- Page 1 3 STAR 2 STAR cool Warranty Registration System Help us to serve you better by registering your product for Warranty Model: S12GLS-N4 / S18GLS-N4 - Web Registered at w ww.onida.com - Telephone Call Centre No. 0XX-39889000(0XX-STD Code of State Capital) - Post / Visit Post the Warranty Registration Card &...
- Page 2 Dear customer Congratulation on buying ONIDA Air Conditioner. Y our Air Conditioner comes with ONIDA Guarantee of Quality as detailed in the manual. ONIDA takes great pride in providing its customers with state- of-the-art products that adheres to international quality standards.
-
Page 3: Table Of Contents
CONTENTS CONTENTS Salient Features Inside Overview Glossy Gold New Inside Overview Color Flat Gold Indoor Unit Display Remote Overview Operations General Instructions for Installation Installation Sketch Installation of Model Take care of your Air Conditioner Precautions to be taken Trouble Shooting Installation and Satisfaction Report Warranty Terms &... -
Page 4: Salient Features
SALIENT FEATURES 0.8T / 1.0T / 1.5T Split Air Conditioner Model Code: S12GLS-N4 / S18GLS-N4 / 3 STAR S09CFL-G3 / S12CFL-G3 / S18CFL-G3 • Aesthetics:- a) Unique Glossy Gold New Panel b) Unique Color Flat Gold Panel • Performance:- a) Imported High BTU Compressor... -
Page 5: Inside Overview Glossy Gold New
INSIDE OVERVIEW INSIDE OVERVIEW GLOSSY GOLD NEW COLOR FLAT GOLD INDOOR UNIT INDOOR UNIT INDOOR UNIT INDOOR UNIT Display Return Warm Air In Return Warm Air In Display Front Panel Front Panel cool cool MODE H.SWING V.SWING MODE H.SWING V.SWING TIMER SLEEP TIMER... -
Page 6: Indoor Unit Display
REMOTE OVERVIEW INDOOR UNIT DISPLAY Display on the indoor unit. For the icon of LED windows, only relevant icons will light up with their displays on. GLOSSY GOLD NEW DISPLAY cool HORIZONTAL SWING VERTICAL SWING MODE H.SWING V.SWING SLEEP SIGNAL RECIEVER TEMPERATURE DISPLAY TIMER SLEEP... -
Page 7: Operations
OPERATIONS OPERATIONS Your split AC operates in one of four modes, AUTO- COOL-DRY- . The modes button cyclically chooses between these operating modes. The AUTO Mode : Operating Your Air Conditioner: 1. Press "MODE" button to cyclically step through the AUTO-COOL-DRY-FAN modes and stop Your Split Air Conditioner can be conveniently operated using the intelligent cordless when AUTO mode is selected. - Page 8 OPERATIONS OPERATIONS The FAN Mode: The FAN Mode: 1. Press "MODE" button to cyclically step through the AUTO-COOL-DRY-FAN modes and stop Turbo MODE: Pressing Turbo key on remote, remote will display symbol “ “ and activates the Turbo when FAN mode is selected. function and air conditioner goes to powerful cooling.
-
Page 9: General Instructions For Installation
Locating the indoor and outdoor units SWING Operation: properly will help optimise the performance of your airconditioner. While your Onida / Your split AC has oscillating louvers for uniform cooling around your room. Dealer's Technician will be happy to guide you You can stop the oscillation if you so desire. - Page 10 • Too long Once again, the Onida / dealer's Technician will ensure optimal installation of the ODU for • Too high you. However, the following information will •...
-
Page 11: Installation Sketch
INSTALLATION INSTALLATION SKETCH INDOOR UNIT 1. Fitment of mounting plate The mounting plate should be fitted on the structural part of wall on which indoor unit is to be installed. 2. Drill two holes at a distance of 450 mm between them for the expansion bolts. 150mm or more to ceiling Installation plate Indoor unit outline... - Page 12 INSTALLATION INSTALLATION Discharge the air of the units: n Installation of indoor unit It can used as vaccum pump. Liquid closing valve After putting the pipe assembly through Liquid connecting pipe Cap Remove screw cap of closing valve and the wall, attach the indoor unit to the gas charging hole;...
-
Page 13: Take Care Of Your Air Conditioner
TAKE CARE OF YOUR PRECAUTIONS TO BE TAKEN AIR CONDITIONER Most of the maintenance work on your air Do's ( c o n d i t i o n e r, d u r i n g w a r r a n t y a n d subsequently under the maintenance •... -
Page 14: Trouble Shooting
TROUBLE SHOOTING CHART Symptoms Possible Causes Suggested Remedy Unit does not start MCB has tripped Reset MCB Fuse has burnt Replace fuse wire Input voltage to the If the input voltage to stabiliser is below the stabiliser is below acceptable range the acceptable range, the AC will not operate Press the On/Off key... -
Page 15: Installation And Satisfaction Report
INSTALLATION & SATISFACTION REPORT Customer Name : Address Phone[O] Unit Model Unit Serial Number Dealer Name Invoice Number Date of Purchase Date of Installation MCB Rating Current (Amps.) Cable Size Ambient Temp. ( C) Earthing Room Temp. ( C) Stabiliser Grill Temp. -
Page 16: Warranty Terms & Conditions
WARRANTY TERMS AND CONDITIONS M/S. MIRC ELECTRONICS LTD, WARRANTS THIS ONIDA AIR CONDITIONER[(except the front grill, knobs, remote unit and add-on plastic parts) TO THE ORIGINAL PURCHASER TO BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP WITHIN ONE YEAR FROM THE DATE OF PURCHASE AS PROVIDED IN THE WARRANTY REGISTERATION CARD. -
Page 17: Preventive Maintenance Service Coupon
Preventive Maintenance Service Customer Identification 8. It shall be the absolute discretion of the company to a) effect the repairs or replacement of parts Number: whether at the site of installation or at any service centre, and b) have the job attended to either by the Date: ________ Preventive Maintenance Service 1 Company's service personnel or its authorised dealer... -
Page 18: Warranty Card(Customer Copy)
We welcome your Valuable Suggestions, if any, to Improve our Products and Services : FOR OFFICE USE ONLY Customer Code: Branch: Mirc Electronics Ltd. For Other Details on Our Products & Services Log On To www.onida.com Note: Company Will Not Be Responsible For The Loss Of This Form During Transit. -
Page 19: Warranty Card(Service Centre Copy)
Mirc Electronics Ltd. Mirc Electronics Ltd. For Other Details on Our Products & Services Log On To www.onida.com For Other Details on Our Products & Services Log On To www.onida.com Note: Company Will Not Be Responsible For The Loss Of This Form During Transit. - Page 20 LIST OF SERVICE CENTER No.S IN INDIA BUSINESS REPLY ENVELOPE ONIDA CUSTOMER RELATION CENTRE Adonis Electronics Pvt Ltd. Onida House - II Mukund Ground Floor, Mahal Industrial Estate, off. Mahakali Caves Road, Andheri East, Mumbai, Maharashtra, India - 400093...
