Rayvision RVH3004 User Manual

Compact 4 channel h.264 network dvr series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Compact 4Ch H.264 Network DVR Series - MU.Ver1.1
Compact 4 Channel H.264
Network DVR Series
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Rayvision RVH3004

Summary of Contents for Rayvision RVH3004

  • Page 1 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 Compact 4 Channel H.264 Network DVR Series User Guide...
  • Page 2 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1...

  • Page 3: Publication History

    Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 Publication History Version Date Description 27 July 2010 Initial Release 12 August 2010 Add new function for Limitable Recording Days, Calendar Search, PC Viewer and Web Viewer...

  • Page 4: Fcc Statement

    Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 Warnings and Safety Precautions FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 IMPORTANT GUIDELINES User Manual – After unpacking this product, read the owner’s manual carefully, • and follow all the operating procedures and other instructions. Power Source – This product should be operated only from the type of power •...
  • Page 6 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 » When the unit exhibits a distinct change in performance - this indicates a need for service. Servicing – Do not attempt to service this product. Opening or removing covers • may expose the user to dangerous voltage or other hazards. Refer all servicing to qualified personnel.
  • Page 7 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 8 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 viii...

  • Page 9: Table Of Contents

    Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 Table of Contents Publication History....................iii Warnings and Safety Precautions ...............iv Table of Contents ....................ix 1 Overview ......................1 1.1 Front Panel Control ....................2 1.2 Rear Panel Connector .................... 2 1.3 Remote Control ...................... 3 2 Installation ......................5 2.1 Hard Disk Installation....................
  • Page 10 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 3.8.3 Date/Time Setup..................... 37 3.8.4 Sequence Setup ..................... 40 3.8.5 Button Beep Setup..................40 3.8.6 Input Device Setup..................41 3.8.7 Auto Exit Menu....................41 3.9 Hardware Setup ..................... 42 3.9.1 Query Error Message..................42 3.9.2 Hard Drive Setup ....................
  • Page 11 Compact 4Ch H.264 Network DVR Series - MU.Ver1.1 7.1.3 Switching the Channel Displays ..............95 7.1.4 Pause the Viewing ..................97 7.1.5 Capture Still Image ..................97 7.1.6 Playback the PVF File (Backup from DVR side)..........97 7.1.7 Remote Playback.................... 99 7.1.8 Remote DVR Configuration................

  • Page 13: Overview

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Chapter Overview...

  • Page 14: Front Panel Control

    Compact 4ch H.264 Network DVR-MU.Ver1.1 1.1 Front Panel Control The 4-channel H.264 network DVR is designed in two versions: with keypad and without keypad. 1.2 Rear Panel Connector The rear panel of the DVR contains virtually all of the connectors you will be using. The diagrams below outline the location and description of each connector:...

  • Page 15: Remote Control

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Name / Labeled Function CH1~CH4 The BNC connector for video input IR_ext IR extender connector (optional) VGA-OUT The VGA output (DB-9) port for the LCD monitor DC IN 12V DC power port for the power adaptor VIDEO-OUT Video output port for the security monitor The RJ45 port for the network cable...
  • Page 16 Compact 4ch H.264 Network DVR-MU.Ver1.1 Button / Name Function in DVR Mode Start or stop recording / backup. Switch to DVR mode Switch to PTZ mode Rewind through video STOP Stop playback or backup II PAUSE Pause recording of playback Fast forward through video ►...

  • Page 17: Installation

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Chapter Installation...

  • Page 18: Hard Disk Installation

    Compact 4ch H.264 Network DVR-MU.Ver1.1 WARNING Be sure there is no power connection before starting installation! 2.1 Hard Disk Installation The same hard drive installation method is used for either version of the DVR. The DVR contains one internal hard drive side-bracket and is used for installing a SATA hard drive.
  • Page 19 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Slide top cover forward (as indicated by the arrow in the illustration) to remove. Attach the SATA HDD data cable into the Hard Drive data slot (Location: J16) as indicated in the following drawing. Attach the SATA HDD power cable into the HDD power slot (Location: PJ2) as indicated in the following drawing.
  • Page 20 Compact 4ch H.264 Network DVR-MU.Ver1.1 Put the SATA hard drive into the housing marked by the dotted line. Make sure the holes for the screws ○ ○ ○ ○ ○ ○ ○ ○ on the hard disk are aligned with the holes for the screws of the side bracket (please use the following drawing for reference).
  • Page 21 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Push the cover down and slide back (as indicated by the arrow in the illustration) into place. Fasten one screw on the top housing and four screws on the bottom housing to secure.

  • Page 22: Video Format Detection

    Compact 4ch H.264 Network DVR-MU.Ver1.1 2.2 Video Format Detection The DVR can automatically detect the video format (either NTSC or PAL) after the cameras have been properly installed and the DVR has been powered on. Please refer the section “Hardware Setup” to setup the NTSC/PAL auto detection. 2.3 Connection Guide Connect all peripheral devices properly before turn on the DVR.
  • Page 23 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Connect USB mouse Connect the USB mouse to the mouse port labeled as “ ” on the DVR. This port only supports a USB mouse and not other devices. Connect the IR Extender (Optional) Connect the IR extender cable to the port labeled as “IR_ext” on the DVR. The cable is an optional device which serves as an IR controller extension.

  • Page 24: Getting Started

    Chapter Getting Started...

  • Page 25: Turning On The Dvr

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.1 Turning on the DVR The DVR is ready for running after all peripherals have been properly installed. Connect the power adaptor to turn the DVR on. The DVR may take a few second to startup.

  • Page 26: State Bar Information

    Compact 4ch H.264 Network DVR-MU.Ver1.1 1% 2010/06/06 15:37:47 3.2.1 State Bar Information The State Bar displays the status and notification icons of the surveillance system. 1% 2010/06/06 15:37:47 Icon Function Icon Function Camera is working No signal from camera Recording Stop recording Network connected Network disconnected...

  • Page 27: Control Bar Information

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.2.2 Control Bar Information The Control Bar may be used to switch displays, open and setup channels and their related applications. Icon Function Icon Function Load default channel display location 4-channel split view Auto channel rotation Start recording Stop force recording Start force recording...

  • Page 28: Main Menu

    Compact 4ch H.264 Network DVR-MU.Ver1.1 » Press left-button of the mouse and drag 1% 2010/06/06 15:37:47 the channel-square to the new position. » Release the mouse button to drop the 1% 2010/06/06 15:37:47 channel-square into new position. » System will keep the new channel display arrangement even if you reboot the DVR system.
  • Page 29 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Main Menu Guideline MAIN MENU Icon Name Function DVR Power Supply To reboot or shutdown the DVR system Set the channel display, record, channel name Channel Setup and video color adjustment. Set the record schedule, video performance and Record Setup quality Detector Setup...

  • Page 30: Channel Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.4 Channel Setup Press to enter the “Channel Setup”. The screen will display the menu shown in the following illustration. CHANNEL SETUP Channel Number Basic Setting Standard Color Adjustment Press the icon to expand the menu. Press the icon to collapse the menu.

  • Page 31: Record Channel

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.4.2.2 Record Channel To set one or all channels are record or not. The channel will be displayed on screen even when it is not recording. “ON” – Record. “OFF” – Not Record. 3.4.2.3 Hidden Channel To set whether or not to display one or all channels on screen.
  • Page 32 Compact 4ch H.264 Network DVR-MU.Ver1.1 3.4.2.6 Image Position Adjustment Adjusts the position of display on the monitor. Select the icon “ ” to adjust the display position of all channels in the 4-split view at once. Select the icon “ to individually set the image position of each channel.

  • Page 33: Standard Color Adjustment

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.4.3 Standard Color Adjustment Adjusts the video color parameters for each channel or simultaneously for all channels. CHANNEL SETUP Channel Number Basic Setting Standard Color Adjustment ◄▬▬▐▬▬► [10] Brightness ◄▬▬▐▬▬► [10] Contrast ◄▬▬▐▬▬► [16] ◄▬▬▐▬▬► [16] Saturation ◄▬▬▐▬▬►...

  • Page 34: Auto Record

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.5.1 Auto Record Auto Record is utilized to set the period (OFF, 10Sec, 20Sec, 30Sec, 40Sec, 50Sec or 60Sec) within which the DVR will automatically start recording. Default value is “30Sec”. This feature is particularly useful in automatically re-starting your DVR recording in case of an abnormal shut down.
  • Page 35 Compact 4Ch H.264 Network DVR-MU.Ver1.1 NOTE When “Motion Mode” is set for the recording schedule. Remember to complete the “Motion Setup” at the main menu of “Detector Setup” - otherwise it will not be able to record during the period set on “Motion Mode”.
  • Page 36 Compact 4ch H.264 Network DVR-MU.Ver1.1 The following example shows that on Sunday, the whole day is set to the “Time” recording mode. Select “Time” recording mode, press the icon “ ” and press “”↵”. Record Schedule Channel Number None Time Motion Day\Hour Sunday...

  • Page 37: Total Power

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 The following example shows that on Sunday, from 19:00 to 24:00 (7:00pm to 12:00mn), and on Friday, from 2:00 to 4:00 (2:00am to 4:00am), are set to the “Time” recording mode. Select the recording mode first. Move the cursor and click the icon “ ”, “ ”, “ ” to change mode on the timetable.

  • Page 38: Auto Settings Adjustment

    Compact 4ch H.264 Network DVR-MU.Ver1.1 Record Setup Total Power: 240/240 (Power/Sec) Resolution Quality Frame rate ◄Half D1► [Standard] [30] [ Half D1 ] [Standard] [30] [ Half D1 ] [Standard] [30] [ Half D1 ] [Standard] [30] Video Resolution, Quality and Frame Rate Setting for each Channel Resolution: Press the button “◄...

  • Page 39: Recording Resolution

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.5.5.2 Recording Resolution Select the recording resolution for each or all channels as: » D1: 704*480 / 60fps (NTSC); 704*576 / 50fps (PAL) » Half D1: 704*240 / 120fps (NTSC); 704*288 (PAL) (Default) » CIF: 352*240 / 120fps (NTSC); 352*288 (PAL) 3.5.5.3 Video Quality Video image quality settings can be Highest, High, Standard, Low, and Lowest.

  • Page 40: Detector Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.6 Detector Setup Detector Setup configures the alarm and motion mode for each or all channels. DETECTOR SETUP Channel Number Alarm Setup Blind Detect Alarm Mode [Sensitivity OFF] Blind Detect Alarm Mode [ Buzzer-Short] Video Loss Mode [X Disable] Video Loss Alarm Mode [ Buzzer-Short]...

  • Page 41: Motion Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 “Sensitivity Normal”: Normal sensitive level “Sensitivity High”: High sensitivity level “Sensitivity Highest”: Highest sensitive level 3.6.2.2 Blind Detect Alarm Mode Select the alarm mode when the Blind Detect Mode is triggered. “Mute”: No beep whatever loss of light or not. “...

  • Page 42: Record Time

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.6.3.1 Record Detection Activate This feature makes the whole setting of motion setup is efficacious even the DVR under the “Time Recording” mode. Enable: Activates record detection for motion (default) Disable: Deactivates record detection for motion NOTE Remember to specify the area you would like monitor using the “Motion Area Setup”...

  • Page 43: Motion Area Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.6.3.7 Trigger Type There are two trigger types: Initial Trigger and Continuous Trigger. Initial Trigger When channel has been triggered, the triggering event will be displayed on full screen for the duration of the setting period. During that period, this channel will ignore any other triggering events.

  • Page 44: Authentication Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.7 Authentication Setup Authentication Setup manages the authorization for accounts, passwords, and permissions. Click the following icons for authority management AUTHENTICATION SETUP Account ID Passwd admin ＊ ＊ ＊ ＊ ＊ ＊ power ＊ ＊ ＊ ＊ ＊ ＊ police ＊...
  • Page 45 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Click “[ Option] for authority management of channel monitoring setup AUTHENTICATION SETUP Account ID Passd Video Monitoring admin ＊ ＊ ＊ ＊ ＊ ＊ power ＊ ＊ ＊ ＊ ＊ ＊ police ＊ ＊ ＊ ＊ ＊ ＊ guest ＊...

  • Page 46: System Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.8 System Setup System Setup sets the Language, Viewing, Date/Time, Sequence, Button Beep, Input Device, and other relevant parameters. SYSTEM SETUP Language Selection [English] View Setup Date/Time Setup Sequence Setup Full Screen Sequence [√ON] ▐▬▬▬▬▬ 4 Split Sequence [XOFF] Button Beep Setup...

  • Page 47: Error Message

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.8.2.1 Main Menu Graphics Mode Sets the main menu displayed by graphic icons or text mode. Graphics Mode Text Mode MAIN MENU MAIN MENU Channel Setup Record Setup Detector Setup Authentication Setup System Setup Hardware Setup Utility/Tools Exit Main Menu 3.8.2.2 Channel Dynamic Effects...

  • Page 48: Channel Information

    Compact 4ch H.264 Network DVR-MU.Ver1.1 1% 2010/06/06 15:37:47 State Bar Information : Recording Light : Network Information : Hard Drive Information 2010/06/06 15:37:47: Date/Time Information : Rotation Information 3.8.2.6 Channel Information Determines how channel information is set and shown. VIEW SETUP System Display Setup State Bar Information Channel Information...

  • Page 49: Date/Time Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 1% 2010/06/06 15:37:47 Channel Information : The Channel Number Icon : Recording Light : Video Loss : Record Mode (Not Flashing) : Detection Mode (Flashing when the motion is triggered) 3.8.3 Date/Time Setup Date/Time Setup Menu sets relevant information on date and time. DAY/TIME SETUP Date Display Mode [YYYY/MM/DD]...

  • Page 50: Date Display Mode

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.8.3.1 Date Display Mode Date Display Mode is used to choose a date format for the state information. The allowable formats are YYYY/MM/DD, DD/MM/YYYY, and MM/DD/YYYY. 3.8.3.2 Time Set “Time Set” is for adjusting the date and time. Time Set [ 2010/06/14 11:28:22] ( / ): Up / Down –...

  • Page 51: Ntp Server

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.8.3.4.3 Time Ends “Time Ends” indicates the end date of daylight saving time. The user can set the month, week number, day, and hour. Time Ends ◄October► Month Week [First Week] [Sunday] Hour 3.8.3.5 NTP Server NTP Server allows for the synchronization of the day/ time settings with the NTP server through internet.

  • Page 52: Sequence Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.8.4 Sequence Setup The Sequence Setup Menu is for setting the channel rotation sequence period. SYSTEM SETUP Language Selection [English] View Setup Date/Time Setup Sequence Setup Full Screen Sequence [√ON] ▐▬▬▬▬▬ [X OFF] 4 Split Sequence Button Beep Setup Input Device Setup Auto Exit Menu...

  • Page 53: Input Device Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.8.6 Input Device Setup Input Device Setup is used to set the speed of the following input devices: mouse, keypad and IR Remote. SYSTEM SETUP Language Selection [English] View Setup Date/Time Setup Sequence Setup Button Beep Setup Input Device Setup Mouse Moving Speed [Normal]...

  • Page 54: Hardware Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.9 Hardware Setup Hardware Setup is the menu for configuring hardware parameters including error message, hard drive, network and screen display. HARDWARE SETUP Query Error Message Hard Drive Setup Network Setup Screen Setup NTSC/PAL Auto Detection [XOFF] Video Output Format [NTSC]...

  • Page 55: Hard Drive Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.9.2 Hard Drive Setup The Hard Drive Setup menu displays hard disk information and allows the user to enable the HDD overwriting. HARD DRIVE SETUP Overwrite Enable [√Yes] ▐▬▬▬▬▬ [ None] Max. Recording Days First Hard Disk Model [WDC WD7500AYPS-01ZKB] HDD Size...

  • Page 56: Network Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.9.2.3 First Hard Disk Model: Automatically displays the hard drive model number • HDD Size: Automatically displays the hard drive size • Max. Days Size: Displays the days of recording data will be retain in the hard •...

  • Page 57: Ip Address Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.9.3.2 IP Address Setup The IP address acts as a locator or an identification number to enable a device on a TCP/IP network to locate other devices and interact with them. Certain parameters need to be set through IP Address Setup to ensure proper network communication. NETWORK SETUP Network Enable [√...
  • Page 58 Compact 4ch H.264 Network DVR-MU.Ver1.1 NOTE You must plan on the network structure if the MIS or Network Administrator manages the network. Consult with the MIS or Network Administrator for the IP address segment and port-forwarding rule for the DVR network setup. 3.9.3.3 Management / Monitoring Setup The Management/Monitoring Setup menu addresses the management and monitoring service for remote DVR control and viewing from the internet (i.e.

  • Page 59: Server Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.9.3.4 Server Setup Configure the DNS server. SERVER SETUP Default DNS Address [168. 95.192. Custom DNS Address [168. 95. Dynamic DNS Activate Service [X Disable] Provider [www.dyndns.com] Server Name [No Definition] Account [No Definition] Password [No Definition] Default DNS Address The Domain Name System (DNS) translates hostnames to IP addresses (default...

  • Page 60: Screen Setup

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.9.4 Screen Setup Adjusts the video format and resolution of the display device. HARDWARE SETUP Query Error Message Hard Drive Setup Network Setup Screen Setup NTSC/PAL Auto Detection [XOFF] Video Output Format [NTSC] Screen Border [√ON] Main Display Screen [VGA]...
  • Page 61 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Main Display Screen Provides options to connect the main display screen to either a BNC or VGA port (Labeled as “VIDEO-OUT”). VGA Resolution Sets the resolution as 640x480, 800x600, 1024x768 or 1280x1024. Video Adjustment Adjusts the position of main display on the monitor when connect the main display screen to BNC port (Labeled as “VIDEO-OUT”).

  • Page 62: Utility/Tools

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.10 Utility/Tools These tools help you to format the USB dongle, to update firmware, to export event logs and to load or restore the environment configuration. UTILITY/TOOLS Format USB Disk Firmware Update Environment Setting Save Settings to USB Load Settings from USB Restore Default Setting 3.10.1 Format USB Disk...

  • Page 63: Firmware Update

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 3.10.2 Firmware Update The firmware is updated by using a USB pen drive that contains the latest firmware file. Attach the external USB disk into the USB port on DVR front panel. FIRMWARE UPDATE Current Revision: V14.0.0 Current Date/Time: Jun 14 2010 05:22:38 Current Language: English Current Checksum: 0x0332E245...
  • Page 64 Compact 4ch H.264 Network DVR-MU.Ver1.1 After reading the firmware is displayed. Click this button on begin the upgrade. FIRMWARE UPDATE Current Revision: V14.0.0 Current Date/Time: Jun 14 2010 05:22:38 Current Language: English Current Checksum: 0x0332E245 File Name: FWVX4TWNFWI File Revision: V14.00 File Date/Time: Jan 15 2010 16:45:52 File Language: English File Checksum: 0x02E165B5...

  • Page 65: Environmental Setting

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 After firmware update is completed, Firmware update is success, System will restart ----“ is displayed, and then the system restarts. FIRMWARE UPDATE Current Revision: V14.0.0 Current Date/Time: Jun 14 2010 05:22:38 Current Language: English Current Checksum: 0x0332E245 Firmware update is success System will restart File Name: FWVX4TWNFWI...
  • Page 66 Compact 4ch H.264 Network DVR-MU.Ver1.1 Load Settings from USB LOAD SETTINGS FROM USB USB Disk [General Flash Disk] Free Capacity [905MB] Total Capacity [1005MB] Read File [Env2010-07-14_0503] Load File] [ File Select] This tool can help you load the system environment configuration from the USB device. Click [ File select] to select the file you would like to load.

  • Page 67: Exit Main Menu

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Load default setting Restore default settings? [ √YES] [ XNO] Select “YES” to load the default setting. After which, the system will reboot. Reset completed, System will restart… 3.11 Exit Main Menu Provides options to save or discard changes before exiting. MAIN MENU Channel Setup Record Setup...

  • Page 68: Exit & Discard Changes

    Compact 4ch H.264 Network DVR-MU.Ver1.1 3.11.2 Exit & Discard Changes All changes are ignored (The changes will not be saved and will take no effect.) before exiting from the menu. Confirm with “Yes” or go back to the menu by choosing “No”. Exit Main Menu □...

  • Page 69: Playback And Data Backup

    Chapter Playback and Data Backup...

  • Page 70: Calendar Menu

    Compact 4ch H.264 Network DVR-MU.Ver1.1 4.1 Calendar Menu Press “ ” and “ ” buttons or click the icon “ ” to enter “Calendar Menu”. The calendar menu helps you to playback by specific hour. First, select the year and month by press “ ” or “ ” buttons or onscreen icons. Second, select the date and hour when the number turns to around with circle “...

  • Page 71: Play Menu

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Plays forward faster Fast Forward Plays forward the recorded video by one hour Next Segment Goes back to Calendar Menu Calendar Menu Goes back to Play Menu Play Menu Goes to Search Menu Event Search Shifts the bar to select the playback time from the Play Bar recorded video data you would like to review.
  • Page 72 Compact 4ch H.264 Network DVR-MU.Ver1.1 2121 ▲ ▲ 2010/07/14 06:18:31 ▲ 2120 ▲ ▲ 2010/07/14 06:17:12 2119 ▲ ▲ 2010/07/14 05:57:38 2118 ▲ ▲ 2010/07/14 04:20:11 2117 ▲ ▲ 2010/07/14 02:18:42 [ Option] [ Play] [ Backup] [ Play]: Start playing the recorded data. After the data has been played, it will show “...

  • Page 73: Event Search

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 4.3 Event Search Press “ ” (or “ ”) button or icon to enter Event Search Menu. SEARCH MENU Channel Number Filter Type [All Events] Filter Time Setup [X Disable] 2121 ▲ ▲ 2010/07/14 06:18:31 ▲...
  • Page 74 Compact 4ch H.264 Network DVR-MU.Ver1.1 SEARCH MENU Channel Number Filter Type [All Events] Filter Time Setup [X Disable] 2121 ▲ ▲ 2010/07/14 06:18:31 ▲ 2120 ▲ ▲ 2010/07/14 06:17:12 2119 ▲ ▲ 2010/07/14 05:57:38 2118 ▲ ▲ 2010/07/14 04:20:11 2117 ▲ ▲...

  • Page 75: Data Backup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 4.4 Data Backup The DVR supports data backup by USB 2.0 device (Support the pen drive and card reader) on the front panel. Press the “ ” (or “II ”) button to enter the “Play Menu”. PLAY MENU Channel Number Play Begin Time...
  • Page 76 Compact 4ch H.264 Network DVR-MU.Ver1.1 Backup channel: selects single or multi channels you would like to backup. • You can change the period of recorded data for backup by setting the “Start Time” and “End Time”. BACKUP MENU Backup Device [Generic Flash Disk] Free Capacity [1029352/1029380 KB]...

  • Page 77: System Information

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Chapter System Information...

  • Page 78: Record Information

    Compact 4ch H.264 Network DVR-MU.Ver1.1 5.1 Record Information Displays the current states of the DVR system. Click “ ” to show record information as following window: RECORD INFORMATION 10 30 The items for record information “ ” Channel Number “ ” Video Loss “...

  • Page 79: Hard Drive Information

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 5.2 Hard Drive Information The Hard Drive Setup menu displays the hard drive status. HARD DRIVE SETUP First Hard Disk Model [WDC WD7500AYPS-01ZKB] HDD Size [715403MB] Max. Recording Days [2Day] Record Start Time [2006/06/11 15:26:18] Record End Time [2010/06/14 13:13:30] Standard Record Size [2438/715351 MB 35%]...

  • Page 80: Network Information

    Compact 4ch H.264 Network DVR-MU.Ver1.1 5.3 Network Information Displays the current state of network connection. NETWORK SETUP IP Type [DHCP] IP Address [192.168. 11.198] IP Status [ Connected] Login Status Login Count Network Service Management Service [√ Enable] Monitoring Service [√...

  • Page 81: Lan & Online Viewing Setup

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Chapter LAN & Online Viewing Setup...

  • Page 82: Pc Connection Through Local Area Network

    Compact 4ch H.264 Network DVR-MU.Ver1.1 6.1 PC Connection through Local Area Network Here is an example that shows how to find the basic network information from the local area network (hub). Search Router IP Address Please click “Start” and then “Run” option under Windows. Please enter “CMD”...
  • Page 83 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Find out your DVR IP address Now we known the Router IP address is 192.168.11.1. Generally the usable IP Address is from 192.168.11.2~192.168.11.253. The suggested IP Address available for assigned to other network devices is from 192.168.11.160 to 192.168.11.199.

  • Page 84: Dyndns Service Overview

    Compact 4ch H.264 Network DVR-MU.Ver1.1 Setup DVR IP Address When you find a usable IP address, go back to DVR menu: “Network Setup” to enter IP address. IP ADDRESS: Enter the DVR’s address [192.168.011.188] • GATEWAY: Enter Router IP Address[192.168.011.001] •...

  • Page 85: Create Dyndns Account

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 6.2.2 Create DynDNS Account Click the Create Account, and then start to create your own DynDNS Account and fill out all the blanks for account’s application as following: Please refer below for the maximum number of characters acceptable for the DVR: S erver Name”: Maximum of 24 characters “...
  • Page 86 Compact 4ch H.264 Network DVR-MU.Ver1.1 After you click "Create Account", it shows the message for verifying the account. DynDNS will create a new account for you and send you an e-mail to the address you provided. It needs to confirm your account within 48 hours after receiving the e-mail or it will automatically delete your account.

  • Page 87: Login And Host Service

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 6.2.3 Login and Host Service Login by entering the Username and Password of your account. Then, go to “My Service” to get a host name...
  • Page 88 Compact 4ch H.264 Network DVR-MU.Ver1.1 Double click “Add New Hostname” as following: Specify the Hostname for DYNDNS IP which will be applied to the DVR’s DYNDNS setting. We take dvr-host-tw.homelinux.net as an example, and click “Add to Cart” The Dynamic DNS Hosts service is sufficient and is provided for free. Press “Next”...
  • Page 89 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Press “Activate Services” Now, the DYNDNS service is completed.

  • Page 90: Setup Router

    Compact 4ch H.264 Network DVR-MU.Ver1.1 Take note of the User name, Password and Hostname. 6.2.4 Setup Router Most of the settings for the router is identical, here is the suggestion: Specify DYNDNS service provider: DnyDNS.org (dynamic) • Specify DYNDNS IP by DYNDNS account (user name / password ) •...

  • Page 91: Pc Viewer & Web Browser Viewer

    Chapter PC Viewer & Web Browser Viewer...

  • Page 92: Pc Viewer Installation

    Compact 4ch H.264 Network DVR-MU.Ver1.1 7.1 PC Viewer Installation PC Viewer will help you to play the video data on the Windows platform computer, please refer to the attached CD, then run “PC Viewer” to playback the DVR video data. Windows OS platform requires that the application be run as the administrator user.
  • Page 93 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Function DVR connection window Delete the DVR connection Modify the DVR connection Add new DVR connection Close the connections window Open the DVR connection window DVR connection status and switch button Exit the PC viewer Capture the still images...
  • Page 94 Compact 4ch H.264 Network DVR-MU.Ver1.1 7.1.2 Connect PC Client to DVR This section describes how to manage the DVR connection window. Click the button to open the DVR connection window. Click the button to add, modify, delete the DVR connection or close the DVR connection window.

  • Page 95: Switching The Channel Displays

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 Select the DVRs you would like to connect, viewing and control from the list of available DVRs. A check mark will indicate your choices. 7.1.3 Switching the Channel Displays This section briefly illustrates how to switch channel display. Display a single channel on one quadrant Double click on the channel you would like to display on one quadrant.
  • Page 96 Compact 4ch H.264 Network DVR-MU.Ver1.1 Display 4 channels viewing on one quadrant Double click the single channel viewing to switch the display. The screen will appear as follows: Display a single DVR connection display in full view Click the DVR connection switch button to display a single DVR connection in full view. The screen will appear as follows:...
  • Page 97 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Display single channel in full view: Double click the specific channel you would like to display in full view, or click the “ ” icon to switch the display. The screen will appear as follows: 7.1.4 Pause the Viewing Click on the “...
  • Page 98 Compact 4ch H.264 Network DVR-MU.Ver1.1 7.1.5 Capture Still Image Click on the “ ” icon to capture still image of the view that is currently displayed on the screen. Save the BMP image to the specific location in your computer. For Web Browser Viewer, the still image will be stored at “C:\Viewer”...
  • Page 99 Compact 4Ch H.264 Network DVR-MU.Ver1.1 7.1.6.1 Preview of the Control Bar Name Function Fast Backward 2x Plays backward faster by twice the normal speed Fast Backward 1x Plays backward faster by 1x the normal speed Playback Starts the video playback Fast Forward 1x Plays forward faster by 1x the normal speed Fast Forward 2x...

  • Page 100: Playback By Event Search

    Compact 4ch H.264 Network DVR-MU.Ver1.1 Click on the icon back to “Time Search” control window. 7.1.6.3 Playback by Event Search “Event Search” playback mode supports playback by the specific event. Select the “Event Begin Date”, “Event Begin Time”, Event End Date”, “Event End Time” and “Event (Event Type)”...
  • Page 101 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Playbacks the event by mouse double clicks. You will see the video playback as following figure: Click on the icon back to “Event Search” control window. NOTE The “Record” and “Normal” events incorporate with video data for playback.

  • Page 102: Remote Dvr Configuration

    Compact 4ch H.264 Network DVR-MU.Ver1.1 7.1.7 Remote DVR Configuration Click the icon to display the remote configuration interface on your PC Viewer. You can change the DVR configuration on this interface. The operation method of the remote configuration interface is consistent with the DVR interface.
  • Page 103 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Click “Play File” to read the PVF file from your USB device.
  • Page 104 Compact 4ch H.264 Network DVR-MU.Ver1.1 After select and open the PVF file, PC Player will start to playback the PVF file.

  • Page 105: Connect Pc Client To Dvr

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 7.1.9 Click on the PC desktop icon “ ” to execute the PC Viewer at the Windows platform computer. The PC Viewer support remote viewing and control for maximum 4 DVR connections. Function DVR connection window Delete the DVR connection Modify the DVR connection Add new DVR connection...
  • Page 106 Compact 4ch H.264 Network DVR-MU.Ver1.1 Click the button to open the DVR connection window. Click the button to add, modify, delete the DVR connection or close the DVR connection window. Let us add a new DVR connection: Press the “Add' button to create a DVR connection. 10.

  • Page 107: Switching The Channel Displays

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 7.1.11 Switching the Channel Displays This section briefly illustrates how to switch channel display. Display a single channel on one quadrant Double click on the channel you would like to display on one quadrant. The screen will appear as follows: Display 4 channels viewing on one quadrant Double click the single channel viewing to switch the display.
  • Page 108 Compact 4ch H.264 Network DVR-MU.Ver1.1 Display a single DVR connection display in full view Click the DVR connection switch button to display a single DVR connection in full view. The screen will appear as follows: Display single channel in full view: Double click the specific channel you would like to display in full view, or click the “...

  • Page 109: Pause The Viewing

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 7.1.12 Pause the Viewing Click on the “ ” icon to pause the current viewing. 7.1.13 Capture Still Image Click on the “ ” icon to capture still image of the view that is currently displayed on the screen.
  • Page 110 Compact 4ch H.264 Network DVR-MU.Ver1.1 Click “Open File” to read the PVF file from your USB device.

  • Page 111: Remote Playback

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 After select and open the PVF file, PC Player will start to playback the PVF file. 7.1.15 Remote Playback Click on the “ ” icon to display the remote playback interface on your PC Viewer.
  • Page 112 Compact 4ch H.264 Network DVR-MU.Ver1.1 7.1.15.1 Preview of the Control Bar Name Function Fast Backward 2x Plays backward faster by twice the normal speed Fast Backward 1x Plays backward faster by 1x the normal speed Playback Starts the video playback Fast Forward 1x Plays forward faster by 1x the normal speed Fast Forward 2x...
  • Page 113 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Select the “Begin Date” and “Begin Time” then click “ ” button to playback the video by your specific time. 7.1.15.2.2 Playback by Event Search “Event Search” interface offers user to playback recording video by specific event.

  • Page 114: Remote Dvr Configuration

    Compact 4ch H.264 Network DVR-MU.Ver1.1 Selects the Event Begin Date and Time, Event End Date and Time and Event type, then press “ ” to load the event list from DVR. Double click the specific event for playback; you will see the video playback on the Main Window as following: NOTE The “Record”...

  • Page 115: Web Browser Viewer

    Compact 4Ch H.264 Network DVR-MU.Ver1.1 You can change the DVR configuration on this interface. The operation method of the remote configuration interface is consistent with the DVR interface. Please refer to the DVR operation sections on this manual. 7.2 Web Browser Viewer This section introduces the remote viewing and control through Web Browser Viewer.
  • Page 116 Compact 4ch H.264 Network DVR-MU.Ver1.1 Select “Security” “Trusted Sites” “Sites” → → Enter the DVR address into the blanks shown in picture, and click “add.” (This address is only for demonstration. Please use the IP address linked to your on-site DVR.) The newly added website will appear at the trusted web sites list.
  • Page 117 Compact 4Ch H.264 Network DVR-MU.Ver1.1 Go back to the internet browser (IE) window, press refresh button or F5. You will enter the Web Browser Viewer login page. Enter the designated user name and password. (Enter the default user name “admin” and password “123456”...

  • Page 118: Switching The Channel Displays

    Compact 4ch H.264 Network DVR-MU.Ver1.1 7.2.1 Switching the Channel Displays Display single channel in full view: Double click the channel to display single channel in full view. Display four channels in full view: Double click the full view display to switch into four channels display. 7.2.2 Web Browser Viewer Operation The Web Browser interface is consistent with PC Viewer.

  • Page 119: Secuviewer

    Chapter SecuViewer...

  • Page 120: Iphone Environment

    8.1 iPhone Environment Please setup your iPhone environment as following condition: Upgrade the iPhone OS version up to iOS4.0 or above. Check the iOS version from iPhone [Settings] [General] [About] [Version] → → → If you need to upgrade the iOS, please update from iPhone [App Store] →...

  • Page 121: Secuviewer Interface Overview

    You can see the SecuViewer icon on the iPhone main screen. 8.3 SecuViewer Interface Overview SecuViewer simple operation guide Connect to the DVR Stop the DVR connection Setup the DVR connection. Display channel one Display channel two Display channel three Display channel four...

  • Page 122: Connect To The Dvr

    8.4 Connect to the DVR Select the SecuViewer icon on iPhone main screen to start the remote monitoring. Select the “Setup” icon to setup the DVR connection.
  • Page 123 Please setup all information to connect to the DVR: » Network IP Address: Enter the DVR 59.124.68.61 IP Address. » Network Port: Enter the network port (default is 8000). admin » User Name: Enter the user name (default is 123456 admin).
