ZyXEL Communications P-630-S Quick Start Manual

ZyXEL Communications P-630-S Quick Start Manual

Zyxel p-630-s adsl usb modem
Hide thumbs Also See for P-630-S:

Advertisement

Quick Links

Download this manual See also: User Manual
P-630-S
ADSL USB Modem

Quick Start Guide

Version 1.0
6/2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the P-630-S and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications P-630-S

Summary of Contents for ZyXEL Communications P-630-S

  • Page 1: Quick Start Guide

    P-630-S ADSL USB Modem Quick Start Guide Version 1.0 6/2006...

  • Page 2: Installing The Usb Driver

    P-630-S Series Quick Start Guide Overview The P-630-S allows you to have high-speed ADSL Internet access from a computer via a USB connection. See the User’s Guide for more information on all features. 1 Installing the USB Driver System Requirements: •...
  • Page 3 P-630-S Series Quick Start Guide 1.1 Windows Screen shots for Windows XP are shown in the following procedure. Note: You must start the driver setup wizard before connecting the P- 630-S to your computer. 1 Close all Windows programs and applications.
  • Page 4 P-630-S Series Quick Start Guide 3 Wait until you are prompted to connect your P-630-S's USB cable to the computer. Connect the USB cable to a USB port on your computer. 4 When the installation is complete, you will see this window. Click OK to...
  • Page 5 P-630-S Series Quick Start Guide 5 Connect the P-630-S’s DSL port to a telephone jack using the included telephone wire. The USB LED turns on when you have a successful USB connection. The DSL LED blinks during DSL line initialization and turns steady green when the P-630-S has a DSL connection.
  • Page 6 P-630-S Series Quick Start Guide Mac OS 9 Screens for Mac OS 9.2 are shown in this section. 1 Close all programs and applications. 2 Insert the included CD into the CD-ROM drive. An icon for the CD appears. Double-click the CD's icon.
  • Page 7 P-630-S Series Quick Start Guide 4 Double-click the .sit file. 5 The file ADSLModem.smi will be created. Double- click ADSLModem.smi.
  • Page 8 P-630-S Series Quick Start Guide 6 The ADSLModem icon will display on the desktop. Double-click ADSLModem. 7 Double-click Driver. 8 Double-click Installation of ADSL Modem to install the driver.
  • Page 9 P-630-S Series Quick Start Guide 9 Click Switch Disk to select a destination (this must be on an actual physical hard drive on the Macintosh, not a virtual drive) and click Install. 10Click Restart to reboot your computer and complete the driver installation.
  • Page 10 P-630-S Series Quick Start Guide Mac OS X Screens for Mac OS 10.3 are shown in this section. The screens may varies slightly for Mac OS 10.4. 1 Close all programs and applications. 2 Insert the included CD into the CD-ROM drive. An icon for the CD appears.
  • Page 11 P-630-S Series Quick Start Guide 4 Double-click the .hqx file. 5 The file ADSLModem.pk g will be created. Double-click ADSLModem.pk g to install the driver.
  • Page 12 P-630-S Series Quick Start Guide 6 A welcome screen appears. Click Continue. 7 Click Continue.
  • Page 13 P-630-S Series Quick Start Guide 8 A screen displays asking you to agree to the license agreement. Click Agree. 9 You will then see the Select a Destination screen, select a destination (this must be on an actual physical hard drive on the Macintosh, not a virtual drive) and click Continue.
  • Page 14 P-630-S Series Quick Start Guide 10Click Upgrade. 11You then see a screen telling you that you must restart the computer after the installation completes. Click Continue Installation. The driver will automatically install.
  • Page 15 P-630-S Series Quick Start Guide 12Click Restart to reboot your computer and complete the driver installation. 13Connect the USB cable to a USB port on your computer. Connect the P- 630-S’s DSL port to a telephone jack using the included telephone wire.

  • Page 16: Accessing The Internet

    P-630-S Series Quick Start Guide 2 Accessing the Internet You will need your Internet access information such as user name and password if given by your ISP. CONNECTION METHOD YOU ACTION INFORMATION ARE USING None Bridge encapsulation with a Open your browser dynamic IP address and surf the web.
  • Page 17 P-630-S Series Quick Start Guide Note: If your ISP gave you an IP address, see also Section 2.2 on page 26 on how to configure a static IP address on your computer. 2.1.1 Windows 1 After you install the driver and...
  • Page 18 P-630-S Series Quick Start Guide 3 The dial-up icon appears on your desktop. 4 Double-click the icon to configure your user name and password for Internet access. Enter the user name and password that your ISP gave you and click Dial.
  • Page 19 P-630-S Series Quick Start Guide 1 Click the Apple icon, Control Panels and ADSL Modem to start the configuration wizard. 2 Click the Config tab, select a profile and click Save.
  • Page 20 P-630-S Series Quick Start Guide 3 Click the Apple icon, Control Panels and TCP/IP. 4 In the TCP/IP screen, select PPP in the Connect via field. Select Using PPP Server in the Configure field or select Manually and enter the IP address given by your ISP.
  • Page 21 P-630-S Series Quick Start Guide 6 Select PPPoA ADSL modem or PPPoE ADSL modem in the Connect via field and ADSL Modem Script in the Modem field. Click the close button at the top left corner and click Save. 7 Click the Apple icon, Control Panels and Remote Access.
  • Page 22 P-630-S Series Quick Start Guide Mac OS X 1 Click Finder, Applications and ADSL Modem. 2 Double-click ADSL Modem to start the configuration wizard.
  • Page 23 P-630-S Series Quick Start Guide 3 Click the Config tab, select a PPPoE or PPPoA profile and click Save. 4 Click the Apple icon and System Preferences.
  • Page 24 P-630-S Series Quick Start Guide 5 Double-click Network. 6 A New Port Detected screen opens when the computer detects that the ADSL link is up. Click OK.
  • Page 25 P-630-S Series Quick Start Guide 7 In the Network screen, select Ethernet Adaptor (en x) in the Show field. Click the PPPoE tab and select the Connect using PPPoE check box. Type the information from your ISP in the Service...
  • Page 26 P-630-S Series Quick Start Guide 2.2 Setting up Your Computer’s IP Address Note: This section shows you how to configure an IP address on your computer. You only need to do this if you were given an IP address by your ISP.
  • Page 27 P-630-S Series Quick Start Guide 2 Right-click on the icon that corresponds to your new USB connection (not the one that corresponds to your network card) and select Properties.
  • Page 28 P-630-S Series Quick Start Guide 3 In the Properties screen, make sure the Connect using field displays "LAN/ATM/ ADSL miniport". Select Internet Protocol (TCP/IP) and click Properties. 4 Click Use the following IP Address and fill in the IP address, Subnet mask and Default gateway (given by your ISP) fields.
  • Page 29 P-630-S Series Quick Start Guide 2.2.2 Mac Mac OS 9 1 Click the Apple icon, Control Panels and TCP/IP. 2 In the TCP/IP screen, select PPP, Routed ADSL Modem or Bridged ADSL Modem in the Connect via field and Manually in the Configure field.

  • Page 30: Troubleshooting

    P-630-S Series Quick Start Guide Mac OS X 1 Click the Apple icon, System Preferences and Network to open the Network screen. 2 Select Ethernet Adaptor (en x) that corresponds to your new USB connection in the Show field. Click...
  • Page 31 CORRECTIVE ACTION None of the Make sure your computer is turned on. LEDs turn Check the USB cable connections between the P-630-S and your computer. Check the USB cable (see if the USB cable works with a different USB device).
  • Page 32 P-630-S Series Quick Start Guide PROBLEM CORRECTIVE ACTION Windows Make sure the P-630-S is turned on and connected to the USB does not port on the computer. auto-detect Perform a hardware scan by clicking Start, Settings, Control the USB Panel and double-clicking Add/Remove Hardware. (Steps connection to may vary depending on the version of Windows).
