Direct-vent gas fireplace inserts elite series

Advertisement

The Ravenna™ fireplace insert is factory equipped for 40,000 BTU
input and can be converted to 33,000 using the smaller orifice provided.
Retain These Instructions For Future Reference
A French manual is available upon request. Order P/N 775,218CF. Ce manuel d'installation
est disponible en francais, simplement en faire la demande. Numéro de la pièce 775,218CF.
I
n the Commonwealth of Massachusetts:
• Installation must be performed by a licensed plumber or gas fitter
• See Table of Contents for location of additional Commonwealth
of Massachusetts requirements
Hot! Do not touch! The glass and surfaces of this appliance will be hot during operation and will
retain heat for a while after shutting off the appliance. Severe burns may result.
Carefully supervise children in the same room as appliance.
Suitable for installation into masonry or factory built fireplaces. These appliances may be installed in an after-
market permanently located, manufactured (mobile) home (USA only), where not prohibited by local codes. This
appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible
for use with other gases unless a certified kit is used.
Lennox™ gas-burning appliances are designed for use as a supplemental heater. They are not intended for
continuous use as a primary heat source.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not light any appliance.
• Do not touch any electrical switch; do not
Use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow your gas supplier's
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier
INSTALLATION AND OPERATION MANUAL
Direct-Vent Gas
Fireplace Inserts
P/N 775,218M Rev. B, 12/2007
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides inflammables à proximité de
cet appareil ou de tout autre appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une odeur
de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur.
• Ne pas vous servir des téléphones se trouvant dans le bâti-
• Appelez immédiatement votre fournisseur de gaz depuis un
• Si vous ne pouvez rejoindre le fournisseur de gaz, appelez
L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
.
fournisseur de gaz.
Ravenna™ 33/40 (RDV33/40)
US
Report No. 050-S-15c-5
WARNINGS
AVERTISSEMENT: Assurez-vous de bien suivre les instruc-
tions données dans cette notice pour réduire au minimum
le risque d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
ment
voisin. Suivez les instructions du fournisseur.
le service des incendies.
Shown with Cast Pillar face

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAVENNA RDV3340 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lennox Hearth Products RAVENNA RDV3340

  • Page 1 The Ravenna™ fireplace insert is factory equipped for 40,000 BTU input and can be converted to 33,000 using the smaller orifice provided. Retain These Instructions For Future Reference A French manual is available upon request. Order P/N 775,218CF. Ce manuel d’installation est disponible en francais, simplement en faire la demande.
  • Page 2: Autions Afety

    FOR YOUR SAFETY do not install or operate your  Ravenna™ gas insert without first reading & under- standing this manual. Any installation or operation of the appliance deviating from that which is stated in this manual WILL void the warranty & may be hazardous. INSTALLATION &...
  • Page 3: Table Of Contents

    & s ... 2 autions afety rifiCe ltitude djustment ... 4 ireplaCe equirements & a ... 4 odes pprovals (mea) ... 5 equirements ommonwealth of ...6-8 nstallation ... 6 eatures ... 6 aCkaging ... 6 atings & f nsert ireplaCe imensions ...
  • Page 4: Smoke Detectors

    Orifice Size/Altitude Adjustment For altitudes above 2,000 feet (In Canada 4,500 FT/1370 M),the orifice should be de-rated by 4% for every 1,000 feet to maintain the proper ratio of gas to air. Improper orifice sizing may result in damage and unsafe conditions. Chang- ing the orifice should only be done by a qualified service technician. Contact your Lennox Hearth Products dealer for proper orifice sizes. The Ravenna™ Insert • Must conform with all local, state, and national installation codes. In the absence of local codes, the installation must conform with National Fuel Gas Code ANSI Z223.1 - latest edition, also known as NFPA 54 (In Canada, the current CAN/CSA B149.1 installation code). Refer to the National Fuel Gas Code and local zoning and code authorities for details on installation requirements. • Mobile home installations must conform with the Mobile Home Construction and Safety Standard, Title 24 CFR, Part 3280 (in Canada CAN/CSA Z240 MH), or, when such a standard is not applicable, the Standard for Mobile Home Installations, ANSI A225.1 - latest edition. • Must be vented directly to the outside in accordance with the latest edition of the National Fuel Gas Code and must never be attached to a chimney serving a separate solid fuel burning appliance. • Has been certified for use with either natural gas or pro- pane. • Is not for use with solid fuels. • Is approved for sitting rooms and/or bedrooms. Fireplace Requirements These heaters are designed to be installed into an existing masonry fireplace (built to UBC 37 or ULC S628 standards) or factory built solid fuel, wood burning fireplace (listed to...
  • Page 5: New York City, New York (Mea)

    New York City, New York (MEA) Installation of these fireplaces are approved for installation in New York City in the US state of New York (MEA#: 138-07-E). Commonwealth Of Massachusetts Requirements Note: The following requirements reference various Massachusetts and national codes not contained in this document. For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: Installation Of Carbon Monoxide Detectors At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gas-fitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on the floor level where the gas equipment is to be installed.
  • Page 6: Pre-Installation

    Pre-Installation eatures Installation Options Manufactured (Mobile) Home N atural Gas Or Propane (LP) Bedrooms Optional Wall-mounted Or Remote Thermostat Electrical The standard fan motor requires 120 Volts AC for operation. The fireplace is not dependent on the fan or an outside elec- trical supply to operate. WARNING - Electrical Grounding Instructions - This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle.
  • Page 7: Nsert Ireplace Imensions

    nsert imensions 31-1/4” (794mm) 13-3/4” (349mm) Top View Figure 1 15-3/4" (400mm) 19-1/2" (495mm) 19-3/4 (502mm) Figure  Side View Insert Dimensions Width of insert behind Surround Panels Rear height Insert depth into fireplace Flue collar diameter (OD) -15/1" inimum ireplaCe pening equired...
  • Page 8: Clearances To Combustibles

    Clearances to Combustibles IMPORTANT: If unit is converted to an RDV33 from an RDV40, the clearances to combustibles can be reduced as shown on this page. WARNING: If this unit is ever converted back to an RDV40, ensure that the clearances are correct for this model. inimum learanCes to ombustibles...
  • Page 9: Installation

    Installation enting nstallation Your Lennox™ gas insert must be vented to the outside in accordance with the current edition of the National Fuel Gas Code ANSI-Z223.1 (In Canada, the current CAN/CSA B149.1 installation code). The insert must not be connected to a chimney flue serving a separate solid fuel burning ap- pliance. This gas insert requires a 3” diameter listed flex liner. The vent should terminate with a listed direct vent termination cap. The chimney should be sealed around the cap to pre- vent air and rain from entering the chimney. Adhere to the vent manufacturer's instructions for installation and vent termination. These appliances are approved for use with the following vent kits. Vent Kits * Cat. No. Model Description H0909 FKDVI Flex Liner Kit, DVI 3” X 35’...
  • Page 10: Z Ero C Learance F Ireplace I Nstallation

    learanCe ireplaCe nstallation This insert may be installed in a masonry or factory built/zero clearance (ZC) fireplace. When installing in a ZC fireplace, the ZC grate must be removed and the ZC damper must be removed or secured open. The ZC doors, screen, refractory or masonry lining, baffles, and smoke shelf may be removed if necessary to install the gas insert. However, do not cut or alter the fireplace components. The removal of any parts to facilitate installation must not alter the integrity of the inner or outer shells of the fireplace cabinet. Any parts removed must be replaceable if the insert is taken out of the fireplace or the fireplace clearly marked with a paint stick that "This fireplace has been altered and is no longer safe to operate." The insert is designed to fit into a ZC fireplace with a mini- mum firebox height of 19-1/2" (495mm). To facilitate this the hood will need to be removed and discarded (Note: the screws should be replaced in the insert body). If the factory-built fireplace has no gas access hole(s) pro- vided, an access hole of 1-1/2" (37.5 mm) or less may be drilled through the lower sides or bottom of the firebox in a proper workmanship like manner. This access hole must be plugged with a non-combustible insulation after the gas supply line has been installed. The installer must mechanically attach the marking supplied with the gas fireplace insert to the inside of the firebox of the fireplace into which the gas fireplace insert is installed. ™ 40 C avenna onversion To convert to a Ravenna 33 gas insert, after step 1 remove and replace the stock burner orifice with the #36 NG orifice supplied in the installation manual bag. Pipe dope or other approved gas line sealant will need to be applied before insert- ing into bulkhead. The foil sticker supplied, stating RDV33, will need to be affixed over the model name RDV40 on the serial number label (located in the control compartment). &...
  • Page 11: Urround Anels Nstallation

    4. Install a light layer of rockwool directly over the ports. - A light layer will give a more constant rear flame. - A heavy layer will give more glow, but will need to be adjusted after light up. Figure 10 5. Install front logs on retainer slots. Figure 11 Front Logs 6. Place embers around the perimeter of the rockwool. IMPORTANT!!! Do not cover the ports with the embers. 7. Place top log on pin. Top Log Ports Figure 1 urround nstallation The Ravenna™ insert surrounds are made of heavy gage steel for durability and, if desired, for the ease of making an inside fit in the fireplace. See Packaging List for avail- able sizes. 1. Remove the speed nuts (A in Figure 13) from the parts bag and install (with the flat surface forward) on the six holes in the surround brackets - three on each side of the insert (B in in Figure 13). A flat bladed screwdriver may help in installing the nuts. 2. Install all surround panels and trim with the insert po- sitioned in the fireplace, but a few inches in front of its final location. 3. If an Arch face is to be installed on the insert, the sight obstructor that comes with the face must be installed prior to installing the surround panels. See the instruc-...
  • Page 12: Air Shutter Adjustment

    Gas Line Installation After leveling, position the insert in the fireplace - holding it about six inches out from its final location. Caution: Specific hearth requirements apply (see Clear- ances to Combustibles). The Ravenna™ gas insert must be connected to the gas line in accordance with local codes and/or the National Fuel Gas Code, ANSI Z223.1 (In Canada, the current CAN/CSA B149.1 installation code). The insert comes with an 8" nipple attached to the supply side of the gas valve. After connect- ing the gas line, all joints in the line and connections at the valve should be checked for leaks before final positioning of the unit. Conduct a gas leakage test of the appliance piping and control system downstream of the shutoff valve in the supply line to the appliance. ressure equirements A MAJOR CAUSE OF OPERATING PROBLEMS WITH GAS APPLIANCES IS IMPROPER GAS PRESSURE! The most important item to check during the initial installation and the first thing to check when operating...
  • Page 13: Re Ighting Hecklist

    See Detail Shutter Figure 15a Adjustment Moving shutter bracket to the right will open shutter, to the left will close shutter. Figure 15b Shutter Adjustment Detail SHUTTER ADJUSTMENT DETAIL Operating Instructions ighting heCklist Be sure to check these items before the initial lighting of the insert: The insert gas label corresponds to the gas supply avail- able - that is "natural gas" for natural gas or "LP gas" for LP gas. Gas pressure has been checked carefully - see Page 12. All gas fittings have been checked for leaks. c All clearances to combustibles have been met-see Page 8.
  • Page 14 5. Locate the pilot by looking over the top of the left front log. A blue flame will be seen when the pilot is lit. 6. Turn the gas control knob counter-clockwise to the "PILOT" position. 7. Push the knob all the way in and hold in that position. Immediately light the pilot by pressing the igniter button several times until pilot is lit. Continue to hold the knob in for about 30 seconds after the pilot is lit. Realease knob and it will pop back out. Pilot should remain lit. If it goes out, repeat steps 4-8 holding knob in an additional 15 seconds after pilot is lit. If knob does not pop out when released, stop and immediately call your service technician or gas supplier. If the pilot will not stay lit after several tries, turn the gas control knob to "OFF" and call your service technician or your gas supplier. 8. After pilot is lit, turn gas control knob counter-clockwise to "ON." Knob can only be turned to "ON" if the knob has popped out. 9. To turn burner on, turn "ON/OFF" rocker switch to "ON" or set the thermostat to the desired temperature above room temperature.
  • Page 15: Paint Curing

    Flame Color & Behavior Your Ravenna™ gas insert is designed for maximum heat- ing efficiency. Therefore, upon lighting of the main burner the flames will be semi-transparent or “bluish.” After 10-20 minutes of operation the logs will heat up and the flames will become a yellow/orange color. Adjusting the insert to cause the flames to turn orange sooner may result in poor combustion, sooting, and a hazardous situation. See Figure 17 showing proper flame appearance. When testing for proper operation - If an optional thermo- stat is installed adjust it to its highest temperature setting. Visually determine that main burner gas is burning properly: i.e., no floating, lifting or flashback. Adjust the primary air shutter(s) as required. Check for proper main burner opera- tion at both high and low flame. Burner Flame Appearance Soot above Soot at Flame Tip Flame Tip...
  • Page 16: O Perating O Ptions

    perating ptions The rocker switch on your Ravenna™ gas insert is used to turn the burner on and off while the pilot is on. The rocker switch can be installed in the hole in the right side of the top surround panel or in the hole in the panel to the left of the igniter button. The hole in the panel is covered by a label which must be carefully cut out before installing the rocker switch. The switch must be disconnected from the coil of wire to which it is attached, the plastic nut unscrewed from the back side of the switch, and then the switch can be inserted into the hole at either location. If the switch is to be located in the surround, route the wire behind the igniter bracket and through the hole in the lower right side of the insert. Attach the three plastic adhesive wire restraints (found in the bag in the firebox) to the side surround panel. Feed the wire through these restraints and up to the switch. Care should be taken to ensure the wire does not come in contact with the hot surfaces of the firebox. Reconnect the wires to the switch. A wall-mounted switch, a millivolt wall thermostat, or a remote control, can be used to supplement the rocker switch. The gas valve is powered by millivolts generated by the pilot assembly. This millivolt system is very sensitive to electrical resistance, therefore, make sure all connections...
  • Page 17: Maintenance And Servicing

    Maintenance & Servicing aintenanCe heCklist The following should only be performed by a qualified service technician. Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. 1. Annual inspection should be made and the following checks performed: oWhen unit is cool, remove glass and inspect burner for dirt, soot, and lint accumulations, and remove if neces-...
  • Page 18: Electrical Requirements

    lass emoval Caution: Do not slam or strike glass door or damage may occur. Do not remove the glass door while the insert is hot. To re- move the glass door, pull forward and up on the top latches. Lift the glass door up and off the lower spring latch. Be careful not to damage or scratch the glass while handling. To reinstall the glass, reverse the removal steps. Do not operate the insert with the glass removed. (A) Spring Handle Latches (B) Door Mounting Plates Figure 0...
  • Page 19: Troubleshooting

    Troubleshooting NOTE: When troubleshooting the gas control system, be sure the external gas shut off valve, located at the gas sup- ply inlet is in the “ON” position. IMPORTANT: Call your gas supplier or plumber for additional help with any gas control problem. Valve system troubleshooting should only be accomplished by a qualified service technician.
  • Page 20: Replacement Parts

    Replacement Parts Ravenna™ 33/40 (RDV33/40) Part Number Description H3132 Cassette Assembly NG 33,000 BTU (if LP, also requires H5433 Conversion Kit) H3045 Cassette Assembly NG 40,000 BTU (if LP, also requires H5433 Conversion Kit) H6010 Burner Assembly H5922 Pilot Assembly Convertible, NG or LP H5938 Gas Control Valve NG (if LP, also requires H5941 LP Regulator) H5939 Regulator, NG H5941 Regulator, LP H5924 Orifice Main Burner #36 NG 33,000 BTU H5963 Orifice Main Burner 1/8" NG 40,000 BTU H5926 Orifice High Altitude Main Burner #37 NG 33,000 BTU H5971 Orifice High Altitude Main Burner #30 NG 40,000 BTU H5925 Orifice Main Burner #51 LP 33,000 BTU H5929 Orifice Main Burner #49 LP 40,000 BTU H5927 Orifice High Altitude Main Burner #52 LP 33,000 BTU H5972 Orifice High Altitude Main Burner #53 LP 40,000 BTU H5433 Conversion Kit, NG to LP H5434...
  • Page 21 Finish Panels/front Supports Cat. No. Description 755 "ZC Lower Finish Panel/Bay Face Support *Requires Trim Pieces below" 7553 "ZC Lower Finish Panel/Reg Face Support *Requires Trim Pieces below" 7551 Front Support Ext. Trim Black 750 Front Support Ext. Trim Gold 7503 Front Support Ext.
  • Page 22: Safety / Listing Label

    SAFETY / LISTING LABEL MODEL Ravenna™ Ravenna™ 40 MODÈLE MANUFACTURED BY / FABRIQUÉ PAR: LENNOX HEARTH PRODUCTS PO BOX 987 Report No. / Número de Rapport AUBURN, WA, USA 98071 050-S-15c-5 FACTORY EQUIPPED FOR NATURAL GAS. IF CONTROL PANEL CONTRADICTS THIS LABEL, UNIT FUEL TYPE HAS BEEN CONVERTED. CET APPAREIL EST MUNI D’ÉQUIPEMENT POUR L’USAGE DU GAZ NATUREL.
  • Page 23: To Turn Off Gas To Appliance

    Lighting Label FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, INJURY OR LOSS OF LIFE. CAUTION: HOT WHILE IN OPERATION. DO NOT TOUCH. KEEP CHILDREN, FURNITURE, GASOLINE AND OTHER LIQUIDS WITH FLAMMABLE VAPORS AWAY.
  • Page 24: Warranty

    WARRANTY Your gas appliance is covered by a limited warranty (provided with appliance). Please read the warranty to be familiar with its coverage. Retain this manual. File it with your other documents for future refer- ence. PRODUCT REFERENCE INFORMATION We recommend that you record the following important information about your appliance. Please contact your Lennox Hearth Products dealer for any questions or concerns. For the number of your nearest Lennox Hearth Products dealer, please call 1-800-9-LENNOX. REPLACEMENT PARTS See Page 20 for a complete replacement parts list. Use only parts sup- plied from the manufacturer. Your Appliance's Model Number _______________________________________ Your Fireplace Insert’s Serial Number ___________________________________ The Date On Which Your Fireplace Insert Was Installed _ _____________________ The Type of Gas Your Fireplace Insert Uses _______________________________ Your Dealer's Name _________________________________________________ Fuel Type (Check one) c Natural Gas c Propane Gas (LP)
