Page 1: Quick Start Guide
P-630-S Series ADSL USB Modem Quick Start Guide Version 1.0 7/2005... -
Page 2: Installing The Usb Driver
Overview The Prestige 630-S (P-630-S) allows you to have high-speed ADSL Internet access from a computer via a USB connection. See the User’s Guide for more information on all features. 1 Installing the USB Driver System Requirements: • Windows 98 SE (Second Edition), Windows Me (Millennium Edition), Windows 2000 or Windows XP Macintosh operating system versions 9.1 or later... - Page 3 Connect the USB cable to a USB port on your computer. 4 When the installation is completed, you will see this window. Click OK to close the wizard. 5 Connect the Prestige’s DSL port to a telephone jack using the included telephone wire. P-630-S Series Quick Start Guide...
- Page 4 Screens for Mac OS 9.2 are shown in this section. 1 Close all programs and applications. 2 Insert the included CD into the CD-ROM drive. An icon for the CD appears. Double- click the CD's icon. 3 Double-click the Mac 9 driver folder. P-630-S Series Quick Start Guide...
- Page 5 .sit file and click Choose. 6 The file ADSLModem 2.0.20.smi will be created in the folder you selected. Double-click ADSLModem 2.0.20.smi. 7 The ADSLModem 20.2 icon will display on the desktop. Double-click ADSLModem 20.2. P-630-S Series Quick Start Guide...
- Page 6 9 Double-click Installation of ADSL Modem to install the driver. 10Click Switch Disk to select a destination (this must be on an actual physical hard drive on the Macintosh, not a virtual drive) and click Install. P-630-S Series Quick Start Guide...
- Page 7 Screens for Mac OS 10.3 are shown in this section. 1 Close all programs and applications. 2 Insert the included CD into the CD-ROM drive. An icon for the CD appears. Double-click the CD's icon. 3 Double-click the Mac X driver folder. P-630-S Series Quick Start Guide...
- Page 8 .sit file and click Choose. 6 The file ADSLModem.pk g will be created in the folder you selected. Double-click ADSLModem.pk g to install the driver. P-630-S Series Quick Start Guide...
- Page 9 7 A welcome screen appears. Click Continue. 8 Click Continue. 9 A screen displays asking you to agree to the agreement. Click Agree. P-630-S Series Quick Start Guide...
- Page 10 Macintosh, not a virtual drive) and click Continue. 11Click Upgrade. 12You then see a screen telling you that you must restart the computer after the installation completes. Click Continue Installation. The driver will automatically install. P-630-S Series Quick Start Guide...
-
Page 11: Accessing The Internet
Internet connection like a traditional modem. Note: If your ISP gave you an IP address, see also on how to configure a static IP address on your computer. P-630-S Series Quick Start Guide ACTION Open your browser and surf the web. - Page 12 3 The dial-up icon appears on your desktop. 4 Double-click the icon to configure your user name and password for Internet access. Enter the user name and password that your ISP gave you and click Dial. P-630-S Series Quick Start Guide...
- Page 13 1 Click the Apple icon, Control Panels and ADSL Modem to start the configuration wizard. 2 Click the Config tab, select a profile and click Save. 3 Click the Apple icon, Control Panels and TCP/IP. P-630-S Series Quick Start Guide...
- Page 14 PPPoE ADSL modem in the Connect via field and ADSL Modem Script in the Modem field. Click the close button at the top left corner and click Save. 7 Click the Apple icon, Control Panels and Remote Access. P-630-S Series Quick Start Guide...
- Page 15 ISP gave you, enter any number in the Number field and click Connect. Mac OS X 1 Click Finder, Applications and ADSL Modem. 2 Double-click ADSL Modem to start the configuration wizard. P-630-S Series Quick Start Guide...
- Page 16 PPPoE or PPPoA profile and click Save. 4 Click the Apple icon and System Preferences. 5 Double-click Network. 6 A New Port Detected screen opens when the computer detects that the ADSL link is up. Click OK. P-630-S Series Quick Start Guide...
-
Page 17: Setting Up Your Computer's Ip Address
IP address by your ISP. 2.2.1 Windows Screens for Windows XP are shown in this guide unless otherwise specified. Steps and screen shots may vary depending on the version of Windows. 1 Click Start, Control Panel and Network Connections. P-630-S Series Quick Start Guide... - Page 18 2 Right-click on the icon that corresponds to your new USB connection (not the one that corresponds to your network card) and select Properties. 3 In the Properties screen, make sure the Connect using field displays "LAN/ATM/ADSL miniport". Select Internet Protocol (TCP/IP) and click Properties. P-630-S Series Quick Start Guide...
- Page 19 Connect via field and Manually in the Configure field. Fill in the IP address, Subnet mask and Router address (given by your ISP) fields. Click the close button at the top left corner and click Save. P-630-S Series Quick Start Guide...
-
Page 20: Troubleshooting
Carefully follow the instructions to uninstall and reinstall the driver. See your User’s Guide on how to uninstall the driver. If the error persists, you may have a hardware problem. In this case, you should contact your local vendor. P-630-S Series Quick Start Guide... - Page 21 1 Go to www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. P-630-S Series Quick Start Guide...
