Pro1 IAQ T925 Installation Manual
  1. Manuals
  2. Brands
  3. Pro1 IAQ Manuals
  4. Thermostat
  5. T925
  6. Installation manual
Pro1 IAQ T925 Installation Manual

Pro1 IAQ T925 Installation Manual

True comfort iiii
Hide thumbs Also See for T925:
Table of Contents

Advertisement

Quick Links

See also: Installation Manaul , Operating Manual
This manual covers the following models:
• T925
Thermostat Applications Guide
D
e
s
c
i r
t p
o i
n
Gas or Oil Heat
Electric Furnace
Heat Pump (No Aux. or Emergency Heat)
Heat Pump (with Aux. or Emergency Heat)
Multi-stage Systems
Heat Only Systems
Cool Only Systems
Millivolt

Table of Contents

Thermostat Quick Reference
Mounting and Battery Installation
Una versión española de este
manual puede ser descargada
en www.pro1iaq.com
® U.S. Registered Trademark. Patents pending.
Copyright © 2006 Pro1 IAQ, Inc. All rights reserved.
Power Type
Battery Power
Hardwire (Common Wire)
No
No
Hardwire (Common Wire) with Battery Backup
Yes
Yes
No
No
No
No
Page
2
3
4
5
6, 7, 8
9
10, 11, 12
13
INSTALLATION MANUAL
A trained, experienced technician
must install this product.
Carefully read these instructions. You
could damage this product or cause a
hazardous condition if you fail to follow
these instructions.
Need Help?
For assistance with this product please
visit http://www.pro1iaq.com or call Pro1
Customer Care toll-free at 888-Pro1iaq
(776-1427) during normal business hours
(Mon-Fri 9 AM - 6 PM Eastern)
1
Rev. 0730

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T925 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro1 IAQ T925

Summary of Contents for Pro1 IAQ T925

  • Page 1: Table Of Contents

    (776-1427) during normal business hours Una versión española de este (Mon-Fri 9 AM - 6 PM Eastern) manual puede ser descargada en www.pro1iaq.com ® U.S. Registered Trademark. Patents pending. Copyright © 2006 Pro1 IAQ, Inc. All rights reserved. Rev. 0730...

  • Page 2: Installation Tips

    INSTALLATION TIPS Wall locations The thermostat should be installed approximately 4 to 5 feet above the floor. Select an area with average temperature and good air circulation. Do not install thermostat in locations: • Close to hot or cold air ducts •...

  • Page 3: Getting To Know Your Thermostat

    Getting to know your thermostat Important: The low battery indicator is displayed when the AA battery power is low. If the user fails to replace the battery within 21 days, the thermostat display will only show the low battery indicator as a final warning before the thermostat becomes inoperable.

  • Page 4: Subbase Installation

    SUBBASE INSTALLATION Caution: Mercury Notice: Electrical Hazard All of Pro1’s products are mercury free. However, if the Failure to disconnect the product you are replacing power before beginning to contains mercury, dispose of it install this product can cause properly. Your local waste electrical shock or equipment management authority can give damage.

  • Page 5: Wiring

    WIRING Caution: Electrical Hazard Warning: Failure to disconnect the power All components of the control before beginning to install this system and the thermostat product can cause electrical installation must conform to shock or equipment damage. Class II circuits per the NEC Code. Wiring If you are replacing a thermostat, make note of the terminal connections on the...

  • Page 6: Technician Setup Menu

    TECHNICIAN SETUP MENU Technician Setup Menu This thermostat has a technician setup menu Configure the installer options as desired using the table below. for easy installer configuration. To set up the thermostat for your particular application: Use the keys to change settings and the NEXT STEP or PREV Press MENU button STEP key to move from one option to...
  • Page 7 TECHNICIAN SETUP MENU Tech Setup Steps (Continued from the previous page) Heating Cooling ºF or ºC 12 or 24 Morning Program Display Temperature Temperature Hour Clock Recovery Options Light Setpoint Limit Setpoint Limit The display light can This feature This feature You can select This feature turns your You can configure this...
  • Page 8 TECHNICIAN SETUP MENU Tech Setup Steps (Continued from the previous page) Contractor Beep System Gas Auxiliary Call Number Switch for Heat Pump Allows you to put your When any key is You can configure the If Emergency Heat is phone number in the pressed an audible system switch for the seleted ON you will...
  • Page 9 MOUNT THERMOSTAT & BATTERY INSTALLATION Mount Thermostat Align the 4 tabs on the subbase with corresponding slots on the back of the thermostat, then push gently until the thermostat snaps in place. On the back of the thermostat insert 2 AA Alkaline batteries (included).

  • Page 10: Programming The Thermostat

    PROGRAMMING THE THERMOSTAT Set Time Follow the steps below to set the day of the week and current time: Press MENU Press SET TIME Day of the week will be flashing. Use the key below the time setting to select the current day of the week.
  • Page 11 PROGRAMMING THE THERMOSTAT You can use the table below to plan your customized program schedule if using 5+1+1. Programming Table Setpoint Setpoint Day of the Events Time Temperature (Cool) Temperature (Heat) Week Weekday Wake Leave Return Sleep Saturday Wake Leave Return Sleep Sunday...
  • Page 12 PROGRAMMING THE THERMOSTAT To customize your 7 day program schedule, follow these steps: Select HEAT or COOL using the SYSTEM key. You have to program heat and cool each separately. Press MENU Press SET SCHEDULE Note: Monday is displayed and the WAKE icon is shown. You are now programming the WAKE time period for the Monday setting.

  • Page 13: Specifications

    SPECIFICATIONS & CONTACT INFORMATION Specifications The display range of temperature 41ºF to 95ºF (5ºC to 35ºC) The control range of temperature 44ºF to 90ºF (7ºC to 32ºC) Load rating 1 amp per terminal, 1.5 amp maximum all terminals combined Display accuracy ±...
