PARTS & DESCRIPTION*
1
Bottom Case
2
Camera Gimbal
Upper Case
3
Dome Cover
4
5
Cover Screws (x4)
Side Port for Cabling
6
6
2
7
BNC Cable
8
DC12V Cable
9
UTP Cable
10
RS485 Cable
11
Alarm Output Cable
9
8
10
11
7
1
3
4
5
5
