Pro1 IAQ T925 Installation Manual page 7

Tech Setup Steps (Continued from the previous page)
Heating Cooling
Temperature Temperature
Setpoint Limit Setpoint Limit
This feature This feature
allows you to set a allows you to set a
maximum heat minimum cool
setpoint value. setpoint value.
The setpoint The setpoint
temperature temperature
cannot be raised cannot be lowerd
above this value. below this value.
LCD Will Show
Adjustment Options
Use the or Use the
key to select the key to select the
maximum heat minmum cool
setpoint. setpoint.
Factory Default Settings
90 ºF 44 ºF
PRO1 Tip
The second stage will turn on at 2x the swing setting. The second stage will turn off when 1x the
swing is reached. For example, if the swing setting is .8 degrees for heating and the thermostat is
set at 70ºF, the first stage will turn on at approximately 69.2ºF. The second stage will turn on at
68.4ºF. The second stage will turn off at 69.2ºF and the first will turn off at 70.8ºF.
ºF or ºC
Select F for
Fahrenheit
temperature read
out or select C for
Celsius read out
or
ºF for Fahrenheit
ºC for Celsius
ºF
TECHNICIAN SETUP MENU
12 or 24 Morning
Hour Clock Recovery
You can select This feature turns your
either a 12 or 24 system on before the
hour clock setting. WAKE programming
time to ensure the
enviroment is at the
WAKE setpoint when
the WAKE time period
begins. This recovery
changes over time
based on the previous
days experience.
Use the or Use the
key to select 12 or 24 key to turn on or off.
hour clock.
12 Hour Clock ON
Program
Options
You can configure this
thermostat to have a
7 day program, a
5+1+1 program or
nonprogrammable.
or Use the or
key to select 7d for 7
day, 5d for 5+1+1,
or 0d for
nonprogammable.
5d
TECH SETUP
STEPS CONTINUED
ON THE NEXT PAGE
Display
Light
The display light can
be configured to
come on when any
key is pressed or
only when the light
key is pressed.
OFF configures
display light to come
on only with the light
key, which will save
battery power.
ON configures the
display light to come
on when any key is
pressed.
ON
7
