Configuration Program
The WBR-3407 contains an HTTP server. This enables you to connect to it, and configure it,
using your Web Browser. Your Browser must support JavaScript.
The configuration program has been tested on the following browsers:
•
Netscape V4.08 or later
•
Netscape 7
•
Internet Explorer V5.01 or later
Preparation
Before attempting to configure the WBR-3407, please ensure that:
•
Your PC can establish a physical connection to the WBR-3407. The PC and the WBR-
3407 must be directly connected (using the Hub ports on the WBR-3407) or on the same
LAN segment.
•
The WBR-3407 must be installed and powered ON.
•
If the WBR-3407's default IP Address (192.168.0.1) is already used by another device, the
other device must be turned OFF until the WBR-3407 is allocated a new IP Address
during configuration.
Using your Web Browser
To establish a connection from your PC to the WBR-3407:
1. After installing the WBR-3407 in your LAN, start your PC. If your PC is already running,
restart it.
2. Start your WEB browser.
3. In the Address box, enter "HTTP://" and the IP Address of the WBR-3407, as in this
example, which uses the WBR-3407's default IP Address:
HTTP://192.168.0.1
4. When prompted for the User name and Password, enter values as follows:
•
User name
•
Password
admin
password
Setup
9
