- Page 1 Call Centre No. 0XX-39889000(0XX-STD Code of State Capital) Post / Visit Post the Warranty Registration Card & Service Centre Model: Copy or Visit the Nearest Service Centre. S093SMH,S122SMH,S182SMH,S123SMH, S183SMH. The unit displayed is for representational purposes only. Actual unit may vary.
- Page 2 Dear customer Congratulation on buying ONIDA Air Conditioner. Y our Air Conditioner comes with ONIDA Guarantee of Quality as detailed in the manual. ONIDA takes great pride in providing its customers with state- of-the-art products that adheres to international quality standards.
-
Page 3: Table Of Contents
CONTENTS Salient Features Inside Overview Indoor Unit Display Remote Overview Operations General Instructions for Installation Installation Sketch Installation of Model Take care of your Air Conditioner Precautions to be taken Trouble Shooting Chart Installation and Satisfaction Report Warranty Terms & Conditions Preventive Maintenance Service Coupon Warranty Card(Customer Copy) Warranty Card(service Centre Copy) -
Page 4: Salient Features
SALIENT FEATURES 0.8T/ 1.0T / 1.5T Split Air Conditioner Model Code : S093SMH,S122SMH,S182SMH,S123SMH,S183SMH. • Aesthetics:- a) Unique Flat Panel b) Sleek Indoor Unit • Performance:- a) 3 Star / 2 Star Energy Saver BEE Rated b) High BTU Tropicalised Compressor... -
Page 5: Inside Overview
INSIDE OVERVIEW INDOOR UNIT DISPLAY INDOOR UNIT Display on the indoor unit. For the icon of LED windows, only relevant icons will light up with their displays on. Front panel Return warm Air in Conditioned Air out Timer Mode Sleep Deflector Display iCOOL... -
Page 6: Remote Overview
REMOTE OVERVIEW OPERATIONS IR Signal Window Operating Your Air Conditioner: Your Split Air Conditioner can be conveniently operated using the intelligent cordless remote control. Switch on the MCB. Operation Display Press Standby button on remote handset to switch ON the AC. All icons will glow once. -
Page 7: Operations
OPERATIONS OPERATIONS i-Cool (With Ceiling Fan Controller):- The AUTO Mode : 1. Press "MODE" button to cyclically step through the TURBO-AUTO-COOL-DRY-ECO-FAN One touch auto cooling control of AC & Ceiling Fan*. modes and stop when AUTO mode is selected. This mode is activated by pressing i-cool key on remote. To enable mode to control Ceiling Auto symbol can be seen on the Remote panel. -
Page 8: Turbo/Eco/Favorite/Smart-Sleep Mode
OPERATIONS OPERATIONS SMART-SLEEP MODE: Turbo MODE: Press Mode Button cyclically step through the TURBO-AUTO-COOL-DRY-ECO-FAN modes 3 Stage Smart-Sleep with 4 personal preference modes, and stop when TURBO mode is selected, It activates the Turbo function and air conditioner To switch on Smart-Sleep operation, press “SLEEP” button on remote and the indoor fan goes to powerful cooling. -
Page 9: Air Flow Direction Adjustment
OPERATIONS OPERATIONS TIMER Operation: You can program your split AC to switch itself ON or OFF at particular time. Air Flow direction Adjustment: Maximum set time is 24 hrs, with 1.0 hr increment . Your split AC has oscillating louvers for uniform cooling around your room. ON TIMER: You can stop the oscillation if you so desire. -
Page 10: General Instructions For Installation
Once again, the Onida / dealer's Technician will ensure optimal installation of the ODU for Locating the Indoor Unit you. However, the following information will •... -
Page 11: Installation Sketch
GENERAL INSTRUCTIONS FOR INSTALLATION SKETCH INSTALLATION • Avoid long and complicated routing between the IDU and ODU, as shown in the three adjacent figures. • Too long Indoor unit accessories Quantity Mounting Plate • Too high Tapping Screw ST4 X 25 Expansion Rubber Plug •... - Page 12 INSTALLATION INSTALLATION Connecting of cables INDOOR UNIT 1. Open the front panel 1. Fitment of mounting plate Electrical box cover 2. Dismentle the electric box cover The mounting plate should be fitted on the structural part of wall on which indoor unit Indoor unit and fastener terminal...
- Page 13 INSTALLATION INSTALLATION n Connecting of pipes Add refrigerant Model Pipe Diameter of pipe Torque (N • m) • If the connecting pipe is longer than 7 meters, add refrigerant as needed. Add Liquid pipe 6.35 mm 13.7--17.6 1.0 T amount A= (Lm-7m) 15g/m. 12.7 mm 49.0--56.4 Gas pipe...
-
Page 14: Take Care Of Your Air Conditioner
TAKE CARE OF YOUR PRECAUTIONS TO BE TAKEN AIR CONDITIONER Most of the maintenance work on your air Do's ( c o n d i t i o n e r, d u r i n g w a r r a n t y a n d subsequently under the maintenance •... -
Page 15: Trouble Shooting Chart
TROUBLE SHOOTING CHART Symptoms Possible Causes Suggested Remedy Unit does not start MCB has tripped Reset MCB Fuse has burnt Replace fuse wire Input voltage to the If the input voltage to stabiliser is below the stabiliser is below acceptable range the acceptable range, the AC will not operate Press the On/Off key... -
Page 16: Installation And Satisfaction Report
INSTALLATION & SATISFACTION REPORT Customer Name : Address Phone[O] Unit Model Unit Serial Number Dealer Name Invoice Number Date of Purchase Date of Installation MCB Rating Current (Amps.) Cable Size Ambient Temp. ( C) Earthing Room Temp. ( C) Stabiliser Grill Temp. -
Page 17: Warranty Terms & Conditions
WARRANTY TERMS AND CONDITIONS M/S. MIRC ELECTRONICS LTD, WARRANTS THIS ONIDA AIR CONDITIONER[(except the front grill, knobs, remote unit and add-on plastic parts) TO THE ORIGINAL PURCHASER TO BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP WITHIN ONE YEAR FROM THE DATE OF PURCHASE AS PROVIDED IN THE WARRANTY REGISTERATION CARD. -
Page 18: Preventive Maintenance Service Coupon
Preventive Maintenance Service Customer Identification 8. It shall be the absolute discretion of the company to a) effect the repairs or replacement of parts Number: whether at the site of installation or at any service centre, and b) have the job attended to either by the Preventive Maintenance Service 1 Date: ________ Company's service personnel or its authorised dealer... -
Page 19: Warranty Card(Customer Copy)
We welcome your Valuable Suggestions, if any, to Improve our Products and Services : FOR OFFICE USE ONLY Customer Code: Branch: Mirc Electronics Ltd. For Other Details on Our Products & Services Log On To www.onida.com Note: Company Will Not Be Responsible For The Loss Of This Form During Transit. -
Page 20: Warranty Card(Service Centre Copy)
Mirc Electronics Ltd. Mirc Electronics Ltd. For Other Details on Our Products & Services Log On To www.onida.com For Other Details on Our Products & Services Log On To www.onida.com Note: Company Will Not Be Responsible For The Loss Of This Form During Transit. - Page 21 LIST OF SERVICE CENTER No.s IN INDIA BUSINESS REPLY ENVELOPE ONIDA CUSTOMER RELATION CENTRE Adonis Electronics Pvt Ltd. Onida House - II Mukund Ground Floor, Mahal Industrial Estate, off. Mahakali Caves Road, Andheri East, Mumbai, Maharashtra, India - 400093...
