Suited to displaying medical images of such modalities as mri, ct and digital mammography (41 pages)
Summary of Contents for Eizo RadiForce GX530-CL
Page 1
(separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the Setup Manual for basic information ranging from connection of the monitor to a PC to using the monitor. • The latest User’s Manual is available for download from our web site: http://www.eizo.com...
Page 2
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
Notice for this monitor This product is intended to be used in displaying and viewing digital images including those of digital mammography for review and analysis by trained medical practitioners. Caution: Federal law (USA) restricts this device to sale by or on the order of a physician. This product has been adjusted specifically for use in the region to which it was originally shipped.
Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. Note •...
3-5. Changing Adjustment Menu Display Medical Standard ........... 35 Position ............14 FCC Declaration of Conformity ......36 3-6. Setting the EIZO Logo Display ....15 EMC Information .............37 3-7. Locking Buttons ...........15 LIMITED WARRANTY ..........40 3-8. Enabling/Disabling DDC Communication .15 China Measures for RoHS Compliance in 3-9.
Chapter 1 Introduction Thank you very much for choosing an EIZO monochrome LCD monitor. 1-1. Features • 21.3 inches • Applicable to the resolution of 5M pixels (Portrait : 2048 × 2560 dots (H × V)) • Uses high-contrast panel (1200:1).
1-2. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes software programs for adjustment, and User’s Manual. Refer to Readme.txt file on the disk for software startup procedures or file access procedures.
1-3. Basic Operations and Functions ● Basic Adjustment menu operations Displaying Adjustment Menu 1. Press . The Adjustment menu appears. Menutitle Currentmode Item Settings Menu Adjusting/Setting 1. Choose a menu to adjust/set with , , and then press 2. Choose an item to adjust/set with , , and then press 3.
Chapter 2 Adjusting Screens 2-1. Compatible Resolutions For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual. 2-2. Setting the Resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below.
2-3. Selecting the Display Mode (CAL Switch Mode) This function allows easy selection of a desired mode according to monitor application. Display Modes Mode Purpose 1-DICOM AvailabletodisplayinDICOMmode. 2-Custom Availableforthesettingaccordingtoyourpreference. 3-CAL Displaysthescreenadjustedbycalibrationsoftware. Themodemenu appears. Procedure 1. Press The mode menu appears at the bottom left of the screen. 2.
Chapter 3 Setting Monitor 3-1. Setting the Resolution This function changes the display orientation of the image based on the operating environment. Attention • Refer to the User’s Manual of the graphics board. • Setting is available even when the PC is not started up. Procedure 1.
3-2. Setting Input Signal Signals can be selected based on your operating environment. Attention • A supported graphics board is required to display. • Refer to the User’s Manual of the graphics board. ● To connect DVI Procedure 1. Press to turn off the monitor.
3-3. Enabling/Disabling Mode Selection Allows you to select the specified modes only. Use this function when all the display modes are not available or when keeping the display mode unchanged. Procedure 1. Choose “Tools” from the Adjustment menu, and press 2.
3-6. Setting the EIZO Logo Display This function allows you to display, or not, the EIZO logo. Procedure 1. Press to turn off the monitor. 2. Holding down, press for at least two seconds to turn on the monitor. The “Optional Settings” menu appears.
3-9. Enabling/Disabling DC5V Output This function allows you to enable/disable the DC5V output. Normally, turn it off during use. Procedure 1. Press to turn off the monitor. 2. Holding down, press for at least two seconds to turn on the monitor. The “Optional Settings”...
Chapter 4 Controlling Monitor Quality This product has the built-in Integrated Front Sensor, which allows the user to perform periodic calibration and Grayscale Check for the monitor independently. Note • To perform advanced quality control that conforms to medical standards, use the optional monitor quality control software kit “RadiCS UX1”.
4-2. Checking Grayscale This function allows you to execute Grayscale Check and view the latest result. In addition, when the schedule is set using RadiCS, the next grayscale check schedule appears. ● Executing Grayscale Check Attention • Execute Grayscale Check under the actual temperature of the monitor usage environment. Procedure 1.
Chapter 5 Power Saving Functions 5-1. Setting Power Save This function allows you to set the monitor into the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. Attention •...
5-3. Setting the power saving mode when a person leaves the monitor The sensor on the front side of the monitor detects the movement of a person by setting a value from “Level-1” to “Level-4” of the Presence Sensor function. When a person moves away from the monitor, it shifts to the power saving mode automatically and does not display the images on the screen to reduce the power consumption.
Chapter 6 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. 6-1. No picture Problem Possible cause and remedy 1. No picture • Checkwhetherthepowercordisconnectedproperly. • Powerindicatordoesnotlight. • Turnthemainpowerswitchon. • Press . • Turnoffthemainpower,andthenturnitonagainafew minuteslater. •...
6-2. Imaging problems Problem Possible cause and remedy 1. The screen is too bright or too dark. • Use“Brightness”intheAdjustmentmenutoadjustit.(The LCDmonitorbacklighthasalimitedlifespan.Whenthe screenbecomesdarkorbeginstoflicker,contactyour localdealer.) 2. Characters are blurred. • CheckwhetherthePCisconfiguredtomeettheresolution andverticalscanfrequencyrequirementsofthemonitor (see“CompatibleResolutions”intheSetupManual.). 3. Afterimages appear. • AfterimagesareparticulartoLCDmonitors.Avoid displayingthesameimageforalongtime. • Usethescreensaverorpowersavingfunctiontoavoid displayingthesameimageforextendedperiodsoftime. 4. Interference patterns or pressure marks •...
6-3. Other problems Problem Possible cause and remedy 1. The adjustment menu does not appear. • Checkwhethertheoperationlockfunctionworks(see“3-7. LockingButtons”(page15)). 2. No mode menu is displayed. • Checkwhethertheoperationlockfunctionworks(see“3-7. LockingButtons”(page15)). 3. (When using Presence Sensor) • Checkthesettingenvironmentofthemonitor.Presence The images remain to be displayed when Sensormaynotworkcorrectlyinthefollowing...
An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). http://www.eizo.com Attention • When attaching an arm or stand, follow the instructions of their User’s Manual.
7-2. Connecting Multiple PCs The product has multiple connections to PCs and allows you to switch to one of the connections for display. Connection examples DVI-Dconnector DisplayPortconnector Digital Digital (DVI) (DisplayPort) Signalcable Signalcable (suppliedDD300DL) (suppliedPP300) DVIconnector DisplayPortconnector ToPC1 ToPC2 ● To switch among input signals Procedure 1.
● To set input signal selection Setting Function Auto ThemonitorrecognizestheconnectorthroughwhichPCsignalsareinput. WhenaPCisturnedofforentersthepowersavingmode,themonitorautomatically displaysanothersignal. Manual ThemonitordetectsonlythePC’ssignalscurrentlydisplayingautomatically.Selectan activeinputsignalwith“Input”. Procedure 1. Choose “Tools” from the Adjustment menu, and press 2. Choose “Input Selection” from “Tools”, and press 3. Select “Auto” or “Manual” with or . 4.
7-3. Making Use of USB (Universal Serial Bus) This monitor has a hub compatible with USB. Connected to a PC compatible with USB or another USB hub, this monitor functions as a USB hub allowing connection to peripheral USB devices. ●...
7-4. Displaying Monitor Information ● Displaying signal information This function displays the information about the current input signals displayed. Procedure 1. Choose “Tools” from the Adjustment menu, and press 2. Choose “Signal Info” from “Tools”, and press The “Signal Info” appears. (Example) ●...
Page 31
Standard USBSpecificationRevision2.0 Upstreamportx1,Downstreamport×2 Port 480Mbps(high),12Mbps(full) Communication 1.5Mbps(low) Speed Supplycurrent Downstream:Max.500mA/1port Main Default Settings CAL Switch Mode : The default display mode setting is DICOM. Mode Brightness Gamma value DICOM 500cd/m DICOM Custom Approx.400cd/m DICOM 300cd/m DICOM Others CALSwitchmode 1-DICOM Input...
Page 32
211 (8.3) 105 (4.1) 3 (0.12) (0.71) 209.5 (8.2) 350 (13.8) 245.5 (9.7) Accessories CalibrationKit EIZO“RadiCSUX1”Ver.3.6.1orlater EIZO“RadiCSVersionUpKit”Ver.3.6.1orlater NetworkQCManagementSoftware EIZO“RadiNETPro”Ver.3.6.1orlater For the latest information about the accessories and information about the latest compatible graphics board, refer to our web site. http://www.eizo.com Chapter7Reference...
7-6. Glossary DDC (Display Data Channel) VESA provides the standardization for the interactive communication of the setting information, etc. between a PC and the monitor. DICOM (Digital Imaging and Communication in Medicine) The DICOM standard was developed by the American College of Radiology and the National Electrical Manufacturer’s Association of the USA.
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiForce, RadiCS, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EIZO EasyPIX, EcoView NET, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation.
Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided.
EMC Information Essential performance of RadiForce series is to display images and operate functions normally. CAUTION The RadiForce series requires special precautions regarding EMC and need to be installed, put into service and used according to the following information. Do not use any cables other than the cables that provided or specifi ed by us. Using other cables may cause the increase of emission or decrease of immunity.
Page 39
Recommended separation distances between portable and mobile RF communications equipment and the RadiForce Series TheRadiForceseriesisintendedforuseinanelectromagneticenvironmentinwhichradiatedRFdisturbances arecontrolled.ThecustomerortheuseroftheRadiForceseriescanhelppreventelectromagneticinterferenceby maintainingaminimumdistancebetweenportableandmobileRFcommunicationsequipment(transmitters)andthe RadiForceseriesasrecommendedbelow,accordingtothemaximumoutputpowerofthecommunicationsequipment. Ratedmaximumoutput Separationdistanceaccordingtofrequencyoftransmitter poweroftransmitter 150kHzto80MHz 80MHzto800MHz 800MHzto2.5GHz d=1.2√ P d=1.2√ P d=2.3√ P 0.01 0.12 0.12 0.23 0.38 0.38 0.73 For transmitters rated at a maximum output power not listed above, the recommended separation distance “d” in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where “P”...
