J2 630/615/580 Ups; Specifications; Hardware - J2 630 System Manual

J2 630/615/580 UPS

Specifications

Batteries Run Time
Power In
Power Out
Data Interface
Batteries Type
Battery Life
Charge Time
Charger Type
Software
Size

Hardware

To install and use the J2 UPS module:
1: Remove the power supply adaptor from the base of the unit.
2: Install the UPS module where the power supply was mounted.
3: Connect the power output jack of the UPS to the power in jack of the unit.
4: Connect the Serial cable of the UPS to the serial port you wish to use. *
5: Connect the power supply adaptor to the UPS power in jack.
6: Connect the power supply adaptor to the mains power. **
7: Configure the Windows UPS drive as shown.
* The serial port connection is not needed for Windows CE.
** When first installed the mains power should be applied for 5 hours to fully charge the
batteries. The unit may be running during this time but will take longer to charge.
630 System Manual
Version 1.1 December 14, 2010
2 hours for the standard J2 630, run time will vary
depending on the application loading
19 Volts DC
13-16.8 Volts DC, 8 amps maximum
RS232 cable, RJ45 connector
2 – 4 18630 cell Li-Ion pack with protection circuit
500 full discharge cycles
5 hours from full discharge
Smart Microcontroller based
XP Standard Generic UPS driver
6" x 3.1" x 1.7" (152mm x 79mm x 43mm)
54
