1.1 General Description

This camera is a digital scouting camera with Incandescent Flash. It is triggered
by any movement of humans or animals monitored by a high sensitive Passive
Infrared (PIR) motion sensor, and then automatically captures high quality pictures
(up to 5M pixels) or records video clips (VGA) according to default settings or preset
customer settings.
This camera uses integrated xenon flash instead of IR LED lamination .It can take
color images day and night. It also can take video clips during the day.
It has a durable and compact shape with low power consumption. It will take up
to 1200 flash pictures with 8AA batteries and supports up to an 8 GB SD card.
The device is designed for outdoor use and is resistant against water and snow.
Furthermore, the camera can be used as a portable digital camera. Pictures or videos
can be taken manually by pressing OK on the control in TEST mode (The
programmer remote needs to be connected).
1.2 Application
This camera can be used as an automatic surveillance device for guarding and
recording unexpected intrusion to homes, shops, schools, offices, cabins, private
property, worksites etc. It can also be used as a trail camera for hunting or monitoring
animals by recording the traces of wild animals. It can be left alone for weeks and
months and it will deliver event records automatically in digital format to the SD card.

1.3 Camera Body Interfaces

The camera has the following I/O interfaces: USB connector, SD-card slot, TV
output and external DC power connector.
On the bottom of camera, there is a lock hole for theft-proof.
Take a few moments to familiarize with the camera controls and displays. It is
helpful to bookmark this section and refer to it when reading through the rest of the
manual.
