Summary of Contents for Touch Dynamic Breeze

  • Page 1 User Manual Revision v1.3 June 2010 Breeze All-in-one Hardware System...
  • Page 2 Copyright 2010 All Rights Reserved Manual Version 1.3 Part Number: 3LMPP3500113 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine.

  • Page 4: Legislation And Weee Symbol

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.

  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Version Date Description 2008 July Initial release  B78 M/B Upgraded from v2.1 to 2.2  B98 V1.0 M/B information Added  Second display installation added  FAN of B98 MB added ...

  • Page 6: Table Of Contents

    Table of Contents 1 Item Checklist ...........1 Standard Item ................1 Optional Item ................2 2 System View ..........3 Front View..................3 Rear View with stand ..............4 Rear View without stand............... 4 Side View..................5 Bottom View.................. 5 I/O View ..................6 3 System Dimensions .........7 15”...

  • Page 7: Item Checklist

    Item Checklist Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: Standard Item a. System b. Driver CD c. User Guide d.

  • Page 8: Optional Item

    Optional Item The touch terminal device provides various peripheral options for your selection. Please refer to your local sales representative or distributor for further information. a. MSR Module b. MSR + iButton Module c. MSR + Fingerprint Module d. VFD Customer Display (with RJ45 cable) e.

  • Page 9: System View

    System View Front View Description Touch MSR (optional) Stand (with power brick and cable management) I/O Ports Stand hole for cables outlet - 3 -...

  • Page 10: Rear View With Stand

    Rear View with stand Rear View without stand Description Display (Optional) Ventilation holes HDD Door VFD dummy cover Ventilation holes VESA holes (100x100mm) Thumbscrew hole for stand / wall-mount bracket Handle of Motherboard - 4 -...

  • Page 11: Side View

    Side View Description Speaker outlet Stand hinge cover (at both sides) Bottom View Description Rubber foot Holder bracket for power brick - 5 -...

  • Page 12: I/O View

    I/O View Description Power Switch PS/2 USB (x4) e / m Thumbscrews for fixing the motherboard DC-IN (19V) Cash Drawer MIC-in Line-out COM 1, 2, 3, 4 Parallel - 6 -...

  • Page 13: System Dimensions

    System Dimensions 15” System Dimensions 17” System Dimensions - 7 -...

  • Page 14: Peripheral Installation

    Peripheral Installation VFD Installation The VFD requires 12V power and must be connected to a powered COM port (COM3 or COM4). Please refer to chapter 7-1-3 (B78 motherboard, jumper JP3), chapter 7-2-3 (B98 motherboard, jumper JP5), Chapter 7- 3-3 (B68 motherboard, jumper JP3), and Chapter 7-4-3 (C48 motherboard, jumper JP7) for correct jumper setting.

  • Page 15: Second Display Installation

    Second Display Installation  Accessories: display VGA Cable x 1 Screw x 2  Installation Procedure: display System stand Thread two ends of the cable respectively through the upper and the lower gap on the 2 display on the bracket. Align the boss on 2 display to the holes on the bottom of the system stand.
  • Page 16 Fasten the 2 display stand with the screws (x2), and connect cable to 2 display. Route VGA cable through stand gap and connect the other end of the cable to the system port. - 10 -...

  • Page 17: Power Cord Installation

    Power Cord Installation The Power brick is installed in the metal bracket fixed in the stand gap. Connect the Power cord to the power adapter. Route through the base gap for cable management - 11 -...

  • Page 18: Msr / 2-In-1 Msr Installation

    MSR / 2-in-1 MSR Installation There are 3 kinds of MSR and 2-in-1 MSR modules available at your request. You may request for further information in your local distributor or sales representative. The 3 MSR modules are: 1. MSR Reader 2.

  • Page 19: Cash Drawer Installation For B78 Motherboard

    Cash Drawer Installation for B78 Motherboard You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 20 Bit 7: Reserved. Bit 6: Reserved. Bit 5: Reserved. Bit 4: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer. = 0: the Cash Drawer opened. Bit 3: Reserved. Bit 2: Cash Drawer “DOUT bit0” pin output control. = 1: Opening the Cash Drawer = 0: Allow closing the Cash Drawer Bit 1: Cash Drawer “DOUT bit1”...

  • Page 21: Cash Drawer Installation For B98/B68/C48 Motherboard

    Cash Drawer Installation for B98/B68/C48 Motherboard You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 22 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 23: Vesa Wall-Mount Kit Installation

    VESA Wall-Mount Kit Installation If you want to mount the POS terminal on the wall, please order the wall mount kit from you distributor and follow the steps below for the installation  Wall-mount kit accessory:  Installation procedure: Remove the stand by loosening the thumb screw (x1). Place the wall mount bracket on the rear cover and tighten the screw (x1).

  • Page 24: Stand Assembly & Disassembly

    Stand Assembly & Disassembly Stand Assembly Slide the VESA hinge bracket into the metal hinge shaft on the stand. Fasten the screws (x6) ( 3 on both sides) to fix the VESA hinge bracket onto the stand. Use rubber hinge cover to plug the holes on both sides. - 18 -...

  • Page 25: Stand Disassembly

    Align larger end of the teardrop mounting holes on the VESA hinge bracket with fixing screws (x4) on the rear cover of the system. Slide to narrow end of the mounting holes, and stick the bracket to the system. Push and fasten the thumb screw to fix it to the system. Stand Disassembly Loosen the thumb screw.

  • Page 26: System Assembly & Disassembly

    System Assembly & Disassembly HDD Replacement Remove the screw (x1) to open the HDD door. Disconnect the HDD cable (x1). Replace the HDD. Compact Flash Card Replacement If the system is equipped with CF (Compact Flash) slot as storage device, please follow the following steps to replace CF card.

  • Page 27: Power Adapter Replacement

    Power Adapter Replacement Route the adapter cable from the hole of cable management of the stand. Disconnect the power cord from the adapter. Loose the screws (x2) to disassemble the power adapter holding bracket and the adapter. - 21 -...

  • Page 28: Specification

    Specification B78 Motherboard Motherboard Model/System 15” System 17” System POS355 Fanless: Intel Celeron M ULV 1.0GHz (BGA) POS355 with cooler: Intel Celeron M 1.5GHz / Pentium M 1.8GHz POS357 with cooler : Intel Celeron M ULV 1.0GHz (BGA) Intel Celeron M 1.5GHz Pentium M 1.8GHz Chipset Intel 852GM + ICH4 FSB 400MHz...
  • Page 29 Motherboard Model/System 15” System 17” System Cash Drawer Port 1 to support 12V /24V cash drawer Audio Jack 1 x Line-out, 1 x MIC-in Audio Built in Speaker 2 x 2W speakers Power Power Adapter 19V/90W Control / Indicator Power Button Indicator LED Peripheral 3 Tracks MSR ( PS/2 )

  • Page 30: B98 / B68 / C48 Motherboard

    B98 / B68 / C48 Motherboard Motherboard Intel Celeron M 1.86G/ Core Intel Atom N270 1.6G Intel Atom D510 dual core 1.66G/ CPU Supports FSB 533Mhz, Core 2 duo FSB 533MHz D525 dual core 1.8G 1.66G FSB667Mhz Chipset Intel 945GME + ICH7M Intel 945GSE + ICH7M CPU with Graphic built-in + ICH 8M 2 x DDR2 DIMM socket up to...
  • Page 31 Motherboard Audio Built in Speaker 15": 2 x 2W speakers, 17": 2 x 3W speakers Power Power Adapter 19V/90W Control / Indicator Power Button Indicator LED Peripheral 3 Tracks MSR ( PS/2 ) MSR (PS/2) / Fingerprint (USB), 2-in-1 MSR MSR (PS/2)/ I-button (PS/2) Second Display optional 8.4"...

  • Page 32: Jumper Settings

    Jumper Settings This chapter describes the connector with function description and jumper settings for motherboard B78 v2.2 and B98 v1.0 and B68v 1.0 and C48 v1.0. B78 Motherboard 7-1-1 B78 Motherboard Layout - 26 -...
  • Page 33 7-1-2 B78 Connector and function Connector Function CN11 Power Connector For 3.5" HDD CN13 COM5 for Touch CN15 CPU FAN Connector CN19 LCD Interface Connector CN20 Inverter Connector CN21 Card Reader Connector CN22 System FAN Connector VGA Port VGA Power Power Option for COM3/COM4 Cash Drawer Power Setting Power Mode Setting...
  • Page 34 7-1-3 B78 Jumper settings 1. COM2 RS232/485/422 Setting Function JP10 (1-2) (3-4) (5-6) (7-8) (9-10) (11-12) (1-2) (3-4) (4-6) (5-7) (7-8) (9-10) ▲RS232 RS485 RS422 ▲ = Manufacturer Default Setting - 28 -...
  • Page 35 2. COM3 & COM4 Power Setting Function (1-2) (3-4) (5-6) (7-8) (9-10) (11-12) ▲RI COM3 Pin10 +12V ▲RI COM4 Pin10 +12V ▲ = Manufacturer Default Setting - 29 -...
  • Page 36 3. Cash Drawer Power Setting Function (1-2) (3-4) (5-6) +12V ▲+19V ▲ = Manufacturer Default Setting 4. LCD ID Setting LVDS Panel # Resolution (1-2) (3-4) (5-6) (7-8) Bits Channel Single Single 1024 Single 1280 1024 Dual 1024 Single - 30 -...
  • Page 37 LVDS Panel # Resolution (1-2) (3-4) (5-6) (7-8) Bits Channel Single Single Single 1024 Single 1440 Dual 1280 1024 Dual 1440 Dual Remark: Panel ID #8 is only applied for Sharp 12” LQ121S1LG41 / LQ121S1LG42 panel. - 31 -...
  • Page 38 5. Power Mode Setting Function (1-2) ▲ATX Power AT Power 6. CMOS Operation Mode Function (1-2) ▲CMOS Normal CMOS Reset 7. USB Path Setting Function JP14 (1-2) ▲To Docking To MB ▲ = Manufacturer Default Setting - 32 -...

  • Page 39: B98 Motherboard

    B98 Motherboard 7-2-1 B98 Motherboard layout - 33 -...
  • Page 40 7-2-2 B98 Connector and function Connector Purpose CN12 LCD Interface Connector CN14 Inverter Connector CN15 COM5 for Touch CN16 Power Connector For HDD SKT1 SPI ROM Cash Drawer Power Setting JP4 / 6 COM2 RS232/485/422 Setting Power Option for COM3/COM4 CMOS Reset LCD Panel ID VGA Port...
  • Page 41 7-2-3 B98 Jumper Setting COM2 RS232/485/422 Setting Function (1-2) (3-4) (5-6) (7-8) (9-10) (11-12) (1-2) (3-4) (4-6) (5-7) (7-8) (9-10) ▲RS232 RS485 RS422 ▲ = Manufacturer Default Setting - 35 -...
  • Page 42 2. COM3 & COM4 Power Setting Function (1-2) (3-4) (5-6) (7-8) (9-10) (11-12) ▲RI COM3 Pin10 +12V ▲RI COM4 Pin10 +12V ▲ = Manufacturer Default Setting - 36 -...
  • Page 43 Cash Drawer Power Setting Function (1-2) (3-4) 5-6) +12V ▲+19V ▲ = Manufacturer Default Setting 4. Power Mode Setting Function JP11 (1-2) ▲ATX Power AT Power 5. CMOS Operation Mode Function (1-2) ▲CMOS Normal CMOS Reset ▲ = Manufacturer Default Setting Note: OPEN SHORT...
  • Page 44 6. LCD ID Setting LVDS Output Panel # Resolution Interface (1-2) (3-4) (5-6) (7-8) Bits Channel 1366 x 768 Single LVDS 1440 x 900 Dual LVDS 1920 x 1080 Dual LVDS 1024 x 768 Single LVDS 1280 x 1024 Dual LVDS 800 x 600 Single...
  • Page 45 Remark: Panel ID #12 is only applied for Sharp 12” LQ121S1LG41 / LQ121S1LG42 panel. Note: OPEN SHORT - 39 -...

  • Page 46: B68 Motherboard

    B68 Motherboard 7-3-1 B68 Motherboard Layout B68v 1.0 - 40 -...
  • Page 47 7-3-2 B68 Connector and Function Connector Purpose SATA1 HDD Power Connector SATA2 HDD Power Connector LCD Interface Connector SATA1 SATA Connector SATA2 SATA Connector SKT1 SPI ROM CRT Connector Power Option for COM3/COM4 Display Power JP5 / 6 COM2 RS232/485/422 Setting LCD Panel ID RTC Reset AT Function...
  • Page 48 7-3-3 B68 Jumper Setting COM2 RS232/485/422 Setting Function (1-2, 3-4, 4-6, 5-6, 7-8, 9-10) (1-2, 3-4, 5-6, 7-8, 9-10, 11-12) ▲RS232 RS485 RS422 ▲ = Manufacturer Default Setting 8. Cash Drawer Power Setting Function JP11 (1-2, 3-4) ▲+12V +19V - 42 -...
  • Page 49 9. COM3 & COM4 Power Setting Function (1-2, 3-4, 5-6, 7-8, 9-10,11-12) ▲RI COM3 Pin30 +12V ▲RI COM4 Pin40 +12V ▲ = Manufacturer Default Setting 10. Power Mode Setting Function (1-2) ▲ATX Power AT Power - 43 -...
  • Page 50 11. CMOS Operation Mode Function (1-2) ▲CMOS Normal CMOS Reset 12. VGA Power Setting Function (1-2) ▲No Power +12V ▲ = Manufacturer Default Setting 13. LCD ID Setting LVDS Output Panel # Resolution Interface (1-2) (3-4) (5-6) (7-8) Bits Channel 1366 x 768 Single LVDS...
  • Page 51 LVDS Output Panel # Resolution Interface Bits Channel (1-2) (3-4) (5-6) (7-8) 1280 x 1024 Dual LVDS 800 x 600 Single LVDS 1024 x 768 Single LVDS 800 x 600 Single LVDS 800 x 600 Single LVDS Remark: Panel ID #12 is only applied for Sharp 12” LQ121S1LG41 / LQ121S1LG42 panel.

  • Page 52: C48 Motherboard

    C48 Motherboard 7-4-1 C48 Motherboard Layout - 46 -...
  • Page 53 7-4-2 C48 Connector and Function Connector Purpose Power Connector For HDD Power Connector For HDD CN19 Internal Power LED CN26 LCD Interface Connector CN27 Inverter Connector SATA1 SATA Connector SATA2 SATA Connector SKT1 SPI ROM Power On Button CMOS Reset Power Option for COM3/COM4 VGA Port JP4/5...
  • Page 54 7-4-3 C48 Jumper Setting COM2 RS232/485/422 Setting Function (1-2, 3-4, 4-6, 5-7, 7-8, 9-10) (1-2, 3-4, 5-6, 7-8, 9-10, 11-12) ▲RS232 RS485 RS422 ▲ = Manufacturer Default Setting 2. Cash Drawer Power Setting Function JP11 (1-2, 3-4) +12V ▲+19V - 48 -...
  • Page 55 3. COM3 & COM4 Power Setting Function (1-2, 3-4, 5-6, 7-8, 9-10,11-12) ▲RI COM3 Pin10 +12V ▲RI COM4 Pin10 +12V ▲ = Manufacturer Default Setting 4. Power Mode Setting Function (1-2) ▲ATX Power AT Power - 49 -...
  • Page 56 5. CMOS Operation Mode Function (1-2) ▲CMOS Normal CMOS Reset 6. VGA Power Setting Function (1-2) No Power ▲+12V ▲ = Manufacturer Default Setting 7. LCD ID Setting Panel # Resolution LVDS Output Interface Bits Channel (1-2) (3-4) (5-6) (7-8) x 600 Single LVDS...
  • Page 57 Panel # Resolution LVDS Output Interface (1-2) (3-4) (5-6) (7-8) Channel x 600 Single LVDS x 600 Single LVDS 1024 x 768 Single LVDS Remark: Panel ID #6 is only applied for Sharp 12.1” LQ121S1LG41 / LQ121S1LG42 panel. Note: OPEN SHORT - 51 -...
  • Page 58 14. System Reset Function JP12 (1-2) ▲System Normal System Reset 15. Inverter Selection Function JP14 (1-2) ▲CCFL ▲ = Manufacturer Default Setting - 52 -...

  • Page 59: Appendix A: Drivers Installation

    Appendix A: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.

  • Page 60: Appendix B: Vfd Customer Display

    Appendix B: VFD Customer Display 1. Specification Item Description Display method Vacuum fluorescent display Number of characters 40 characters (20 columns x 2 lines) Character font 5 x 7 Dot matrix Display color Blue green Brightness 700 cd /m 96 alphanumeric Character type 25 international character sets Character size...
  • Page 61 2. Interface Serial Data transmission Asynchronous Synchronization MARK = -3 to –15 V (logic “1”) Signal level SPACE = +3 to +15 V (logic “0”) Baud rates 4800, 9600, 19200, 38400 bps Parity None, even 8 bits Bit length 1 bit Stop bits 3.
  • Page 62 1.4. Command Control SW12 Function Depends on SW1~SW11 setting Bypass SW1~SW11 setting, fixed at:  Command type: POS7300, Baud rate: 9600   Parity check: None-parity  Demo mode: Disable - 56 -...
  • Page 63 1.5. International Character Set Code Table Character Set Default Note (20h – 7Fh) (80H-FFH) CP-437 ON OFF U.S.A. ＊ (USA, Standard Europe) OFF ON ON OFF FRANCE ON OFF ON ON OFF GERMANY OFF OFF ON ON OFF U.K. CP-858 ON OFF ON OFF DENMARK I (Multilingual + Euro Symbol) OFF ON OFF ON OFF SWEDEN...
  • Page 64 4. Software Status Setting Commands When the system is powered on, the VFD will read the DIP switches to set the Command Type, Baud Rate, Parity, and International Character set. The user can change the settings as follows: 1.6. Baud Rate Setting Command STX 05 B n /Change the baud rate setting/ ASCII Format...
  • Page 65 1.8. International Character Set Setting Command STX 05 S n /Change the international character set/ ASCII Format STX 05 S n ETX Dec. Format [02] [05] [83] n [03] 30h≦n≦4Fh Hex. Format [02h][05h][53h] n Description Change the display international character font. Character Set Code Table Note...
  • Page 66 1.9. Command Type Setting Command STX 05 C n /Change the command type setting/ ASCII Format STX 05 C n ETX Dec. Format [02] [05] [67] n [03] 30h≦ n ≦37h Hex. Format [02h][05h][43h] n Description This command will change the command type and initialize the display.
  • Page 67 5. Command List Table Command List Table – 1 EPSON POS7300 CD5220 UTC/S UTC/P AEDEX ADM788 DSP800 D101 Move cursor right Move cursor left Move cursor up Move cursor down Move cursor to right-most position Move cursor to left-most position Move cursor to home position Move cursor to bottom position Move cursor to specified...
  • Page 68 EPSON POS7300 CD5220 UTC/S UTC/P AEDEX ADM788 DSP800 D101 Cursor on/off Change to UTC enhanced mode Change to UTC standard mode Write string to upper line Command List Table – 2 EPSON POS7300 CD5220 UTC/S UTC/P AEDEX ADM788 DSP800 D101 Upper line message continuous scroll Bottom line message scroll...
  • Page 69 EPSON POS7300 CD5220 UTC/S UTC/P AEDEX ADM788 DSP800 D101 Clear field 1 and move cursor to field 1, first position Clear field 2 and move cursor to field 2,first position Clear display range from n position to m position and move cursor to n position Save the current displaying data to n layer for demo display...
  • Page 70 6. Command Details POS7300 Series Command List 6.1. POS7300 Standard Mode Command List-1 Command Code (hex) Function Description ESC F A [DATA] Write string to upper line 1B 46 41 [DATA] 0D  Maximal [DATA] length is 40 Write string to lower line ESC F B [DATA] 1B 46 42 [DATA] 0D ...
  • Page 71 Command Code (hex) Function Description NULL H 0 48 Move cursor up NULL K 0 4B Move cursor left NULL M 0 4D Move cursor right NULL P 0 50 Move cursor down NULL G 0 47 Move cursor to left-most position NULL O 0 4F Move cursor to right-most position...
  • Page 72 CD5220 Standard Mode Command List 6.2. CD5220 Standard Mode Command List-1 Command Code (hex) Function Description ESC DC1 1B 11 Overwrite mode US SOH 1F 01 ESC DC2 1B 12 Vertical scroll mode US STX 1F 02 ESC DC3 1B 13 Horizontal scroll mode US ETX 1F 03...
  • Page 73 Command Code (hex) Function Description  n = 00h ~ FFh  n = 0 for no blink Move cursor to specified position ESC I x y 1B 6C x y  x = 1 ~ 14h, for columns location. US $ x y 1F 24 x y ...
  • Page 74 Note: 1. While using command “ESC Q A” or “ESC Q B”, other commands cannot be used except when using command “CLR” or “CAN” to change operating mode. 2. When using command “ESC Q D”, the upper line message will scroll continuously until a new command is received, it will then clear the upper line and move the cursor to the upper left-end position.
  • Page 75 Parameter “n” character Code Table Character ‘E’ Windows-1250 (East European Latin) - 69 -...
  • Page 76 UTC Standard Mode Command List 6.3. Command Code (hex) Function Description Back space Horizontal tab Line feed Carriage return Display position DLE n 10 n  n = 0 ~ 27h, for location. Over write display mode Vertical scroll mode Cursor on Cursor off Clear display...
  • Page 77 AEDEX/EMAX Mode Command List 6.5. Command Code (hex) Function Description Upper line message scroll ! # 4 [DATA] CR 21 23 34 [DATA] 0D  Maximal [DATA] length is 40 ! # 5 h h : m m Display time 21 23 35 h h ':' m m 0D ...
  • Page 78 DSP800 Mode Command List 6.7. Command Code (hex) Function Description Select international character set EOT SOH I n ETB 04 01 49 n 17  n = 00 ~ 0Fh or 30 ~ 3Fh Move cursor to specified position EOT SOH P n ETB 04 01 50 n 17 ...
  • Page 79 EPSON ESC/POS Command List 6.8. EPSON ESC/POS Command List-1 Command Code (hex) Function Description Select/cancel reverse character. US r n 1F 72 n  n = 00,01 US MD1 1F 01 Specify overwrite mode. US MD2 1F 02 Specify vertical scroll mode. US MD3 1F 03 Specify horizontal scroll mode.
  • Page 80 Command Code (hex) Function Description  n = a displayable character code Set starting/ending position of macro definition. US : 1F 3A Ex.: 1F 3A … (macro string) … 1F 3A US @ 1F 40 Execute self - test Display time 0 ≦...
  • Page 81 EPSON ESC/POS Command List-2 Command Code (hex) Function Description Execute and quit macro. It’s an interval of n between the two words. It’s an interval of m between the two strings.  00 ≦ (n, m) ≦ FFh US ^ n m 1F 5E n m ...
  • Page 82 2. Select character code table (80H~FFh) by command “ESC t n” Character code table Character code table Character code table CP-437 7h Russia Fh Windows-1257 (Baltic) (USA, Standard Europe) Windows-1252 1h Katakana (for Japan) 8h Greek (West European Latin) 2h CP-850 (Multilingual) 9h CP-852 (Hungary) 11h Windows-1253 (Greek) Windows-1250...
  • Page 83 7. Character Set Character Code 20H – 7FH 7.1. 7.1.1. International Character Sets Character Code Number Hex 23 Country Dec 35 ¦ U.S.A à ° ç § é ù è ¨ France § Ä Ö Ü ä ö ü β Germany £...
  • Page 84 7.1.2. USA, Standard Character Sets 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh “ $ % & ‘ < > @ A B C D E F G H Q R S T U V W X Y ¦...
  • Page 85 7.2.2. CP-850 (Multilingual) 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh Ç ü é â ä à å ç ê ë è Ä Å ï î ì É æ Æ ô ö ò...
  • Page 86 7.2.4. Katakana for Japan 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh α β γ ⊿ є η θ λ μ π ρ σ τ Ф Ω ∑ £ § IE IR ∫...
  • Page 87 7.2.6. Russia 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh А Б В Г Д Е Ж З и Й К Л М Н О П Р С Т У Ф Х Ц Ч Ш Щ Ъ Ы Ь...
  • Page 88 7.2.8. Greek 00h 01h 02h 03h 04h 05h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh Α Β Γ Δ Ε Ζ Η Θ Ι Κ Λ Μ Ν Ξ Ο Π Ρ Σ Τ Y Φ Х Ψ Ω...
  • Page 89 7.2.10. CP-862 (Hebrew) 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh ‫ן‬ ‫א‬ ‫ב‬ ‫ג‬ ‫ד‬ ‫ה‬ ‫ו‬ ‫ז‬ ‫ח‬ ‫ט‬ ‫י‬ ‫ך‬ ‫כ‬ ‫ל‬ ‫ם‬ ‫מ‬ ‫נ‬ ‫ס‬ ‫ע‬ ‫ף‬ ‫פ‬ ‫ץ‬...
  • Page 90 7.2.12. CP-865 (Nordic) 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh Ç ü é â ä à å ç ê ë è ï î ì Ä Å É æ Æ ô ö ò...
  • Page 91 7.2.14. Windows-1250 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh € ‚ „ … † ‡ ‰ Š ‹ Ť Ž Ź Ś ‘ ’ “ ” • – — ™ š ›...
  • Page 92 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh € ‚ ƒ „ … † ‡ ˆ ‰ Š ‹ Œ Ž ‘ ’ “ ” • – — ˜ ™ š › œ...
  • Page 93 00h 01h 02h 03h 04h 05h 06h 07h 08h 09h 0Ah 0Bh 0Ch 0Dh 0Eh 0Fh € ‚ ƒ „ … † ‡ ˆ ‰ ‹ ‘ ’ “ ” • – — ˜ ™ › ¡ ¢ £ ₪ ¥ ¦...
  • Page 94 8. Command Details A.1. Overwrite mode In this mode, the cursor will move towards the right and begin from the upper left position. When the cursor has reached the end of the upper line, the cursor will move down to the bottom left position to continue.
  • Page 95 A.7. Move cursor right Move the cursor to the right. When the cursor has reached the right-end, this command operates differently depending on the display mode.  Overwrite mode: When the cursor has reached the right-end of the lower line, it will continue to the left-end of the upper line and overwrite previous characters.
  • Page 96 A.14. Move cursor to specified position The cursor will be moved to column x on line y. A.15. Initialize display The data in the input buffer will be cleared and reset from default. A.16. Reset the window Reset the window on the display. When s=0, the window is cancelled (values: x1, x2, and y are not required.) When s=1, the window will be reset (values: x1, x2, and y are required.) The x1 and x2 set the position of the left column and right column, respectively, of the...
  • Page 97 9. Control Code Set CODE CODE NULL SOH, MD1 STX, MD2 ETX, MD3 EOT, MD4 ENQ, MD5 ACK, MD6 BEL, MD7 BS, MD8 VT, HOM FF, CLR SO, SLE1 RS, SF1 SI, SLE2 US, SF2 - 91 -...
