When the source number has been entered the display changes to show the following menu:
RAUD Select
--- DIR
The first line of the menu displays the selected source number, its mnemonic and directory text.
This menu allows the displayed source number to be changed, using either the displayed dial-pad or the
DIR function.
DIR Directory. Allows viewing of directory entries.
LIST Allows viewing of audio connections already established using the
Remote Audio facility. Connections can be deleted at this stage (see
next menu).
CNCT Connect. Changes menu to allow entry of destination numbers (3 or 4
digit), directly using the dial-pad or from the directory by pressing DIR.
EXIT Exits to Soft mode.
To view current Remote Audio Control operations press LIST, which changes the display to show the
following menu:
RAUD 600,
UP DOWN
The first line of the menu now displays the source number followed by a destination number and its
directory text.
UP/DOWN Scrolls current Remote Audio Control operations, which have been
set up from the panel.
DEL Deletes the displayed Remote Audio Control operation.
RTN Returns to previous menu where the source number may be
altered.
EXIT Exits to Soft mode.
This menu allows Remote Audio Control operations set up from the panel to be viewed and optionally
deleted. The UP/DOWN pushbuttons scroll through the list that is arranged in chronological order of the
time at which the route was set up.
Press RTN to return to the previous menu, enabling a destination number to be selected, if desired.
To enter a destination number, press CNCT, which changes the menu to display the following:
RAUD: 600,
--- DIR
Panel User Guide
Page 190
600 600
LIST ---
601 Floor
--- DEL
Select Destination
--- ---
PORT 600
CNCT ---
Manager
--- ---
--- ---
Issue 1.4
--- EXIT
RTN EXIT
RTN EXIT
