Frigidaire Venice WLVF-1/0343 Important Instructions & Operating Manual page 8

Wall hanging fireplace with led flame technology & digital display
Hide thumbs

Advertisement

Place the front frame over the front of the fireplace aligning the slots in the bracket at each side
of the glass panel with the knobs on the sides of the fire (see figure below). Two people will be
required for this operation.
Instructions for Use
This fireplace can be operated either by the switches located on the top right hand side of the
fireplace or the supplied remote control.
Manual Operation
The switches are located on the top right hand side of the fireplace. The standby switch must
first be turned on.
Press the
button once to turn on the fireplace and flame effect. A red indicator light will
appear to indicate that the function is ON.
Press the 750W button once for low heat setting; press twice to turn off the heat.
Press the 1500W button once for high heat setting; press twice to turn off the heat.
Remote Control Operation
The power switch
fireplace will beep to indicate that it is powered up.
Insert 2 x AAA batteries (not included) into the battery compartment of the remote control.
Make sure they are inserted with the correct polarity. (The -/+ signs placed in the proper
position.) Securely close the battery compartment cover.
It takes some time for the receiver to respond to the transmitter. Do not press any buttons on
the remote control more than once within two seconds in order for the fireplace to operate
properly.
Press the standby button
effect.
Press the "LOW/HIGH" to switch between Low and High Heat settings.
Press the "TEMP" button to adjust the thermostat to reach the desired temperature.
located at the right hand side of the fireplace must first be switched on; the
on the remote control once to turn on the fireplace with flame
8
