The Direct Access Keys can be programmed with a range of attributes as set in the Configuration and
Master Assignment Programming System (CMAPSi) workstation software. The pushbutton attributes
are:
Talk Only
Listen Only
Talk and Listen
Talk & Forced Listen
NOTE: For the above functions, the destination can be a single or group of panels and external sources,
conferences or IFBs.

4.3.2 PD4206R Direct Access Key Indicator LED

The tri-coloured LEDs associated with the Direct Access Keys (DAKs) have the following meanings:
• Red (R) means "Talk" (key pressed).
• Green (G) means "Listen" (incoming audio from that source).
• Orange (O) means activity (a mix of Talk and Listen).

4.3.3 Designation Strip

Insert a paper Designation Strip to indicate the area of communication for each of the DAK's.
NOTE: Designation strips can be printed using the CMAPSi Print facility.
II
4000 Digital Series
STA0380

Table 24: PD4206R Pushbutton Attributes

A single DAK press causes an audio route to be made from the source
panel to the desired destinations. Normally used for communication
from one panel to another.
A single DAK press causes an audio route to be made from the desti-
nation. Used when listening to an external audio signal (not originating
from a Control Panel) is required.
A single DAK press causes a bi-directional audio route to be made
between the source panel and the destinations. Used between panels
and also with certain external audio signals.
This is similar to Talk and Listen except that the Listen route is perma-
nently made. The operator need only press the DAK to talk.
Issue 1.4 Panel User Guide
Page 65
