Domestic Dishwasher
SERVICE MANUAL
Models
DWI 5212P
Features
Programme control, four program for select
Water softening function is provided which can prevent incrustation
A grade for energy consumption of European standard EN50242
B grade for washing efficiency of European standard EN50242
B grade for drying efficiency of European standard EN50242

Advertisement

Table of Contents
loading

Related Manuals for Proline DWI 5212P

Summary of Contents for Proline DWI 5212P

  • Page 1 Domestic Dishwasher SERVICE MANUAL Models DWI 5212P Features Programme control, four program for select Water softening function is provided which can prevent incrustation A grade for energy consumption of European standard EN50242 B grade for washing efficiency of European standard EN50242...

  • Page 2: Table Of Contents

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Contents 1.Features ……………………………………………………………………………………… 3 2.Safety Precaution ………………………………………………………………..…………… .4 3.Net dimension ………………………………………………………………………………… .5 4.Installation and Accessory Parts ……………………………………………….……………..5 5.Parts and Functions ……………………………………………………………...…………….7 6.Function Schedule………………………………………………………………...…….…..…10 7.Program Diagram………………………………………………………………….….………...11 8.Maintenances Services and Trouble Shooting………………………………………………12 9.Circuit Diagram ………………………………………………………………………….……..19...

  • Page 3: Features

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 1.Features 1.1 Programme control, four program for select 1.2 Water softening function is provided which can prevent incrustation forming 1.3 A grade for energy consumption of European standard EN50242 1.4 B grade for washing efficiency of European standard EN50242 1.5 B grade for drying efficiency of European standard EN50242...

  • Page 4: Safety Precaution

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 2.Safety Precaution IMPORTANT Carefully read the instructions contained in this manual, as it provides information that is essential to safe and proper installation, use and maintenance of this appliance. This appliance complies with following EEC directives: -73/23/EEC of 19/02/73(Low Voltage)and subsequent modifications;...

  • Page 5: Net Dimension

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 3.Net dimension 4.Installation and Accessory Parts 4.1 Mounting the Wooden Panel onto the Door and Sliding the Dishwasher into the Cabinet During the preparatory stages for installing the dishwasher into the kitchen cabinet, holes must not be drilled in the sides, or door, in order to avoid compromising the performance and/or operation of the appliance.
  • Page 6 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 4.5 Adjusting the Door Springs (Fig.10B) The door must be perfectly balanced. In the factory, the tension of the springs is regulated to ensure that the door is perfectly balanced when light wood door panels are mounted on the door. If heavier, solid wood door panels are used, the door can be balanced by simply turning the two screws (both screws must be turned the same amount) located on the top part of the machine.

  • Page 7: Parts And Functions

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P system,heating system),as long as it does not exceed a temperature of 60º. In this case,the wash cycle time will be shortened by about 15 minutes and the wash efficiency slightly reduced.
  • Page 8 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P A. Upper Rack B. Top Spray Arm C. Lower Rack D. Bottom Spray Arm E. Washing Filter F. Detergent and Rinse Aid Dispenser G. Salt Container Cap Salt The hardness of the water varies from place to place. If hard water is used in the shwasher,deposits will form on the dishes utensils.
  • Page 9 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Loading the detergent To open the "A" cover on the dispenser,press the "B" button.The detergent for the wash cycle should be poured into the "C" compartment. After the detergent has been placed in the dispenser, close the cover and press down until it clicks in place.

  • Page 10: Function Schedule

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 6.Function Schedule Intensive wash 1、 Hot Pre-wash Cold rinse 70℃Main-wash 38min Cold rinse 6 min Hot rinse 24min Drying 19min Normal wash 2、 Pre-wash Pre-wash 9min 50℃Main-wash 55min Hot rinse-65℃...

  • Page 11: Program Diagram

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 7.Program Diagram Cycle Cycle Selection Information Description of Cycle Detergent Rinse Aid Very dirty dishes, pots and Pre-wash with hot water. pans. (Not to be used with Extended wash at 70℃.

  • Page 12: Maintenances Services And Trouble Shooting

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 8.Maintenances Services and Trouble Shooting 8.1Maintenances Services It may occur that the dishwasher does not function or does not function properly Before calling for assistance,Iet us see what can be done first :have you forgotten to press one of the buttons or to perfom an essential operation? 8.2 Trouble Shooting...
  • Page 13 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Analysis of the common breakdowns. Door switch trouble Phenomenon: the dishwasher does not work Whether door is closed Close the door check if door flap is OK Replace it Dismantle the door case and using...
  • Page 14 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P water supply trouble Phenomenon: water level cannot reach the required location Whether water is flowing in the hose Turn on the stopcock Whether the stopcock is turned on Whether solenoid valve...
  • Page 15 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Drain pump trouble Phenomenon: water cannot be drained Whether drain pump is working Whether drain pump is electrified Whether the pipeline and drain pump was blocked The drain hose is too...
  • Page 16 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Heating trouble Phenomenon: program controller stop turnning Whether socket connector is connected well Connect it well Whether thermo limiter is change thermo limiter Whether heater is OK change heater Program...
  • Page 17 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Water overflow trouble Phenomenon: drain pump keep on working Whether water Whether water flows out of deposited is the bottom the water overflow conduit Bottom case is leaking Check whether the water...
  • Page 18 Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P Power supply trouble Phenomenon: dashwaser cannot work check whether the power connector Connect it properly check whether the power connector is in position is in position check whether the circuit...

  • Page 19: Circuit Diagram

    Serial Number: FA01M0E0G00 Version:00.00 Edition: 2006-6 Dishwasher Model: DWI 5212P 9.Circuit Diagram Page 19 / 19...
