Eizo Radiforce GX550 Instructions For Use Manual

Monochrome lcd monitor
Hide thumbs Also See for Radiforce GX550:
Table of Contents

Advertisement

Quick Links

Download this manual
Instructions for Use
Monochrome LCD Monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For monitor adjustment and settings, refer to the "Installation
Manual".
• For the latest product information including the "Instructions for
Use", refer to our web site :
http://www.eizoglobal.com

Advertisement

Table of Contents
loading

Related Manuals for Eizo Radiforce GX550

Summary of Contents for Eizo Radiforce GX550

  • Page 1 Instructions for Use Monochrome LCD Monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For monitor adjustment and settings, refer to the “Installation Manual”.
  • Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Precautions

    PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor.
  • Page 4 A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
  • Page 5 If the unit falls, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
  • Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the power cord or cables attached is dangerous and may result in injury. Carry or place the unit according to the correct specified methods. •...

  • Page 7: Notice For This Monitor

    Notice for this monitor Intended use This product is intended to be used in displaying and viewing digital images, including standard and multi-frame digital mammography, for review, analysis and diagnosis by trained medical practitioners. It is specially designed for breast tomosynthesis applications. Caution: Federal law (USA) restricts this device to sale by or on the order of a physician.
  • Page 8 • The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The screen may have defective pixels or a small number of light dots on the screen. This is due to the characteristics of the panel itself, and is not a malfunction of the product.

  • Page 9: Table Of Contents

    Notice for this monitor ......... 7 CONTENTS ............. 9 Chapter 1 Introduction ........10 1-1. Features ............10 1-2. Package Contents ........11 1-3. EIZO LCD Utility Disk........11 ● Disk contents and software overview ....11 ● Using RadiCS LE ...........11 1-4. Controls and Functions ......12 1-5.

  • Page 10: Chapter 1 Introduction

    • The daisy-chain function is included enabling multiple monitors to be connected with the DisplayPort cable. A graphic board supporting DisplayPort1.2 is required. For details, refer to the EIZO website. http://www.eizoglobal.com • The CAL Switch function allows the user to select the display mode optimum to the displayed image.

  • Page 11: Package Contents

    • Digital signal cable : DD300DL DVI - DVI (Dual Link) 1-3. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ●...

  • Page 12: Controls And Functions

    1-4. Controls and Functions Approx. 30˚ Adjustment menu*1 1. Integrated Front Sensor Detects the movement of a person in front of the monitor. (Mobile) 2. Ambient Light Sensor Measures the environmental illumination. 3. Presence Sensor Detects the movement of a person in front of the monitor. 4.

  • Page 13: Compatible Resolutions

    1-5. Compatible Resolutions The monitor supports the following resolutions. √ : Supported DisplayPort vertical scan Resolution frequency Portrait Landscape Portrait Landscape Portrait 720×400 70 Hz √ √ √ √ √ 640×480 60 Hz √ √ √ √ √ 800×600 60 Hz √...

  • Page 14: Chapter 2 Connection

    Chapter 2 Connection 2-1. Connecting Cables Attention • Check that the monitor and the PC are powered off. • When replacing the current monitor with this monitor, refer to “1-5. Compatible Resolutions” (page 13) to change the PC settings for resolution and vertical scan frequency to those that are available for this monitor, before connecting the PC.
  • Page 15 Signal cable : DD300DL Signal cable : PP300 Daisy-chaining multiple monitors Attention • Visit the EIZO website for information about monitors and graphic boards that can be used for the daisy-chain connection: http://www.eizoglobal.com • Remove the cap before connecting the signal cable.

  • Page 16: Making Use Of Usb (Universal Serial Bus)

    Plug the power cord into a power outlet and the power connector on the monitor. Connect the USB cable when using RadiCS LE. For information about the connection to the USB upstream port, refer to “2-2. Making Use of USB (Universal Serial Bus)”...

  • Page 17: Connection Procedure (Setup Of Usb Function)

    ● Connection procedure (Setup of USB function) Procedure 1. Connect the monitor first to a PC using the signal cable, and run the PC. 2. Connect the supplied USB cable between the USB downstream port of a USB compatible PC (or another USB hub) and the monitor’s USB upstream port.

  • Page 18: Chapter 3 Setting Up

    Chapter 3 Setting Up 3-1. Adjusting the Screen Height and Angle Hold left and right edge of the monitor with both hands, and adjust the screen height, tilt and swivel of the screen to the best condition for working. Attention •...

  • Page 19: Attaching Arm

    3-2. Attaching Arm An optional arm (or an optional stand) can be attached by removing the stand section. For supported optional arms (or optional stands), refer to the EIZO website: http://www.eizoglobal.com Attention • When attaching an arm or stand, follow the instructions of their User’s Manual.

  • Page 20: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light.

  • Page 21: Chapter 5 Specifications

    Chapter 5 Specifications 5-1. Specifications List LCD Panel Type Backlight Size 54.1 cm (21.3 inch) Resolution 5M pixels (Portrait orientation: 2048 dots × 2560 lines (H × V)) Display Size (H x V) 337.9 mm × 422.4 mm (Portrait orientation) Pixel Pitch 0.165 mm Display Tones...

  • Page 22: Main Default Settings

    Operating Temperature: 0˚C to 35˚C (32˚F to 95˚F) Environmental Humidity 20% to 80% R.H. (no condensation) Requirements Air pressure 540 hPa to 1060 hPa Transportation/ Temperature -20˚C to 60˚C (32˚F to 95˚F) Storage Humidity 10% to 90% R.H. (no condensation) Environmental Air pressure 200 hPa to 1060 hPa...

  • Page 23: Dimensions

    32.5 5-4. Accessories Calibration Kit EIZO “RadiCS UX1” Ver. 4.4.2 or later EIZO “RadiCS Version Up Kit” Ver. 4.4.2 or later Network QC Management Software EIZO “RadiNET Pro” Ver. 4.4.2 or later EIZO “RadiNET Pro Lite” Ver. 4.4.2 or later Cleaning Kit EIZO “ScreenCleaner”...

  • Page 24: Chapter 6 Glossary

    Chapter 6 Glossary Daisy-chain connection A method of connecting two or more monitors to a PC in a daisy-chain. DDC (Display Data Channel) VESA provides the standardization for the interactive communication of the setting information, etc. between a PC and the monitor. DICOM (Digital Imaging and Communication in Medicine) The DICOM standard was developed by the American College of Radiology and the National Electrical Manufacturer’s Association of the USA.

  • Page 25: Appendix

    ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO Monitor Configurator, EIZO ScreenSlicer, G-Ignition, i • Sound, Re/Vue, Screen Administrator and UniColor Pro are trademarks of EIZO Corporation. All other company and product names are trademarks or registered trademarks of their respective owners.

  • Page 26: License / Copyright

    License / Copyright A round gothic bold bit map font designed by Ricoh is used for the characters displayed on this product. Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor.

  • Page 27: Fcc Declaration Of Conformity

    Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...

  • Page 28: Emc Information

    EMC Information Essential performance of RadiForce series is to display images and operate functions normally. CAUTION The RadiForce series requires special precautions regarding EMC and need to be installed, put into service and used according to the following information. Do not use any cables other than the cables that provided or specified by us. Using other cables may cause the increase of emission or decrease of immunity.
  • Page 29 Guidance and manufacturer’s declaration - electromagnetic immunity The RadiForce series is intended for use in the electromagnetic environment specified below. The customer or the user of the RadiForce series should assure that it is used in such an environment. Immunity test IEC/EN60601 test Compliance level Electromagnetic environment - guidance level...
  • Page 30 Recommended separation distances between portable and mobile RF communications equipment and the RadiForce Series The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the RadiForce series can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series as recommended below, according to the maximum output power of the communications equipment.

  • Page 31: Recycling Information/Informationen Zum Thema Recycling/Informations Sur Le Recyclage/Информация Относно Рециклиране

    Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una fi lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizoglobal.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale.
  • Page 32 Ten produkt po zużyciu powinien być zbierany i przetwarzany zgodnie z krajowymi przepisami dotyczącymi ochrony środowiska. Wyrzucając ten produkt, należy skontaktować się z lokalnym dystrybutorem lub partnerem. Adresy kontaktowe można znaleźć we wskazanej poniżej witrynie internetowej fi rmy EIZO. http://www.eizoglobal.com...
  • Page 33 Při likvidaci produktu musí být produkt vyzvednut a recyklován podle zákonů příslušné země, aby nedocházelo k zatěžování životního prostředí. Zbavujete-li se produktu, kontaktujte distributora nebo pobočku ve své zemi. Kontaktní adresy jsou uvedeny na následující webové stránce společnosti EIZO. http://www.eizoglobal.com Ringlussevõtu alane teave...
  • Page 34 вашата страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: http://www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
  • Page 35 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan 中国苏州市苏州工业园区展业路 8 号中新科技工业坊 5B Siemensallee 84, 76187 Karlsruhe, Germany 00N0L956B1 http://www.eizoglobal.com IFU-GX550-5 Copyright © 2016-2018 EIZO Corporation. All rights reserved. 2nd Edition-May, 2018 Printed in Japan.
