Please read and comply with
these original instructions prior
English
to the initial operation of your appliance and
store them for later use or subsequent own-
ers.
Contents
Safety instructions . . . . . . .
Function . . . . . . . . . . . . . . .
Proper use . . . . . . . . . . . . .
posal . . . . . . . . . . . . . . . . . .
ments . . . . . . . . . . . . . . . . .
Operation . . . . . . . . . . . . . .
Transport. . . . . . . . . . . . . . .
Storage . . . . . . . . . . . . . . . .
Faults . . . . . . . . . . . . . . . . .
Specifications . . . . . . . . . . .
Spare parts . . . . . . . . . . . . .
Warranty . . . . . . . . . . . . . . .

Safety instructions

Before using the appliance for the first time,
read and observe these operating instruc-
tions and the accompanying brochure:
Safety information for brush cleaning units
and spray-extraction units, 5.956-251.
The machine has been approved for use on
surfaces with gradients of up to 10%.
Behaviour in emergency situations
Press emergency stop button in an emer-
gency. The appliance will be shut off and
the park brake will be locked.
Safety Devices
Safety devices serve to protect the user
and must not be rendered inoperational or
their functions bypassed.
Emergency-stop button
To put all functions out of operation imme-
diately: Press emergency-stop button.
Safety pedal
The drive can only be activated when the
operated keeps the pedal depressed with
the foot.
Symbols
The following symbols are used in this op-
erating manual:
Danger
Immediate danger that can cause severe
injury or even death.
Warning
Possible hazardous situation that could
lead to severe injury or even death.
Caution
Possible hazardous situation that could
lead to mild injury to persons or damage to
property.
12
The device is meant for vacuuming carpet-
ed surfaces. The dirt is loosened from the
carpet by brushing; it is then vacuumed and
collected in a filter bag.
A working distance of 850 mm will im-
-
prove the efficiency when you are using
the appliance for a long period.
The appliance is self-driven.
-
The batteries can be charged using a
-
charger connected to a 230 V socket.
All models are equipped with a built-in
-
charger.
The model CV 60/2 RS Bp Pack in-
-
cludes batteries.
For model CV 60/2 RS Bp, batteries
must be ordered separately.
Note
The appliance can be equipped with vari-
ous accessories depending on the cleaning
task and the location site.
Please request our catalogue or visit us on
the Internet at www.kaercher.com.
EN . . 9
Use this appliance only as directed in these
operating instructions.
The appliance should only be used for
-
vacuuming carpeted floors.
The appliance may only be equipped
-
with original accessories and spare
parts.
The appliance is not intended for the
-
cleaning of public traffic routes.
The application temperature ranges
-
from +5°C to +40°C.
The machine should not be used on
-
surfaces that are sensitive to pressure.
Please consider the allowed load per
surface unit of the floor. Details of load
per surface unit can be found in the
technical data.
The appliance is not suited for the use
-
in potentially explosive environments.
The machine is not suitable for vacuum-
-
ing dust which endangers health.
Reactive metal dusts (for e.g. alumini-
-
um, magnesium, zinc) can form explo-
sive gases when they come in contact
with highly alkaline or acidic detergents.

Function

Proper use

-
EN
1
Environmental Protection,
Disposal
The packaging materials are
recyclable. Please do not throw
packaging in the domestic
waste but pass it on for recy-
cling.
Old units contain valuable recy-
clable materials. Batteries, oil
and similar substances may
not be released into the envi-
ronment. Therefore please dis-
pose of old units through
suitable collection systems.
Notes about the ingredients (REACH)
You will find current information about the
ingredients at:
www.kaercher.com/REACH
