Caution:
Electrical Hazard
Failure to disconnect the
power before beginning to
install this product can cause
electrical shock or equipment
damage.
For vertical mount put
one screw top and one
screw bottom.
For horizontal mount put
one screw left and one
screw right.
Horizontal mount
SUBBASE INSTALLATION
UP
C
O
B
W
Vertical mount
Mercury Notice:
All of Pro1's products are
mercury free. However, if the
product you are replacing
contains mercury, dispose of it
properly. Your local waste
management authority can give
you instructions on recycling
and proper disposal.
Vertical mount
RH
Horizontal mount
RC
G
Y
4
