  • Page 1 State Capital) - Post / Visit Post the Warranty Registration Card & Service Centre Model: W12TRC3 / W18TRC3 W12TRC2 / W18TRC2 Copy or Visit the Nearest Service Centre. AIR CONDITIONERS The unit displayed is for representational purposes only. Actual unit may vary.
  • Page 2 Dear customer Congratulation on buying ONIDA Air Conditioner. Y our Air Conditioner comes with ONIDA Guarantee of Quality as detailed in the manual. ONIDA takes great pride in providing its customers with state- of-the-art products that adheres to international quality standards.

  • Page 3: Table Of Contents

    CONTENTS Salient Features Inside Air Conditioner Control Panel Remote Overview Operations Safety Precautions Installation Electrical Requirements Take care of your Air Conditioner Precautions to be taken Trouble Shooting Chart Installation and Satisfaction Report Warranty Terms & Conditions Preventive Maintenance Service Coupon Warranty Card(Customer Copy) Warranty Card(Service Center Copy) List of service center no.s in India...

  • Page 4: Salient Features

    SALIENT FEATURES 1.0T / 1.5T Window Air Conditioner Model Code : W12TRC3 / W18TRC3 3 STAR W12TRC2 / W18TRC2 • Aesthetics:- a) Unique Tracy Panel • Performance:- a) 3 Star / 2 Star Energy Saver BEE Rated b) High BTU Compressor...

  • Page 5: Inside Air Conditioner

    INSIDE THE AIR CONTROL PANEL CONDITIONER TIME ON TIME OFF MODE 1. Front panel SET TEMPERATURE( C) AUTO COOL HIGH 2. Air filter TEMP ON/OFF 3. Frame MODE FAN SPEED FEATHER TOUCH: SWING SLEEP TIMER ON TIMER OFF RESET LOCK 1.

  • Page 6: Remote Overview

    REMOTE OVERVIEW OPERATIONS Signal ejecting window Operating Your Air Conditioner: Your Window Air Conditioner can be conveniently operated using the intelligent cordless SET TEMPERATURE( C) remote control. AUTO Switch on the MCB. COOL HIGH Press ON/OFF button on remote handset to switch ON the AC. TEMPERATURE ADJUSTMENT All icons will glow once.

  • Page 7: Operations

    OPERATIONS OPERATIONS Your Window AC operates in one of four modes, AUTO- COOL-FAN-DRY. The modes button The FAN Mode: cyclically chooses between these operating modes. 1. Press "MODE" button to cyclically step through the AUTO, COOL, FAN, & DRY Modes and The AUTO Mode : stop when FAN mode is selected.
  • Page 8 OPERATIONS OPERATIONS COMBINED TIMER: (Setting both ON and OFF timers simultaneously) CANCEL TIMER: If you want to cancel the Timer either TIMER ON or TIMER OFF, press the corresponding TIMER OFF TIMER ON: (On Stop Start Operation) TIMER button and set the time to 0:0. This feature is useful when you want to stop the air conditioner after you go to bed, and start it again in the morning when you wake up or when you return home.

  • Page 9: Safety Precautions

    OPERATIONS SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Vent Control Incorrect operation due to ignoring of instruction will cause harm or damage, the seriousness is classified by the following indications. The Vent control is located above the control knobs.

  • Page 10: Installation

    INSTALLATION SAFETY PRECAUTIONS Select the best location When cleaning the unit , first Do not put a pet or house Do no t us e for special make sure th e power and plant wher e it wil l be purposes.
  • Page 11 INSTALLATION INSTALLATION Installation of the Housing Installation Steps Step 1. Remove the front panel and the air filter Step 1 1. Hold the slot under the front panel, then uplift it outwards, and remove the front panel (See Remove the air conditioner from it’s packaging, remove fixing NOTE: UNIT MAY BE SUPPORTED BY A screws and slide the air conditioner out of it’s housing (Refer to SOLID FRAME FROM BELOW OR...

  • Page 12: Electrical Requirements

    Tonnage of your Voltage Stabilizer Air conditioner Rating Step4. Install the frame. W12TRC3 / W12TRC2 1.0 Ton 3 KVA 1. Install the frame and connect the coupler plugs, making sure not to interfere with the W18TRC3 / W18TRC2 1.5 Ton 4 KVA temperature sensor cable (See Fig.9).

  • Page 13: Take Care Of Your Air Conditioner

    TAKE CARE OF YOUR PRECAUTIONS TO BE TAKEN AIR CONDITIONER Air Filter Do's ( The air filter behind the inlet grill should be checked and cleaned at least once every 2 weeks (or as necessary) to • Seal all air gaps in the room maintain optimal performance of the air conditioner.

  • Page 14: Trouble Shooting Chart

    TROUBLE SHOOTING CHART Symptoms Possible Causes Suggested Remedy Unit does not start MCB has tripped Reset MCB Fuse has burnt Replace fuse wire Input voltage to the If the input voltage to stabilizer is below the stabilizer is below acceptable range the acceptable range, the AC will not operate Press the On/Off key...

  • Page 15: Installation And Satisfaction Report

    INSTALLATION & SATISFACTION REPORT Customer Name : Address Phone[O] Unit Model Unit Serial Number Dealer Name Invoice Number Date of Purchase Date of Installation MCB Rating Current (Amps.) Cable Size Ambient Temp. ( C) Earthing Room Temp. ( C) Stabiliser Grill Temp.

  • Page 16: Warranty Terms & Conditions

    WARRANTY TERMS AND CONDITIONS M/S. MIRC ELECTRONICS LTD, WARRANTS THIS ONIDA AIR CONDITIONER[(except the front grill, knobs, remote unit and add-on plastic parts) TO THE ORIGINAL PURCHASER TO BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP WITHIN ONE YEAR FROM THE DATE OF PURCHASE AS PROVIDED IN THE WARRANTY REGISTERATION CARD.

  • Page 17: Preventive Maintenance Service Coupon

    Preventive Maintenance Service Customer Identification 8. It shall be the absolute discretion of the company to a) effect the repairs or replacement of parts Number: whether at the site of installation or at any service centre, and b) have the job attended to either by the Preventive Maintenance Service 1 Date: ________ Company's service personnel or its authorised dealer...

  • Page 18: Warranty Card(Customer Copy)

    We welcome your Valuable Suggestions, if any, to Improve our Products and Services : FOR OFFICE USE ONLY Customer Code: Branch: Mirc Electronics Ltd. For Other Details on Our Products & Services Log On To www.onida.com Note: Company Will Not Be Responsible For The Loss Of This Form During Transit.

  • Page 19: Warranty Card(Service Center Copy)

    Mirc Electronics Ltd. Mirc Electronics Ltd. For Other Details on Our Products & Services Log On To www.onida.com For Other Details on Our Products & Services Log On To www.onida.com Note: Company Will Not Be Responsible For The Loss Of This Form During Transit.

  • Page 20: List Of Service Center No.s In India

    LIST OF SERVICE CENTER No.S IN INDIA BUSINESS REPLY ENVELOPE ONIDA CUSTOMER RELATION CENTRE Adonis Electronics Pvt Ltd. Onida House - II Mukund Ground Floor, Mahal Industrial Estate, off. Mahakali Caves Road, Andheri East, Mumbai, Maharashtra, India - 400093...

This manual is also suitable for:

W12trc2W18trc3W18trc2
