Appendix 1: Changing AXIS cameras settings

The Ax-Tv unit will request a video stream from the camera as necessary in each case (resolution,
compression, etc.) for optimum operation as digital cameras (VX units) as IP cameras and IP ONVIF
cameras.
You have the option to create profiles to adjust the cameras appearance, resolution, compression
and image size, only for native AXIS cameras (without ONVIF protocol active), if you deem it
necessary to modify the AXIS cameras operation.
You can create up to four profiles that correspond to the four different views that are available on the
AX-TV. The profile name is AX-TV x where x correspond to the view type that the Ax-Tv provides (1,
4, 9 o 16 cameras).
To create these profiles you have to access the IP camera Setup menu, in the list on the left select
Video & Audio and then, select Stream Profiles.
In this window are the camera list profiles, press the Add button to create a new profile.
1. - Into the Image section insert the camera name, AX-TV x and select into Video Encoding
section the MPEG option.
2. - In the Image Appearance section select the resolution. Shown below are the maximum values
that can be selected for each profile.
Into this section you can increase the compression if necessary.
3. - In the Video Stream section you can configure the maximum frame rate via two options, select
unlimited or set a limit (maximum is 30 images/frames per second.
4. - In the MJPEG tab you can specify the maximum frame size or select the size by default.
User Manual - 12
16:9
AX-TV1 1280 x 720
AX-TV4 640 x 360
AX-TV9 480 x 270
AX-TV16 320 x 180
4:3
800 x 600
480 x 360
320 x 240
240 x 180
