Summary of Contents for Bematech BR200BT

  • Page 1 BR200BT User Manual...

  • Page 3: General Handling Precautions

    ANUAL Important Notice No warranty of any kind is made in regard to this material, including, but not limited to, implied warranties of merchantability or fitness for any particular purpose. We are not liable for any errors contained herein nor for incidental or consequential damages in connection with furnishing, performance or use of this material.

  • Page 4: Laser Safety

    ANUAL Radio and Television Interference Operation of this equipment in a residential area can cause interference to radio or television reception. This can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the following measures: - Reorient the receiving antenna.

  • Page 5: For Ce-Countries

    ANUAL Laser Light Viewing: The scan window is the only aperture through which laser light may be observed from this product. A failure of the scanner engine, while the laser diode continues to emit a laser beam, may cause emission levels to exceed those for safe operation.

  • Page 6: Wireless Communication

    ANUAL Wireless Communication  Wireless technology operates 100M / 75M with communication dongle. Maximum communication range may vary depending on obstacles (person, metal, wall, etc.) or electromagnetic environment.  The following conditions may affect the sensitivity of wireless communication.  There is an obstacle such as a person, metal, or wall between this unit and wireless device.
  • Page 7 ANUAL Bad host placement Good host placement At least 1 m 2. Move the access point (host/dongle) off the floor and away from walls and metal objects (such as metal file cabinets). Metal objects, walls, and floors will interfere with your wireless signals. The closer your access point is to these obstructions, the more severe the interference, and the weaker your connection will be.

  • Page 8: Table Of Contents

    ANUAL Table of Contents Important Notice ........................i General Handling Precautions ................i Guidance for Printing ..........Error! Bookmark not defined. Laser Safety ......................ii For CE-Countries ....................iii Power Supply....................... iii Wireless Communication ..................iv Introduction ......................... 1 Scanner and Accessories ....................2 Charging the Battery ....................
  • Page 9 ANUAL Reset Name ....................22 Setting Name ....................23 Wireless Discovery ..................23 Data Transnit Method ..................24 Normal .......................24 Out of Range ....................24 Batch Mode ....................25 Clearing Batch .................... 25 Batch Transfer ..................... 26 Batch Mode Sounds Settings ..............26 System Function Settings ................... 27 Scan Mode......................28 Radio Communication Setting ................29 Dongle Host mode ..................29...
  • Page 10 ANUAL Industrial 2 of 5 Parameter Setting ............59 UPC/EAN/JAN Parameter Setting ...............60 Telepen Parameter Setting .................65 Matrix 2 of 5 Parameter Setting ..............66 Data Editing ......................70 Identifier Code ................... 70 Header and Trailer ..................72 Full ASCII Code 39 Table ................73 Appendix 1: USB Virtual COM Driver Installation ..........

  • Page 11: Introduction

    Designed for optimal reading performance, the compact BR200BT offers wide scanning range and wireless communication technology for easy handling of any applications. BR200BT includes a 32-bit CPU and excellent scan engine in a small yet powerful unit delivering intuitive and rapid scanning regardless of environment.

  • Page 12: Scanner And Accessories

    ANUAL Scanner and Accessories The scanner package contains: Wireless scanner with battery Dongle Micro USB cable 5V USB Power adapter Quick Guide If any contents are damaged or missing, please contact your dealer immediately. Handy Wireless Scanner...
  • Page 13 ANUAL Battery Installation Installing Batteries Please follow the steps below to install the batteries. Always use the rechargeable batteries provided by the manufacturer to avoid any non-compatible danger or void the warranty. Move the lock for the battery compartment to the unlock position and remove the back cover.

  • Page 14: Charging The Battery

    ANUAL Charging the Battery To charge the battery using the USB cable: There are two method to charge scanner via USB cable.  Host USB Power  Power adaptor Connect the micro USB connector directly to the scanner. Connect the other end of the USB connector to the host to begin charging. You can also connect the USB cable to an outlet using the power adapter to charge the battery.

  • Page 15: Power On The Scanner

    ANUAL Power on the Scanner Ensure the battery is fully charged. Please refer to the previous section to charge the battery. Press and hold the power button for 1 second until a long beep sound is heard to turn on the scanner. To power off the scanner press and hold the function / off button for 3 second until 2 short beeps are heard.

  • Page 16: How To Scan

    ANUAL How to Scan There are two ways to scan with this device.  Handheld scanning  Presentation scanning Handheld scanning Power on the scanner. Press the scan trigger and aim at the barcode. When decoding is successful, the scanner beeps and the LED indicates blue. Presentation Scanning Set the scanner for presentation scanning mode.

  • Page 17: Radio Communication Host Type

    ANUAL Radio Communication Host Type This scanner support three radio communication types:  Dongle mode  SPP master/slave mode  HID mode Dongle Host Mode The scanner communicates with the host through the dongle. One dongle can be used to connect multiple scanners.

  • Page 18: Scanner Usb Online To Host

    ANUAL Scanner USB online to Host The scanner provides other ways for you to connect to the host. When the radio communication is not available, the scanner can be connected to transmit data via USB Online mode. Please see USB Online Mode for detail operation information.

  • Page 19: Dongle Led

    ANUAL Dongle LED Please see the following for the operational indication of the scanner. LED Status Indication Blue flashing Dongle is detected by the host, communication not yet established Steady blue Dongle is connected to the host Blue flash once Data transmission Steady red Dongle is plugged into the host but not...

  • Page 20: Ack/Nak Protocol Or Frame Packing

    ANUAL ACK/NAK Protocol or Frame Packing When scanner is in SPP Master/Slave mode, and add in the data protocol or packing could confirm the data reliability. Refer to below for different setting options: a) No ACK/NAK protocol: data Remote BT BT Scanner device b) ACK/NAK only...

  • Page 21: Scanner To Remote Application

    ANUAL Scanner to Remote Application Data Format of Packet To send a data (barcode) to the remote application, the BT scanner has to encapsulate it: Size of Data Barcode Reserved (Format Data (End of (Header) payload Type Byte Byte) Byte) 1 byte 1 byte 1 byte...

  • Page 22: Barcode Type Table

    ANUAL Barcode Type Table Code Value Code39 0x11 Codabar 0x01 Code128 0x03 Interleaved 2/5 0x02 Code93 0x06 UPC-E 0x14 UPC-A 0x24 EAN-8 0x34 EAN-13 0x44 Chinese Post Code 0x05 0x07 Handy Wireless Scanner...

  • Page 23: Programming Guide

    ANUAL Programming Guide Program Procedure Using Barcode Manual Power up the scanner. Scan the Start of Configuration barcode. Scan the barcode for the desired feature. Multiple features can be enabled/disabled before scanning the End of Configuration barcode. Scan the End of Configuration barcode and save the new configuration. Power off and on the scanner when the setting is done.
  • Page 24 ANUAL Default Parameters The factory default setting table gives the default settings of all the programmable parameters. The default settings will be restored whenever the "Reset" programming label is scanned and the scanner is in programming mode. Default values are highlighted in grey background in the settings.
  • Page 25 ANUAL EAN/UPC Enable CODE 39 Enable Code 32 Disable CODABAR Enable ITF 2 OF 5 Enable Disable Chinese post code Disable Code 93 Enable Code 128 Enable EAN-128 Disable Telepen Disable Code 11 Disable Standard 2 of 5 Disable Industrial 2 of 5 Disable GS1 DataBar Disable...
  • Page 26 ANUAL MSI identifier code Code 11 identifier code Standard 2 of 5 identifier code Industrial 2 of 5 identifier code GS1 DataBar identifier code GS1 DataBar Limited identifier code GS1 DataBar Expanded identifier code Default Data Transmit Format Code Message format EAN-13 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 EAN-8...

  • Page 27: Connecting To A Host

    ANUAL Connecting to a Host The scanner provides several data transmit methods to communicate with the host. User may select the method according to their preferences. Read this section to learn the setups for connecting to different hosts. Start Of Configuration USB Online Mode The scanner connects directly to a USB host to recharge and transmit data.

  • Page 28: Dongle Host Mode

    ANUAL Start Of Configuration Dongle Host Mode The scanner communicates with the host through the dongle. Typically, scanner and dongle in the same delivery box are paired and corresponded to host interface in factory. To check if the scanner is paired to the dongle, check the scanner LED group1 for slow blue flash and check the top dongle LED for steady blue light.

  • Page 29: Wireless Mode

    Next. The scanner should be on the list of discoverable devices. The default name of the scanner is “BR200BT”. Select “BR200BT” and click “Next”. Select “Let me choose my own passkey” and enter the pin code. The default pin code is “12345678.

  • Page 30: Spp Master Mode

    ANUAL Start Of Configuration SPP Master Mode In this mode, the scanner connects to the host /PC via wireless connection and performs like there’s a serial connection. In master mode, the scanner initiates the connection to the remote device. Power on of the remote device and have its address ready in hand and make it discoverable.

  • Page 31: Bt Hid Mode

    ANUAL Start Of Configuration BT HID mode In BT HID mode, the scanner connects to the host /PC via wireless connection and performs like there’s a keyboard connection. The scanner initiates the connection to the remote device. Power on the scanner and program it with “BT HID Mode”. To connect a smart mobile phone (for example, iPhone, Android), the Smart phone mode must also be enabled.

  • Page 32: Setting Pin Code

    To delete pin code, use the “Delete pin code setting”. Delete the stored pin code. Delete pin code Reset Name To change the scanner name back to the default name “BR200BT” use the “Default device name” setting. Change device name back to default “BR200BT”. Default device name...

  • Page 33: Setting Name

    Setting Name To change the name displayed when the scanner is discovered, scan the “Friendly device name set” label. Default name is “BR200BT”. Use the ASCII table in Programming Guide to input the name (Max.12 digits). Scan “Confirm Setting” to store the new name.

  • Page 34: Data Transnit Method

    ANUAL Start Of Configuration Data Transnit Method The data transfer method includes three types: Normal (default), Out-of-Range Mode, and Batch Mode. Users may modify this setting according to their preferences. Normal When the scanner is within the connection range, the scanned data will be transferred to the host computer immediately.

  • Page 35: Batch Mode

    ANUAL Start Of Configuration Batch Mode Whether within the connection range or not, in batch mode, the scanner stores all scanned data that will be transferred to the host computer after scanning “Send Batch Data” label. Number of storable bar codes = 61,365 bytes of memory / (number of characters in the bar code +2) Note: Scanner LED indicator will not flash while waiting for connection in this mode.

  • Page 36: Batch Transfer

    ANUAL Start Of Configuration Batch Transfer Use the settings in this section to setup batch transfer. Scanning this label automatically exits you from the Programming Mode. Press and hold the trigger for over Send Batch Data By 1 second to send the data. Scanning Label Data is ready to be transferred upon USB connection.

  • Page 37: System Function Settings

    ANUAL System Function Settings Default values are highlighted in grey background. Start Of Configuration Barcode Value Description Return scanner to factory defaults Return dongle host to factory defaults Return to USB default (Communication dongle link required) Return as USB-virtual COM port default Return to stand-alone keyboard default Return as OPOS port default Function Button Enable...

  • Page 38: Scan Mode

    ANUAL Start Of Configuration Barcode Value Description Display firmware version Abort (exit programming mode without any updates) Scan Mode Trigger mode The scanner becomes inactive as soon as the data is transmitted. It must be triggered to become active again. Auto scan mode The scanner is still active after the data is transmitted but the successive transmission of the same barcode is not...

  • Page 39: Radio Communication Setting

    ANUAL Start Of Configuration Radio Communication Setting Dongle Host mode Dongle Host mode enable Enable dongle mode with this setup. Unlock pairing mode In this mode, the scanner can pair with another dongle when disconnected. Lock pairing mode. In this mode, the scanner can not pair with another dongle.

  • Page 40: Bt Hid Mode

    ANUAL Start Of Configuration BT HID mode BT HID mode (Combo keyboard) For Apple mode (Must execute BT HID mode first) SPP Master/Slave mode Scanner SPP Master enable SPP Master (Connect wireless address “BxxxxxxxxxxxxT” in CODE39 format) Scanner SPP Slave enable Setting wireless address (SPP Master only) Set PIN code (SPP Master only) BT Setting...
  • Page 41 ANUAL Start Of Configuration Default Device name Friendly device name set Delete pin code Confirm Setting (for address, device name, and pin code setting required) Required Pair with slave (SPP Master) Discover enable Discover disable Encryption enable Encryption disable Data communication without protocol Data communication with ACK/NAK protocol Data communication with Packing protocol End Of Configuration...

  • Page 42: Data Transmit Mode

    ANUAL Start Of Configuration Data Transmit Mode Data transmit normal Out of range buffer enable Batch mode Send Batch Data By Scanning Label Clear batch data after send Clear batch data by scanning “Delete batch data” label Delete batch data Send Batch Data on line USB cable contact.

  • Page 43: Radio Protocol Communication Parameter

    ANUAL Start Of Configuration Radio protocol communication parameter Radio protocol timeout= 3 sec Radio protocol timeout= 5 sec Radio protocol timeout =8 sec Radio protocol timeout= 10 sec Radio protocol timeout =13 sec Radio protocol timeout =16 sec Radio protocol timeout= 20 sec End Of Configuration Handy Wireless Scanner...

  • Page 44: Power Off Timeout Parameter

    ANUAL Start Of Configuration Power off timeout parameter Power off timeout=5 min Power off timeout=10 min Power off timeout=20 min Power off timeout=30 min Power off timeout=1 hr Power Off timeout : 2 hr Power Off timeout : 4 hr Power Off timeout : 6 hr Power Off timeout : 8 hr End Of Configuration...

  • Page 45: Same Code Delay

    ANUAL Start Of Configuration Power Always On Power off by scanning this label Link beeper enable Link beeper disable Power-up beeper enable Power-up beeper disable Same Code Delay 50 msec 100 msec 200 msec 300 msec End Of Configuration Handy Wireless Scanner...
  • Page 46 ANUAL Start Of Configuration 400 msec 500 msec 600 msec 700 msec 800 msec 1000 msec Infinite End Of Configuration Handy Wireless Scanner...

  • Page 47: Operation Function Setting

    ANUAL Start Of Configuration Operation Function Setting Good Read Beeper Tone Selection Medium beeper tone High beeper tone Low beeper tone Speaker disable End Of Configuration Handy Wireless Scanner...

  • Page 48: Beeper Duration Selection

    ANUAL Start Of Configuration Beeper duration Selection Long Medium Short Ultra Short Ultra Long End Of Configuration Handy Wireless Scanner...

  • Page 49: Inter Character Delay

    ANUAL Start Of Configuration Inter Character Delay 0 ms 2 ms 5 ms 10 ms 20 ms 50 ms Inter Message Delay 0 ms 100 ms 500 ms 1000 ms End Of Configuration Handy Wireless Scanner...

  • Page 50: Interface Settings

    ANUAL Start Of Configuration Interface Settings RS-232C Interface Setting Baud Rate 115200 19200 9600 4800 2400 1200 Parity Bit Even parity Odd parity Mark parity Space parity None parity Stop Bit 1 stop bit 2 stop bit Data Bit 7 data bit 8 data bit End Of Configuration Handy Wireless Scanner...
  • Page 51 ANUAL Start Of Configuration Handshaking Protocol None handshaking ACK/NAK Xon/Xoff RTS/CTS Enable BEEPER ON<BEL> CHARACTER Ignore Beep on<BEL> character ACK/NAK response time 300ms ACK/NAK response time 2 sec ACK/NAK response time 500 ms ACK/NAK response time 3 sec ACK/NAK response time 1 sec ACK/NAK response time 5 sec ACK/NAK response time infinity End Of Configuration...
  • Page 52 ANUAL Start Of Configuration Message Terminator RS-232 message terminator—none RS-232 message terminator—CR/LF RS-232 message terminator—CR RS-232 message terminator—LF RS-232 message terminator—H tab RS-232 message terminator—STX/ETX RS-232 message terminator—EOT End Of Configuration Handy Wireless Scanner...

  • Page 53: Keyboard Wedge Setting

    ANUAL Start Of Configuration Keyboard Wedge Setting Keyboard Wedge Setting IBM PC/AT/PS/2 Keyboard emulation International Keyboard mode ( ALT method) Keyboard language support---USA Keyboard language support---UK send scan code Keyboard language support---GERMANY Keyboard language support---FRENCH send scan code Keyboard language support---SPANISH send scan code Keyboard language support---ITALIAN send scan code...
  • Page 54 ANUAL Start Of Configuration Message Terminator Keyboard terminator---none Keyboard terminator---Enter Keyboard terminator---H-TAB End Of Configuration Handy Wireless Scanner...

  • Page 55: Usb Interface Setting

    ANUAL Start Of Configuration USB Interface Setting USB interface International Keyboard mode ( ALT method) Keyboard language support---USA Keyboard language support---GERMANY Keyboard language support---FRENCH send scan code Keyboard language support---SPANISH send scan code Keyboard language support---JAPANESE Keyboard language support---ITALIAN Message Terminator Keyboard terminator---none Keyboard terminator---Enter Keyboard terminator---H-TAB...

  • Page 56: Smart Phone Software Keypad Control Setting

    ANUAL Start Of Configuration Smart Phone Software Keypad Control Setting Smart Phone Software Keypad Control Multi-media keyboard mode This option enables Multi-media keyboard  mode Software keypad show/hide  This option show or hide the Software keypad To show/hide Software keyboard: Scan the Start Of Configuration barcode.

  • Page 57: The Symbologies

    ANUAL Start Of Configuration The Symbologies Codabar Parameter Setting Barcode Barcode Label Description Value RC02 Codabar enable RD02 Codabar disable CB05 Codabar start/stop character transmission－none CB06 Codabar start/stop character transmission－A,B,C,D CB07 Codabar start/stop character transmission－ DC1~DC4 CB08 Codabar start/stop character transmission－ a/t,b/n,c/*,d/e CB09 Codabar maximum length setting...
  • Page 58 ANUAL Start Of Configuration Barcode Barcode Label Description Value CB13 No check character CB14 Validate modulo 16,but don’t transmit CB15 Validate modulo 16 and transmit DC50 Codabar data redundant check=off DC51 Codabar data redundant check=1 DC52 Codabar data redundant check=2 DC53 Codabar data redundant check=3 End Of Configuration...

  • Page 59: Code 39 Parameter Setting

    ANUAL Start Of Configuration Code 39 Parameter Setting Barcode Barcode Label Description Value RC01 Code 39 enable RD01 Code 39 disable RC13 Code 32 enable RD13 Code 32 disable DC00 Code 39 data redundant check=off DC01 Code 39 data redundant check=1 DC02 Code 39 data redundant check=2 DC03...
  • Page 60 ANUAL Start Of Configuration Barcode Barcode Label Description Value 3905 Code 39 check digit calculate and transmit 3906 Code 39 check digit calculate but without transmit 3907 No check character 3908 Code 39 maximum length setting 3909 Code 39 minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) 3912...

  • Page 61: Code 93 Parameter Setting

    ANUAL Start Of Configuration Code 93 Parameter Setting Barcode Barcode Label Description Value RC08 Code 93 enable RD08 Code 93 disable DC30 Code 93 data redundant check=off DC31 Code 93 data redundant check=1 DC32 Code 93 data redundant check=2 DC33 Code 93 data redundant check=3 9301 Code 93 maximum length setting...

  • Page 62: Code 128 Parameter Setting

    ANUAL Start Of Configuration Code 128 Parameter Setting Barcode Barcode Label Description Value RC06 Code 128 enable RD06 Code 128 disable RC10 EAN-128 enable RD10 EAN-128 disable DC40 Code 128 data redundant check=off DC41 Code 128 data redundant check=1 DC42 Code 128 data redundant check=2 DC43 Code 128 data redundant check=3...

  • Page 63: Chinese Post Code Parameter Setting

    ANUAL Start Of Configuration Chinese Post Code Parameter Setting Barcode Barcode Label Description Value RC05 Chinese post code enable RD05 Chinese post code disable DC60 Chinese post code data redundant check=off DC61 Chinese post code data redundant check=1 DC62 Chinese post code data redundant check=2 DC63 Chinese post code data redundant check=3 SZ01...

  • Page 64: Msi/Plessy Parameter Setting

    ANUAL Start Of Configuration MSI/Plessy Parameter Setting Barcode Barcode Label Description Value RC14 MSI enable RD14 MSI disable DC70 MSI data redundant check= off DC71 MSI data redundant check=1 DC72 MSI data redundant check=2 DC73 MSI data redundant check=3 MS01 MSI/Plessy maximum length setting MS02 MSI/Plessy minimum length setting...

  • Page 65: Code 11 Interface Setting

    ANUAL Start Of Configuration Code 11 Interface Setting Barcode Barcode Label Description Value RC07 Code 11 enable RD07 Code 11 disable 1101 Code 11 maximum length setting 1102 Code 11 minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) 1103 Code 11 one check digit verification...

  • Page 66: Itf 2 Of 5 Parameter Setting

    ANUAL Start Of Configuration ITF 2 of 5 Parameter Setting Barcode Barcode Label Description Value RC04 ITF 2 of 5 enable RD04 ITF 2 of 5 disable RC09 IATA code enable RD09 IATA disable DC80 ITF 25 data redundant check=off DC81 ITF25 data redundant check=1 DC82...
  • Page 67 ANUAL Start Of Configuration Barcode Barcode Label Description Value IT01 ITF 2 of 5 code maximum length setting IT02 ITF 2 of 5 code minimum length setting IT06 ITF 2 of 5 one fixed length setting IT07 ITF 2 of 5 two fixed length setting Confirm to save this setting (required for reading full ASCII table and length setting) IT08...

  • Page 68: Standard 2 Of 5 Parameter Setting

    ANUAL Start Of Configuration Standard 2 of 5 Parameter Setting Barcode Barcode Label Description Value RC22 Standard 2 of 5 code enable RD22 Standard 2 of 5 code disable D051 Standard 2 of 5 code maximum length setting D052 Standard 2 of 5 code minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) D053...

  • Page 69: Industrial 2 Of 5 Parameter Setting

    ANUAL Start Of Configuration Industrial 2 of 5 Parameter Setting Barcode Barcode Label Description Value RC21 Industrial 2 of 5 code enable RD21 Industrial 2 of 5 code disable D251 Industrial 2 of 5 code maximum length setting D252 Industrial 2 of 5 code minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) D253...

  • Page 70: Upc/Ean/Jan Parameter Setting

    ANUAL Start Of Configuration UPC/EAN/JAN Parameter Setting Barcode Barcode Label Description Value RC11 EAN convert to ISSN/ISBN enable RD11 EAN convert to ISSN/ISBN disable RC03 UPC/EAN/JAN enable RD03 UPC/EAN/JAN disable UE01 UPC/EAN/JAN all enable UE02 EAN-8 or EAN-13 enable UE03 UPC-A and EAN-13 enable UE04 UPC-A and UPC-E enable...
  • Page 71 ANUAL Start Of Configuration Barcode Barcode Label Description Value UE10 Add on 5 only UE11 Add on 2 only UE12 Add on 2 or 5 UE13 Force UPC-E to UPC-A format enable UE14 Force UPC-E to UPC-A format disable UE15 Force UPC-A to EAN-13 format enable UE16 Force UPC-A to EAN-13 format disable...
  • Page 72 ANUAL Start Of Configuration Barcode Barcode Label Description Value UE23 Transmit EAN-8 check digit enable UE24 Transmit EAN-8 check digit disable UE25 Transmit EAN-13 check digit enable UE26 Transmit EAN-13 check digit disable UE27 Transmit UPC-A leading character enable UE28 Transmit UPC-A leading character disable UE30 Add-on format with separator...
  • Page 73 ANUAL Start Of Configuration Barcode Barcode Label Description Value DC12 UPC-A data redundant check=2 DC13 UPC-A data redundant check=3 DC14 UPC-E data redundant check=off DC15 UPC-E data redundant check=1 DC16 UPC-E data redundant check=2 DC17 UPC-E data redundant check=3 DC20 EAN-13 data redundant check=off DC21 EAN-13 data redundant check=1...
  • Page 74 ANUAL Start Of Configuration UE35 EAN/UPC +add-on mandatory for 978/977 bookland (Supplement requirement, not sent for other) UE38 EAN/UPC +addon mandatory for 978/977 bookland (Supplement requirement, optional for other) UE42 EAN/UPC +addon mandatory for 491 Japanese bookland (Supplement requirement, not sent for other) UE43 EAN/UPC +addon mandatory 491 Japanese bookland (Supplement requirement, optional for other)

  • Page 75: Telepen Parameter Setting

    ANUAL Start Of Configuration Telepen Parameter Setting Barcode Barcode Label Description Value RC25 Telepen enable RD25 Telepen disable TE03 Telepen numeric mode enable TE04 AIM Telepen enable End Of Configuration Handy Wireless Scanner...

  • Page 76: Matrix 2 Of 5 Parameter Setting

    ANUAL Start Of Configuration Matrix 2 of 5 Parameter Setting Barcode Barcode Label Description Value RC12 Matrix 2 of 5 enable RD12 Matrix 2 of 5 disable D151 Matrix 2 of 5 maximum length setting D152 Matrix 2 of 5 minimum length setting Confirm to save this setting (required for reading full ASCII table and length setting) D153...
  • Page 77 ANUAL Start Of Configuration GS1 DataBar Parameter Setting There are 7 kinds of barcodes in the GS1 DataBar family and they are categorized into three groups. Barcode types in the same group use the same barcodes for setting. Group Representative Contents Group 1 GS1 DataBar Omnidirectional...
  • Page 78 ANUAL Start Of Configuration GS1 DataBar Limited (Formally RSS Limited) Barcode Barcode Label Description Value RC16 GS1 DataBar Limited enable RD16 GS1 DataBar Limited disable SS10 Transmit GS1 DataBar Limited check digit SS11 Don’t transmit GS1 DataBar Limited check digit SS12 Transmit GS1 DataBar limited application ID (01) SS13...
  • Page 79 ANUAL Start Of Configuration GS1 DataBar Expanded (Formally RSS Expanded) Barcode Barcode Label Description Value RC17 GS1 DataBar Expanded enable RD17 GS1 DataBar Expanded disable SS07 GS1 DataBar Expanded/EAN-128 emulation enable SS06 GS1 DataBar Expanded/EAN-128 emulation disable SS08 GS1 DataBar Expanded check digital enable SS09 GS1 DataBar Expanded check digital disable SS16...

  • Page 80: Data Editing

    ANUAL Start Of Configuration Data Editing Identifier Code Barcode Barcode Label Description Value IS00 Disable identifier code IS01 Enable identifier code table as factory standard IS03 Enable identifier code table as AIM standard. CI01 Code 39 identifier code setting CI02 ITF 2 of 5 identifier code setting CI03 Chinese Post Code identifier code setting...
  • Page 81 ANUAL Start Of Configuration Barcode Barcode Label Description Value CI08 Codabar identifier code setting CI09 Code 128 identifier code setting CI10 Code 93 identifier code setting CI11 MSI identifier code setting CI12 GS1 DataBar Omnidirectional identifier code setting CI13 GS1 DataBar Limited identifier code setting CI14 GS1 DataBar expanded identifier code setting CI15...

  • Page 82: Header And Trailer

    ANUAL Start Of Configuration Header and Trailer Barcode Barcode Label Description Value CP11 Add code length as header enable (2 digits) Add code length as header disable (2 digits) CP12 Header (Preamble) HT01 Trailer (Postamble) HT02 Truncate header character HT03 Truncate trailer character HT04 Confirm to save this setting (required for reading full...

  • Page 83: Full Ascii Code 39 Table

    ANUAL Start Of Configuration Full ASCII Code 39 Table Hexa Hexa- Code 39 ASCII Code 39 ASCII code code Full ASCII ---NUL Full ASCII ---SI Function key-----“Shift” Full ASCII ---SOH Full ASCII ---DLE Function key-----“Ins” Function key----- “5(num)” Full ASCII ---STX Full ASCII ---DC1 Function key-----“Del”...
  • Page 84 ANUAL Start Of Configuration Full ASCII Code 39 Table (continued) Hexa- Hexa- Code 39 ASCII Code 39 ASCII code code Full ASCII ---RS Full ASCII ---- Function key-----“CTL(L)” Full ASCII ---US Full ASCII ---. Function key-----“ALT(L)” Full ASCII ---SP Full ASCII ---/ Full ASCII ---! Full ASCII ---0 Full ASCII ---“...
  • Page 85 ANUAL Start Of Configuration Full ASCII Code 39 Table (continued) Hexa- Hexa- Code 39 ASCII Code 39 ASCII code code Full ASCII ---< Full ASCII ---K Full ASCII ---= Full ASCII ---L Full ASCII ---> Full ASCII ---M Full ASCII ---? Full ASCII ---N Full ASCII ---@ Full ASCII ---O...
  • Page 86 ANUAL Start Of Configuration Full ASCII Code 39 Table (continued) Hexa- Hexa- Code 39 ASCII Code 39 ASCII code code Full ASCII ---Z Full ASCII ---i Full ASCII ---[ Full ASCII ---j Full ASCII ---\ Full ASCII ---k Full ASCII ---] Full ASCII ---l Full ASCII ---^ Full ASCII ---m...
  • Page 87 ANUAL Start Of Configuration Full ASCII Code 39 Table (continued) Hexa- Hexa- Code 39 ASCII Code 39 ASCII code code Full ASCII ---x Full ASCII ---| Full ASCII ---y Full ASCII ---} Full ASCII ---z Full ASCII ---~ Full ASCII ---{ Full ASCII ---DEL End Of Configuration Handy Wireless Scanner...

  • Page 88: Appendix 1: Usb Virtual Com Driver Installation

    ANUAL Appendix 1: USB Virtual COM Driver Installation Contact your distributor to get the driver and follow the steps below to enable USB virtual COM port. Connect the handheld scanner and the host (e.g. a PC) with a USB interface cable. Enable USB virtual COM port with programming barcode on page 32.

  • Page 89: Appendix 2: Barcode Length Setting

    ANUAL Appendix 2: Barcode Length Setting Introduction The length of a barcode is the number of characters it contains, including check digits. As listed in the Default Parameters section, each barcode type has different default length. You may change the setting by the following procedure. To set up barcode length, the paramours to be determined are barcode type and the desired barcode length.
