Separating Hinge Module

    (2) Separating Hinge module * Warning: Completely remove power cable when opening main unit or installing optional devices. HINGE module Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 34 HINGE module Step3. Lift up the LCD monitor. Step4. Turn the 2 hand-screws to “open” direction. Step5. Remove the monitor cable.
  • Page 35 HINGE module Step6 Lift up the LCD monitor module and detach from the main body. Step7. Separate LCD monitor module. Step8. Remove the 4 screws. Step9. Separate the hinge module.

  • Page 36: Separating

    (3) Separating Back cover * Warning: Completely remove power cable when opening main unit or installing optional devices. Back cover Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 37 Back cover Step3. Remove the 2 screws on front Step4. Remove the Back cover pushing It outward. Step5. Separate the Back cover.

  • Page 38: Separating Motherboard

    (4) Separating Motherboard * Warning: Completely remove power cable when opening main unit or installing optional devices. Motherboard Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 39 Motherboard Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 40 Motherboard Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Step5. Remove the cables...
  • Page 41 Separating motherboard Step6. Remove the 4 screws. Step7. Replace the motherboard.

  • Page 42: Separating Hdd

    (5) Separating SSD&HDD * Warning: Completely remove power cable when opening main unit or installing optional devices. SSD&HDD Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 43 SSD&HDD Step3. Raise the main LCD monitor Module. Pull the bottom and lift up the I/O port cover. Step 1 Step 2 Step4. Pull out HDD Tray by pressing the grip.
  • Page 44 SSD&HDD Step5. Open four Tray hinges carefully in opposite directions as in image. Step6. HDD will be separated smoothly. Step7. Assemble HDD bottom to join Tray bottom. Caution: Power must be disconnected before replacing HDD. Before replace the device, remove static electricity of technician.

  • Page 45: Installation Of Optional Devices - Option

    3. Installation of Optional Devices * Warning: Completely remove power cable when opening main unit or installing optional devices. (1) LCD monitor module LCD monitor module Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 46 LCD monitor module Step3. Lift up the LCD monitor. Step4. Turn the 2 hand-screws to “open” direction. Step5. Remove the monitor cable.
  • Page 47 LCD monitor module Step6 Lift up the LCD monitor module and detach from the main body. Step7. Separate LCD monitor module. Step8. LCD monitor module is now Replacement.

  • Page 48: Cdp Module - Option

    (2) CDP module – Option / Domestic demand * Warning: Completely remove power cable when opening main unit or installing optional devices. CDP-Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 49 CDP-Option Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 50 CDP-Option Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Step5. Put holes in the sample place. (Image reference) CABLE Step6. Reassemble Mother board reverse procedure of ‘Step4’.
  • Page 51 CDP-Option Step7. Assemble the CDP module with the mother board bracket of the body. Step8. Assemble CDP module to back of Mother board bracket by hand screw.
  • Page 52 CDP-Option Step7. Reassemble back cover procedure of ‘Step1-4’.

  • Page 53: Nd Display Module -Option / Domestic Demand

    (3-1) 2 Display module –Option / Domestic demand * Warning: Completely remove power cable when opening main unit or installing optional devices. 2nd display(10inch, 12.1 inch monitor) – Option / Domestic demand Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 54 2nd display(10inch, 12.1 inch monitor) – Option / Domestic demand Step3. Lift up the LCD monitor. Step4. Turn the 2 hand-screws to “open” direction. Step5. Remove the monitor cable.
  • Page 55 2nd display(10inch, 12.1 inch monitor) – Option / Domestic demand Step6 Lift up the LCD monitor module and detach from the main body. Step7. Separate LCD monitor module.
  • Page 56 2nd display(10inch, 12.1 inch monitor) – Option / Domestic demand display Step8. Fit lower hinge cap under Hinge to put holes in the sample place. Step9. Assemble the 2nd display with the Hinge. Step10. Fasten 1 screw to fix the hinge. Step11.
  • Page 57 2nd display(10inch, 12.1 inch monitor) – Option / Domestic demand Step12. Remove the I/O Cover. Step13. Fit lower hinge cap under Hinge to put holes in the sample place. (RJ11 PORT, VGA PORT)
  • Page 58 2nd display(10inch, 12.1 inch monitor) – Option / Domestic demand Step14. Carefully equip touch monitor. Step15. Tighten the rear screws in the direction of “LOCK” 2nd display installation complete * The unit is successfully installed if the O/S boots on the 2nd display unit.

  • Page 59: Nd Display Module -Option / Export

    (3-2) 2 Display module –Option / Export * Warning: Completely remove power cable when opening main unit or installing optional devices. 2nd display(10inch, 12.1 inch monitor) – Option / Export Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 60 2nd display(10inch, 12.1 inch monitor) – Option / Export Step3. Lift up the LCD monitor. Step4. Turn the 2 hand-screws to “open” direction. Step5. Remove the monitor cable.
  • Page 61 2nd display(10inch, 12.1 inch monitor) – Option / Export Step6 Lift up the LCD monitor module and detach from the main body. Step7. Separate LCD monitor module.
  • Page 62 2nd display(10inch, 12.1 inch monitor) – Option / Export display Step8. Fit lower hinge cap under Hinge to put holes in the sample place. Step9. Assemble the 2nd display with the Hinge. Step10. Fasten 1 screw to fix the hinge. Step11.
  • Page 63 2nd display(10inch, 12.1 inch monitor) – Option / Export Step12. Remove the I/O Cover. Step13. Fit lower hinge cap under Hinge to put holes in the sample place. (COM3 PORT, VGA PORT)
  • Page 64 2nd display(10inch, 12.1 inch monitor) – Option / Export Step14. Reassemble monitor procedure of ‘Step3-5’. Step15. Tighten the rear screws in the direction of “LOCK” 2nd display installation complete * The unit is successfully installed if the O/S boots on the 2nd display unit.
  • Page 65 2nd display(10inch, 12.1 inch monitor) – Option / Export ※ Bios Setup after 2 display Installation Step16. Connect 2 display to POS device and turn on AC power. Step17. While booting POS device, press ‘Delete’ key and enter into BIOS mode. Select ‘Advanced – Super IO Configuration.
  • Page 66 Step18. After enter to ‘Serial Port 3 Configuration’ mode, select ‘Change Settings – RI # Pin Function’.
  • Page 67 Step19 Change ‘RI# Pin Function - [No Power]’ to ‘+12V’.
  • Page 68 Step20 After saving the configuration please choose ‘Save & Exit Step21 POS terminal will be rebooted. You can see the default is changed into COM3 and 12V ※ Caution: Set the BIOS after assembling 2 LCD with pos terminal...

  • Page 69: Msr Module - Option

    (4-1) MSR Module - Option * Warning: Completely remove power cable when opening main unit or installing optional devices. MSR-OPTION Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 70 MSR-OPTION Step3. Assemble 2 screws from side using hand. (as shown above) Step 4. Assemble the MSR...
  • Page 71 MSR-Option Step 5. Monitor under put holes in the sample place.
  • Page 72 MSR-Option Step6. Access to POSBANK homepage Step7. Click on the button on the toolbar (Position : SUPPORT -> Firmware and Drivers ) Step8. Search the MSR at search engine. Step9. Download the MSR mapper file (file name : [POS Peripherals]MSR Utility _Magnetic Stripe Reader(MSR) Utility) Step10.
  • Page 73 Step11. Click NEXT.. Step12. After the installation is complete 'Select Device' to Make sure that the choice is normally a FW update.
  • Page 74 Check MSR Module type C type Do – MSR DO not – SCR, I-button Interface - Only USB D type Do – MSR DO not –SCR, I-button Interface – USB, Serial E type Do- MSR, SCR, I-button Do not-X Interface – USB, Serial...

  • Page 75: Insert Scr To Msr Module - Option

    (4-2) Insert SCR to MSR Module – Option * Warning: Completely remove power cable when opening main unit or installing optional devices. Insert SCR to MSR - OPTION Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 76 Insert SCR to MSR - Option Step3. Monitor under put out holes in the sample place.
  • Page 77 Insert SCR to MSR - OPTION Step4. Separate 2 screws from side using hand. (as shown above)
  • Page 78 Insert SCR to MSR - Option Step5. Turn screw and remove separate MSR module. (lift up) Step6. Fasten 4 screws to fix the MSR rear case.
  • Page 79 Insert SCR to MSR - Option Step7. Fasten 1 screw to fix the MSR module. Step8. Reassemble a unit using the reverse procedure of step1-4 above.

  • Page 80: Msr+Scr+I-Button (Another Guess) Module - Option

    (4-3) MSR+SCR+I-Button (another guess) Module – Option * Warning: Completely remove power cable when opening main unit or installing optional devices. MSR+SCR+I-Button (another guess) Module – Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 81 MSR+SCR+I-Button (another guess) Module – Option Step3. Assemble 2 screws from side using hand. (as shown above) Step 4. Assemble The MSR+SCR+I-Button.
  • Page 82 MSR+SCR+I-Button (another guess) Module – Option Step 5. Monitor under put out holes in the sample place.
  • Page 83 MSR+SCR+I-Button (another guess) Module – Option Step6. Access to POSBANK homepage Step7. Click on the button on the toolbar (Position : SUPPORT -> Firmware and Drivers ) Step8. Search the MSR at search engine. Step9. Download the MSR mapper file...
  • Page 84 Step11. Click NEXT.. Step12. After the installation is complete 'Select Device' to Make sure that the choice is normally a FW update.

  • Page 85: Usb Module - Option

    (5) USB Module - Option * Warning: Completely remove power cable when opening main unit or installing optional devices. USB-Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 86 USB-Option Step3. Lift up the I/O COVER. Step4. Assemble the USB with the Body. Step5. Fasten 2 hand screw to fix the USB..
  • Page 87 USB - Option Step6. Put holes in the sample place. (USB Port)
  • Page 88 USB - Option Step7. Put holes in the sample lace. (POWER PORT)

  • Page 89: Smart Battery Module - Option

    (6) Smart Battery Module – Option * Warning: Completely remove power cable when opening main unit or installing optional devices. Smart Battery Module Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 90 Smart Battery Module - Option Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 91 Smart Battery Module - Option Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Step5. Put holes in the sample place. (Image reference) and connect smart battery board Smart battery board...
  • Page 92 Smart Battery Module - Option Step6. Connect cable to smart battery board.and connect cable other sub smart battery board Step7. Reassemble Mother board reverse procedure of ‘Step4’. Sub Smart battery board Step8. Insert sub smart battery board assemble by 2 screws.
  • Page 93 Smart Battery Module - Option Step9. Lay down the product on soft cloth. Step10. Use cutter or ripper to remove Smart battery cover. Step11. Insert Smart battery and assemble by 2 screws.
  • Page 94 Smart Battery Module – Option -Warning- 1. When power cable connect the product, Do not disassemble of assemble the products. 2. Check the Smart battery.

  • Page 95: Speaker Module - Option

    (7) Speaker Module - Option * Warning: Completely remove power cable when opening main unit or installing optional devices. Speaker-Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 96 Speaker-Option Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 97 Speaker-Option Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Step5. Assemble 2 Speakers to inner side of body by screws. Step6. Connect each Mother board Speaker connector to Speaker cable.

  • Page 98: 2Nd Hdd Module - Option

    (8) 2 HDD Module - Option * Warning: Completely remove power cable when opening main unit or installing optional devices. 2nd HDD - Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 99 HDD - Option Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 100 2nd HDD - Option Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Step5. Put holes in the sample place. (Image reference) and connect smart battery board Step6. Reassemble Mother board reverse procedure of ‘Step2’...
  • Page 101 HDD - Option ZOOM - IN Step7.Connect SATA Cable to Mother Board. SATA Cable connector position 1 Connector - SATA POWER 2 Connector - SATA DATA ->1/SATA POWER ->2/SATA DATA...
  • Page 102 Step8. Put back Mother board and connect 2nd HDD to SATA cable. Step9. Assemble 2nd HDD to back side of Mother board bracket by hand screw. Step10. Assemble the Back cover before Turn hand screw and assemble Mother board Bracket. (down and push)

  • Page 103: Memory - Option

    (9) Memory - Option * Warning: Completely remove power cable when opening main unit or installing optional devices. Memory -Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 104 Memory -Option Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 105 Memory -Option Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Step5. Place Mother board as in image. Step6. Install the Memory.
  • Page 106 Memory - Option Memory installation position - 2GB SODIMM RAM(DDR3)
  • Page 107 Memory - Option Assemble the SODIMM from the Step7. socket. DDR SODIMM notch...
  • Page 108 Memory -Option Step8. Assemble the Back cover before Turn hand screw and assemble Mother board Bracket. (down and push)

  • Page 109: Cash Drawer - Option

    (10) Cash drawer - Option * Warning: Completely remove power cable when opening main unit or installing optional devices. Cash drawer - Option Step1. Please lift up the I/O cover Step2. Remove the adapter cable. Disconnect cap from base of Unit.
  • Page 110 Cash drawer - Option Step3. Separating Back cover. Caution Step4. Turn hand screw and remove Hook Mother board Bracket. (Pull and lift up) Caution : Look at the frame hook before pull and lift up.
  • Page 111 Cash drawer - Option Zoom in Step4-1 Step4-2 Hook Caution : Look at the frame hook before pull and lift up. Back cover Step5. Use cutter or ripper to remove Io bracket blanking.
  • Page 112 Cash drawer - Option Step6. Assemble a hexa bolt and fasten Screw to cash drawer. Same image about step6.
  • Page 113 Cash drawer - Option Step7. Assemble cable to Mini PCI Board. Zoom-in Step8. Insert Mini PCI Board and fasten two screws..
  • Page 114 Cash drawer - Option Cash drawer No1. : Cash drawer to Mini PCI No2. : Mini PCI to Mother board(COM5) MINI PCI...

  • Page 115: Motherboard

    4. Motherboard (1) Motherboard Overview This includes description of the jumpers and connectors on the motherboard. Warring Take note of the following precautions before you install motherboard components or change any motherboard settings. Unplug the power cord from the wall socket before touching any component. Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.

  • Page 116: Motherboard Layout

    (2) Motherboard Layout This includes description of the jumpers and connectors on the motherboard. Motherboard view...
  • Page 117 NO Description NO Description External USB Inverter USB9 12V/5V Select for 2 Display SYS FAN Display (VGA + COM4) Power switch COM2 12V/R1/5V Reset switch COM1 12V/R1/5V 12V/5V Select for 2 LVDS PS/2 LVDS + COM4 Battery Monitor Main Cable CPU FAN Resistive 5-wire touch SATA Power CN1...

  • Page 118: Jumpers

    (7) Jumpers Clear CMOS (CMOS1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which includes system setup information such as system passwords.
  • Page 119 2.COM1, COM2, RI/+5V/+12V Select (JCOMPWR1 / JCOMPWR2) R1 (Default) +12V 3. LVDS Backlight control mode (JLVDS_P1) None PWM PWM Mode Mode (Default)
  • Page 120 4. LVDS Backlight power selection(JLVDS_P3) 3.3V (Default) 5. VGA2 power selection(CRT_SEL) (Default)
  • Page 121 6. Onboard Touch function Enable/Disable selection(USB_SEL) Disable Enable (Default)

  • Page 122: Bios Setup Utility

    5. BIOS Setup Utility * This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. (1) BIOS setup program This motherboard supports a programmable firmware chip that you can update using the provided utility. Use the BIOS Setup program when you are installing a motherboard, reconfiguring your system, or prompted to “Run Setup.”...
  • Page 123 1.1 Legend Box The keys in the legend bar allow you to navigate through the various setup menus. Key(s) Function Description ←,→ Select Screen ↑,↓ Select Item Enter Select Change Option / Field General Help Previous Value Optimized Defaults Save and Exit Exit...
  • Page 124 1.2 List Box This box appears only in the opening screen. The box displays an initial list of configurable items in the menu you selected. 1.3 Sub-menu Note that a right pointer symbol (▶) appears to the left of certain fields. This pointer indicates that you can display a sub-menu from this field.

  • Page 125: Bios Setup

    (2) BIOS Setup 2.1 BIOS Menu Screen When you enter the BIOS, the following screen appears. The BIOS menu screen displays the items that allow you to make changes to the system configuration. To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu.
  • Page 126 2.2 Main Setup This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. Use this menu for basic system configurations, such as time, date etc. 1. System Language English 2. System Time The time format is <Hour>,<Minute>,<Second>.
  • Page 127 2.3 Advanced BIOS Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Chipset configuration, to go to the sub menu for that item.
  • Page 128 2.4 Launch PXE 0Prom [Disable] Configuration options: [Disabled] [Enabled]...
  • Page 129 2.5 ACPI Settings [S3 (suspend to RAM)] System ACPI parameters. Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed . Wake on LAN control [Disabled] Enable/Disable WOL function Wake on Ring control [Disabled] Enable/Disable Wake on Ring function PS2 KB/MS PME control[Disabled] PS2 keyboard/Mouse PME Control any key or click as wake up event.
  • Page 130 .6 CPU Configuration Hyper-Threading[Enabled] Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) And Disable for other OS(OS not optimized for Hyper-Threading Technology) Execute Disable Bit [Enabled] XD can prevent certain classes of malicious buffer overflow attacks when combine with a supporting OS (Windows Server 2003 SP1,Windows XP SP2,SuSE Linux9.2, RedHat Enterprise 3 update 3.) Limit CPUID Maximum[Disable] Disable for Windows XP...
  • Page 131 2.7 IDE Configuration • IDE Devices configuration SATA Controller[Enable] SATA ports(1-2)Device names if Present and Enable. Configuration SATA as [AHCI] Select a configuration for SATA controller . SATA Port 1/2 [Enable] SATA port(1-2) Enable/Disable...
  • Page 132 2.8. USB Configuration • USB configuration Parameters Legacy USB support [Enable] Enables Legacy USB support AUTO option disable legacy support if no USB device are connected DISABLE option will keep USB device available only for EFI applications EHCI Hand-off[Enable] This is a workaround for OSes without EHCI hand-off support the EHCI ownership change should be claimed by EHCI driver .
  • Page 133 2.9 Super I/O Configruation • System supper I/O CHIP parameters Serial Port 1 configuration Set parameters of serial port 1 (COM1) Serial Port 2 configuration Set parameters of serial port 2 (COM2) Parallel Port configuration Set parameters of parallel port Serial Port 3 configuration Set parameters of serial port 3 (COM3) Serial Port 4 configuration...
  • Page 134 Serial Port 6 configuration Set parameters of serial port 6 (COM6) AC Power Loss state[Always OFF] Set the state after power loss. Watch Dog count Mode[Second(s) Mode] Select watch Dog count mode. Watch Dog Time-out Value Timer will start to count from end of POST .00- Time out Disable.
  • Page 135 2.10 Hardware Monitor Smart Fan Mode configuration Smart Fan Mode select...
  • Page 136 System smart fan mode [Disable] System smart Fan mode select CPU smart fan mode [Disable] System smart Fan mode select...
  • Page 137 2.11 Chipset...
  • Page 138 2.12 Host Bridge Host bridge parameters Memory Frequency and Timing Display memory Frequency and Timing settings.
  • Page 139 2.13 Boot Display Configuration...
  • Page 140 2.14 LCD Panel type [VBIOS Default] Select LCD Panel used by internal Graphics Device by Select the appropriate setup item.
  • Page 141 Color depth [24Bits] Select color Depth for LVDS...
  • Page 142 2.15 South Bridge parameters Into South Bridge Subdiredtory...
  • Page 143 TPT Devices Set parameters of INTEL IO controller Hub(TPT) devices PCI Express Root port 4 Set parameters of PCI Express Root port 4 settings Onboard LAN controller [Enabled] Enable or Disable onboard LAN controller...
  • Page 144 2.16 Boot...
  • Page 145 2.17 Security Administrator password Set administrator password User password Set User password...
  • Page 146 2.18 Save & Exit Save Changes and Exit  Exit system setup after saving the changes. Discard changes and Exit  Exit system setup without saving any changes. Save changes and Reset  Reset teh system after saving the changes. Discard changes and Reset ...
  • Page 147 Discard changes done so far to any of the setup options. Restore Defaults  Restore/Load Default values for all the setup options. Save as User Defaults  Save the changes done so far as User Defaults Restore User Defaults  Restore the User Default to all teh setup options.

  • Page 148: Troubleshooting

    6. Troubleshooting (1) Network Issues Symptom Corrective Procedure ▪ Check if hub or switch is working correctly Cannot access LAN ▪ Check RJ45 cable connection ▪ Check if LAN LEDs are on/off ▪ Reinstall LAN card ▪ Replace motherboard (2) MSR Issues Symptom Corrective Procedure ▪...

  • Page 149: Touch-Screen Issues

    (5) Touch-screen Issues Symptom Corrective Procedure ▪ Check touch-screen cable connection Touch-screen doesn’t detect touch ▪ Check motherboard and LCD cable connection operations ▪ Check BIOS set-up (6) Power Issues Symptom Corrective Procedure ▪ Check A/C cable connection System switches off abruptly and ▪...

  • Page 150: Maintenance

    7. Maintenance Safety Warning POSBANK will not be held responsible for repairs conducted via service providers other than those officially specified by the seller. General Guidelines Always disconnect the unit from the power outlet. 2. Disconnect all cables from the POS main unit before attempting reparation.

Table of Contents

Save PDF
