- Page 1 J2 615 Integrated Touchscreen Computer System Manual March 2010...
- Page 2 Change history Version 0.1 to Version 1.0 1: Fix cable pin out RJ45 to DB25 J2 Serial Cable, RTS DB25 pin wrong, DB25 SD and RD signals marked wrong. 2: Fix cable “Pin-out when using 8 wire CAT5/6 cable”, RTS DB25 and DSR pin wrong, DB25 SD and RD signals marked wrong.
-
Page 3: Table Of Contents
Onboard SSD ........................ 19 Mini PCI-E ........................20 Power Supply ........................ 20 Typical Power Consumption 615 .................. 21 Packing List ........................22 Standard Items ......................22 System Installation ......................23 Counter Top Base ......................23 ... - Page 4 Optional Items ......................... 32 Customer Display Option ....................33 Connecting the Cable for a J2 615/580 customer display ..........33 Dip Switch and Software Setting .................. 33 J2 615/580 UPS ........................ 35 Specifications ........................ 35 Hardware ........................35 ...
-
Page 5: Overview
HDD or a larger size SSD, please contact your J2 sales person for more details. The “all in the head” design means that the J2 615 can serve as a counter top, or as a wall or a pole mounted unit all in the same computer. With the standard counter top base and optional VESA/wall mount brackets, the versatile 615 can fit numerous touch screen applications. - Page 6 J2 615 Intrgrated Touch Screen Computer 615 System Manual Version 1.0 March 21, 2010...
-
Page 7: Specifications
One Gigabit, RJ45 in cable well (Realtek RTL8111) Optional 12” or 10.4”secondary customer-facing display, powered from the J2 615 (or other external monitor), up to 2048 x 1536 Cash Drawer RJ 11 (24V or 12V) with status, can support two cash drawers DC Jack Power in, 19VDC 3.42 amps... - Page 8 10.4" or 12” Second LCD display, with or without touch, Second Display powered from the J2 615 Customer Customer Side VFD display with 2 x20 characters, powered from 615 Display 2 hour DC UPS, mounts in base of unit Mounting Standard Counter Top Base, Adjustable Viewing Angle 0-90°...
-
Page 9: System
System The J2 615 uses the same dynamic design as the J2 580 and J2 650 computers. This allows for different systems to be integrated at the same customer site, maintaining a well balanced look and feel for your important installations. -
Page 10: I/O Ports
The function of the button can be controlled by the OS; should the J2 615 hang for some reason, note that it can always be powered off by holding the On /Off button in for six seconds. -
Page 11: Solid State Drive / Hard Disk Drive
Solid State Drive / Hard Disk Drive The J2 615 has one drive bay that supports a 2.5 inch SATA SSD or HDD. The standard drive supplied is an 8GB Solid State Drive (SSD). The SSD or HDD can be accessed simply by loosening the one screw on the drive bay panel on the right side of the unit. -
Page 12: Touch Screen
615 unit includes a water tight gasket for spill resistance. The ELO Infrared (IR) is also available for the J2 615 as an option. The IR touch screen has no known failure mode-- it does not “wear out.” With a protective cover over the LCD panel the IR touch screen does not reduce LCD panel brightness. -
Page 13: Lcd Display
0, 90, 180 or 270 degrees without any loss of performance. Secondary Display Port A secondary video display is supported on the J2 615 and can be set as the primary or secondary display. Secondary video displays can be configured as a Twin, Intel Dual Display Clone or Extended Desktop. -
Page 14: Usb Ports
Both serial (COM) ports 3 and 4 can be strapped to provide power to external devices. The J2 615 is shipped standard with serial 4 strapped to supply +12 to pin 9 of the DB9 connector. Normally serial port 4 is used for J2’s 2x20 character VFD customer display which gets its power from the serial port. - Page 15 Both serial ports 3 and 4 can have jumpers set to select for either +12 volts or +5 volts. J2 does not recommend using +5 volts devices if it can be avoided, as it is quite easy to damage a +5 volt device by plugging it into a port supplying +12 volts. Most all serial scanners are available in the + 12 volt version.
- Page 16 Pin 8 Pin 5 Pin 10 Pin 9 The J2 Cable Adaptor (supplied) RJ45 to DB25 J2 Serial Pinter Cable Pin-out when using 8 wire CAT5/6 cable RJ45-10 Pin Signal DB25 Signal RJ45- 8 Pin Signal DB25 Signal Pin 1...
-
Page 17: Audio
Audio Line-out Jack Cash Drawer Port The 615 has one cash drawer port that can support one cash drawer directly, or two cash drawers when using a “Y” splitter cable. The “Y” splitter cable is the same type as would be used with an EPSON printer. - Page 18 2) Using the J2 supplied Virtual COM port for CE.NET, XP Pro, POSReady and XPE 3) Direct access to the I/O ports: The Virtual COM port driver that is standard on Windows XP Pro, WEPOS and XP embedded maps the cash drawers to COM 6 and COM7. These COM port numbers can be changed by modifying using the J2 virtual port configuration utility.
-
Page 19: Cmos Reset
SSD) combo is required. This allows for the use of two SATA storage drives in the J2 615. This connector may be used when it is not desirable for the SSD to be easily accessible by the user, maybe for security reasons. (See illustration below) 615 System Manual Version 1.0 March 21, 2010... -
Page 20: Mini Pci-E
802.11n wireless LAN card. Power Supply The J2 615 uses a 65 watt notebook type power supply that is normally mounted in the base of the unit. The power supply is rated with an output of 19 VDC 3.42 Amps and has an input rating of 100-240VAC at 50~60Hz 1.8 Amps maximum. -
Page 21: Typical Power Consumption 615
Power Supply Mounting in Base Typical Power Consumption 615 The typical power consumption of the 615 is much lower that a desktop computer and more comparable to a notebook computer. Using the Intel’s Atom processors and Intel chipset allows for much lower power consumption than previous generations of POS computers. This, when coupled with J2 software power reduction utilities, can greatly reduce the system’s total carbon foot print. Test conditions Voltage: 220VAC 50Hz, measured voltage 240VAC OS: Windows XP Pro Heavy Load Program: Winstress 98% loading Maximum load: Prime95 Temperature: 27c Updated: June 20, 2009 All systems where tested in their standard hard drive configuration. Results are +/‐ 15%. J2 615 1.6 GHz Atom with 1GB Memory, 8GB SSD ... -
Page 22: Packing List
1: System 2: AC Power cord 3: Serial RJ45 to DB9 Adaptor 4: Serial Printer Cable Standard Items 1: System with 2: AC power cord 4: Printer Cable 3: COM Cable (1) 615 System Manual Version 1.0 March 21, 2010... -
Page 23: System Installation
System Installation Counter Top Base The J2 615 is shipped with a counter top base which allows for the head to be adjusted from 0-90°. To remove the integrated head from the base, loosen the thumbscrew located on the back of the unit under the hinge of the counter top base, as shown below. - Page 24 To mount the J2 615 to the base, do the reverse (as shown below): a. attach the panel to the desk mount hinge bracket and slide it into the position, as shown by the red arrows b. Tighten the thumbscrew to finish the installation 615 System Manual Version 1.0 March 21, 2010...
-
Page 25: Optional Vesa / Wall Mount Bracket Installation
The bracket slides on to the J2 615 mount posts, as shown. Normally the bracket would already be mounted to the wall or a VESA mount and the 615 would be hung on the bracket. Once in place the thumb screw would be tightened. -
Page 26: Msr Installation
Connect the cable and tighten the screw c. Slide the MSR into the position and tighten the screws to finish the installation. Be careful not to pitch the cable when installing. 615 System Manual Version 1.0 March 21, 2010... -
Page 27: Ssd/Hhd Access
SSD/HHD Access Loosen the screw Slide the SSD/HDD Module (as shown) 615 System Manual Version 1.0 March 21, 2010... -
Page 28: Removing The Power Supply Adaptor
Removing the Power Supply Adaptor Remove the two screws to release the adaptor and the bracket. (one screw is under plug) 615 System Manual Version 1.0 March 21, 2010... -
Page 29: Bios Settings
The time and date can also be set though the keys to select items and the Enter key to OS. The total memory installed in the system can accept and enter the sub-menu. be seen on this screen also. 615 System Manual Version 1.0 March 21, 2010... - Page 30 This screen shows the current Health readings on be set in this menu. The “PWRON After the J2 615. A Windows based program is PWR-Fail” controls whether the unit will turn available from J2 that can access and display the back on by itself after AC power is lost.
-
Page 31: Driver Installation
Driver Installation Driver Download If you did not purchase your operating system from J2 you may download the drivers for the 615 system from the J2 web site at” http://www.j2retailsystems.com/support/615/. For Windows XP there are five drivers that need to be installed. They are:... -
Page 32: Optional Items
Optional Items The J2 615 computer supports all the same option modules (as shown below) on the J2 580 product, and also includes the UPS (not shown below): VESA/Wall Mount Bracket MSR Module (front swipe) Finger Print / MSR-Finger Print Combo... -
Page 33: Customer Display Option
Customer Display Option Connecting the Cable for a J2 615/580 customer display Cable must be fitted correctly. The end with the shrink sleeve goes into the display, the other end to COM3 or COM4. Normally COM4 power is already enabled on that port. Dip Switch and Software Setting Command Type Selection SW1 SW2 SW3 Command Type Demo Mode Support Default ON ON ON POS7300 ＊... - Page 34 20 ON ON OFF ON ON U.S.A Windows-1251 (Cyrillic) 21 OFF ON OFF ON ON U.S.A Windows-1252 22 ON OFF OFF ON ON U.S.A Windows-1255 (Hebrew) 23 OFF OFF OFF ON ON U.S.A Windows-1257 (Baltic) 615 System Manual Version 1.0 March 21, 2010...
-
Page 35: J2 615/580 Ups
J2 615/580 UPS Specifications Batteries Run Time 1.5 hours for the standard J2 615, run time will vary depending on the application loading Power In 19 Volts DC Power Out 13-16.8 Volts DC, 8 amps maximum Data Interface... -
Page 36: Software Setup In Xp
4: Under Select manufacturer select Generic. Select the COM port you wish to use in the On port drop down menu. Be sure this port is not used for anything else (printer) or the driver will not install. Select model should be Custom. Click Next>. 615 System Manual Version 1.0 March 21, 2010... - Page 37 5: The default values for the Interface Configuration are what the J2 UPS uses, therefore just click Finish. 6: When returned to the Power Options Properties window, click Apply to save the configuration. It will take a number of seconds to configure. Once done the Details should show Manufacturer: Generic and Model: Custom and the UPS and driver should be working.
-
Page 38: Status Led
There is one green status LED on the UPS. This can be viewed when looking into the top of the base, as shown in the picture below: 615/580 UPS STATUS LED Add picture here The status LED can be used to determine what mode the UPS is running in. Please refer...
