CHAPTER 1:UnPACking THE CyClEOPs indOOR CyClE

Place the box upright and cut the plastic binding straps. Lift the top of the box to expose the Indoor Cycle and packaging. Re-
move all parts from the box and foam inserts and ensure all the following parts are included:
Part
Stabilizer front
Stabilizer rear
Main bike assembly
Handlebar tube
Seat post tube
Saddle w/ clamp
Seat assembly
Handlebar
Water bottle holder
Pedal set
IP hardware kit
Stabilizer bolts
Stabilizer bolt washers
Console Bracket bolts
Water bottle spacer
4mm Spacer bolts
Multi-purpose wrench
5mm allen wrench
4mm allen wrench
Console Bracket w/ screw
Console (400 Pro, 300 Pro, 200 Pro)
CHAPTER 2:
BikE AssEmBly
step 1: attach stabilizer Feet
1. Note the difference between the front and rear stabilizer feet. The larger foot with wheels goes in the rear of the IC.
2. Align the rear base of the frame with the rear stabilizer and secure it with four 6mm bolts with washers. NOTE: Tighten
the inner bolts first, and then proceed to the outer bolts to ensure the foot is secured properly and evenly.
3. Repeat with the front stabilizer.
Rear Stabilizer Feet
Qty
1
1
1
1
1
1
1
1
1
1
1
8
8
2
1
2
1
1
1
1
1
Front Stabilizer Feet
1
