- Page 1 110LP MOON Series Phono Preamplifier Owner’s Manual...
- Page 2 110LP MOON Series...
-
Page 3: Table Of Contents
Owner’s Manual Table of Contents Introduction Unpacking Installation & Placement Circuit Board Layout s Internal Adjustments Rear Panel Connections Operating the 110LP Specifications www.simaudio.com Simaudio Ltd., 1345 Newton Road Boucherville, Québec J4B 5H2 CANADA Date Code: 20150512... -
Page 4: Introduction
110LP MOON Series Introduction Thank you for selecting the MOON 110LP Phono Your MOON 110LP Phono Preamplifier incorporates Preamplifier as a part of your music/cinema system. many significant design features to achieve its “world This component has been designed to offer state-of- class”... -
Page 5: Unpacking
MOON 110LP Phono Preamplifier from potential damage that may occur during transit. Please write the serial number of your new MOON 110LP in the space provided below for future reference. Serial Number... -
Page 6: Circuit Board Layout
110LP MOON Series Circuit Board Layout Figure 1: MOON 110LP Circuit Board layout Available Adjustments: A – Capacitance loading jumper B – Resistance loading jumper C – Gain level jumper... -
Page 7: Internal Adjustments
Moving Coil Cartridge Loading: There are a total of four (4) screws on the rear side of the To configure your MOON 110LP for use with a moving chassis that you must remove using the included allen- coil (MC) cartridge (refer to figure 1), we recommend key. -
Page 8: Rear Panel Connections
“18VDC INPUT” for use with the included power supply. requires that your Phono Preamplifier and the rest of All rear panel connectors on the MOON 110LP have been chosen because they provide the best possible your components be completely turned off. -
Page 9: Operating The 110Lp
Then connect the terminated end of the power supply “pops”) emanate from your speakers when powering cord to the input labeled 12VDC, located on the rear your 110LP on or off, you should i) Always power up panel of the phono preamplifier’s chassis. In order to your 110LP... -
Page 10: Specifications
110LP MOON Series Specifications Circuit Layout Mirror-image symmetrical circuit Single-ended inputs 1 pair (RCA) Input Impedance - Adjustable 100 and 47kΩ Input Capacitance - Adjustabl 0 and 100pF Gain Level – Adjustable 40 and 60dB Single-ended outputs 1 pair (RCA) - Page 11 Owner’s Manual ____________________________________________________________________________________...
- Page 12 110LP MOON Series...
