(separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the Setup Manual for basic information ranging from connection of the monitor to a PC to using the monitor. • The latest User’s Manual is available for download from our web site: http://www.eizo.com...
Page 2
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
Notice for this monitor GX240: This product is intended to be used in displaying and viewing digital images by trained medical practitioners. It does not support the display of mammography images for diagnosis. GX340: This product is intended to be used in displaying and viewing digital images for diagnosis of X-ray or MRI, etc.
Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. Note •...
Chapter 1 Introduction Thank you very much for choosing an EIZO monochrome LCD monitor. 1-1. Features • 21.3 inches • Applicable to the resolution of 2M pixels (Portrait : 1200 × 1600 dots (H × V))(GX240-CL) • Applicable to the resolution of 3M pixels (Portrait : 1536 × 2048 dots (H × V))(GX340-CL) •...
Avoid storing or using the sensor where it may be exposed to direct sunlight. 1-2. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ●...
1-3. Basic Operations and Functions ● Basic Adjustment menu operations Displaying Adjustment Menu 1. Press . The Adjustment menu appears. Menutitle Currentmode Item Setting Menu Adjusting/Setting 1. Choose a menu to adjust/set with , , and then press 2. Choose an item to adjust/set with , , and then press 3.
Chapter 2 Adjusting Screens 2-1. Compatible Resolutions For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual. 2-2. Setting the Resolution ● Windows 8 / Windows 7 1. For Windows 8, click the “Desktop” tile on the Start Screen to display the desktop. 2.
● To adjust brightness The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Setting Range 0 to 100% Procedure 1. Choose “Mode” from the Adjustment menu, and press 2. Choose “Brightness” from “Mode”, and press 3.
● To set the mode in the base display area The mode suitable for the base display area can be set. Setting Range Base-L, Base-H Procedure 1. Choose “Mode” from the Adjustment menu, and press 2. Choose “Base Area” from “Mode”, and press 3.
Chapter 3 Setting Monitor 3-1. Setting Orientation This function changes the display orientation of the image based on the operating environment. Attention • Refer to the User’s Manual of the graphics board. • Setting is available even when the PC is not started up. Procedure 1.
3. Choose the position with or . 4. Press to exit. 3-5. Setting the EIZO Logo Display This function allows you to display, or not, the EIZO logo. Procedure 1. Press to turn off the monitor. 2. Holding down, press for at least two seconds to turn on the monitor.
3-6. Locking Buttons This function allows you to lock the adjusted/set status to prevent changing them. Procedure 1. Press to turn off the monitor. 2. Holding down, press for at least two seconds to turn on the monitor. The “Optional Settings” menu appears. 3.
3-9. Return To Default Setting There are two different Resets: Mode Reset for only resetting the mode adjustments to the default settings and All Reset for resetting all settings to the defaults. Attention • After resetting, you cannot undo the operation. Note •...
Chapter 4 Controlling Monitor Quality This product has the built-in Integrated Front Sensor, which allows the user to perform periodic calibration and Grayscale Check for the monitor independently. Attention • When a panel protector (RP-903) is installed, the Integrated Front Sensor cannot be used. Do not execute “SelfCalibration” or “Grayscale Check”...
4-2. Checking Grayscale This function allows you to execute Grayscale Check and view the latest result. In addition, when the schedule is set using RadiCS, the next grayscale check schedule appears. ● Executing Grayscale Check Attention • Do not execute this function when a panel protector (RP-903) is installed. •...
4-4. Setting On/Off for Warning and QC History This function allows you to set On/Off for Warning and QC History when the Grayscale Check result is Failed. Procedure 1. Choose “RadiCS SelfQC” from the Adjustment menu, and press 2. Choose “Settings” from the “RadiCS SelfQC” menu, and press 3.
Chapter 5 Power Saving Functions 5-1. Setting Power Save This function allows you to set the monitor into the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. Attention •...
5-3. Setting the power saving mode when a person leaves the monitor The sensor on the front side of the monitor detects the movement of a person by setting a value from “Level-1” to “Level-4” of the Presence Sensor function. When a person moves away from the monitor, it shifts to the power saving mode automatically and does not display the images on the screen to reduce the power consumption.
Chapter 6 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. 6-1. No picture Problem Possible cause and remedy 1. No picture • Checkwhetherthepowercordisconnectedproperly. • Powerindicatordoesnotlight. • Turnthemainpowerswitchon. • Press . • Turnoffthemainpower,andthenturnitonagainafew minuteslater. •...
6-2. Imaging problems Problem Possible cause and remedy 1. The screen is too bright or too dark. • Use“Brightness”intheAdjustmentmenutoadjustit.(The LCDmonitorbacklighthasalimitedlifespan.Whenthe screenbecomesdarkorbeginstoflicker,contactyour localdealer.) 2. Characters are blurred. • CheckwhetherthePCisconfiguredtomeettheresolution andverticalscanfrequencyrequirementsofthemonitor (see“CompatibleResolutions”intheSetupManual.). 3. Afterimages appear. • AfterimagesareparticulartoLCDmonitors.Avoid displayingthesameimageforalongtime. • Usethescreensaverorpowersavingfunctiontoavoid displayingthesameimageforextendedperiodsoftime. 4. Interference patterns or pressure marks •...
6-3. Other problems Problem Possible cause and remedy 1. The adjustment menu does not appear. • Checkwhethertheoperationlockfunctionworks(see“3-6. LockingButtons”(page16)). 2. No mode menu is displayed. • Checkwhethertheoperationlockfunctionworks(see“3-6. LockingButtons”(page16)). 3. (When using Presence Sensor) • Checkthesettingenvironmentofthemonitor.Presence The images remain to be displayed when Sensormaynotworkcorrectlyinthefollowing...
An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). http://www.eizo.com Attention • When attaching an arm or stand, follow the instructions of their User’s Manual.
7-2. Connecting Multiple PCs The product has multiple connections to PCs and allows you to switch to one of the connections for display. Connection examples DVI-Dconnector DisplayPortconnector Digital Digital (DVI) (DisplayPort) Signalcable Signalcable DD300DL:GX340-CL PP300 DD300:GX240-CL (supplied) (supplied) DVIconnector DisplayPortconnector ToPC1 ToPC2 ●...
● To set input signal selection Settings Function Auto ThemonitorrecognizestheconnectorthroughwhichPCsignalsareinput. WhenaPCisturnedofforentersthepowersavingmode,themonitorautomatically displaysanothersignal. Manual ThemonitordetectsonlythePC’ssignalscurrentlydisplayingautomatically.Selectan activeinputsignalwith“Input”. Procedure 1. Choose “Tools” from the Adjustment menu, and press 2. Choose “Input Selection” from “Tools”, and press 3. Select “Auto” or “Manual” with or . 4.
7-3. Making Use of USB (Universal Serial Bus) This monitor has a hub compatible with USB. Connected to a PC compatible with USB or another USB hub, this monitor functions as a USB hub allowing connection to peripheral USB devices. ●...
7-4. Displaying Monitor Information ● Displaying signal information This function displays the information about the current input signals displayed. Procedure 1. Choose “Tools” from the Adjustment menu, and press 2. Choose “Signal Info” from “Tools”, and press The “Signal Info” appears. (Example) ●...
PIVOT 211 (8.3) 18.5 (0.73) 209 (8.2) 245.5 (9.7) HIGHEST POSITION Accessories CalibrationKit EIZO“RadiCSUX1”Ver.4.0.1orlater EIZO“RadiCSVersionUpKit”Ver.4.0.1orlater NetworkQCManagementSoftware EIZO“RadiNETPro”Ver.4.0.1orlater CleaningKit EIZO“ScreenCleaner” For the latest information about the accessories and information about the latest compatible graphics board, refer to our web site. http://www.eizo.com...
7-6. Glossary DDC (Display Data Channel) VESA provides the standardization for the interactive communication of the setting information, etc. between a PC and the monitor. DICOM (Digital Imaging and Communication in Medicine) The DICOM standard was developed by the American College of Radiology and the National Electrical Manufacturer’s Association of the USA.
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiForce, RadiCS, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EIZO EasyPIX, EcoView NET, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation.
Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided.
EMC Information Essential performance of RadiForce series is to display images and operate functions normally. CAUTION The RadiForce series requires special precautions regarding EMC and need to be installed, put into service and used according to the following information. Do not use any cables other than the cables that provided or specifi ed by us. Using other cables may cause the increase of emission or decrease of immunity.
Page 42
Recommended separation distances between portable and mobile RF communications equipment and the RadiForce Series TheRadiForceseriesisintendedforuseinanelectromagneticenvironmentinwhichradiatedRFdisturbances arecontrolled.ThecustomerortheuseroftheRadiForceseriescanhelppreventelectromagneticinterferenceby maintainingaminimumdistancebetweenportableandmobileRFcommunicationsequipment(transmitters)andthe RadiForceseriesasrecommendedbelow,accordingtothemaximumoutputpowerofthecommunicationsequipment. Ratedmaximumoutput Separationdistanceaccordingtofrequencyoftransmitter poweroftransmitter 150kHzto80MHz 80MHzto800MHz 800MHzto2.5GHz d=1.2 d=1.2 d=2.3 0.01 0.12 0.12 0.23 0.38 0.38 0.73 For transmitters rated at a maximum output power not listed above, the recommended separation distance “d” in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where “P”...
