- Page 1 USER MANUAL VERSION 1.3 JANUARY 2011 Jupiter PC...
-
Page 2: Important Safety Instructions
Copyright 2011 All Rights Reserved Manual Version 1.3 Part Number: The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. - Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
-
Page 4: Legislation And Weee Symbol
LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life. -
Page 5: Revision History
Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release 2009 March • B68 motherboard added 2009 December • Jumper setting updated • C48 motherboard added • Specification updated • B68, B98 Jumper Setting updated 2010 October •... -
Page 6: Table Of Contents
Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........1 2. System View ......2 2-1. Front and Side View ..........2 2-2. I/O view ..............3 2-3. Dimensions ..............3 3. Components Replacing ... 4 3-1. RAM Module Replacing ...........4 3-2. - Page 7 5. Jumper Setting ......13 5-1. For C48 Motherboard ..........13 5-1-1. Motherboard Layout ..........13 5-1-2. Connectors & Functions .......... 14 5-1-3. Jumper Setting ............15 5-2. For B68 Motherboard ..........18 5-2-1. Motherboard Layout ..........18 5-2-2. Connectors & Functions .......... 19 5-2-3.
-
Page 8: Packing List
Packing List 111. Standard Accessories System box Power Cord RJ45 to DB9 cable Driver bank 112. Optional Accessories WLAN Card + internal antenna pSSD card module pSSD Card... -
Page 9: System View
System View 211. Front and Side View Power adapter holding bracket HDD Door I/O Placement External antennas (Options) (installing for either one) Ventilation holes VESA and wall-mount mounting holes... -
Page 10: I/O View
212. I/O view Item No. Description DC Jack LAN Port Cash Drawer Port MIC-in Line-Out COM Port 1, 2, 3, 4 (from left to right) USB x 4 Parellel Port Power Button Power LED Indicator PS/2 VGA Port 213. Dimensions 335mm... -
Page 11: Components Replacing
Components Replacing 311. RAM Module Replacing Please unfasten the screws (x3) and gently flip up the rear cover to access the motherboard first, please refer to the motherboard layout to find the RAM module place. Removing a RAM module Use both fingers to pull the ejector clips out of the sides of the module. Slide out to remove the memory module from the memory slot. -
Page 12: Hdd Replacing
312. HDD Replacing If your system is equipped with HDD as storage device, please replace it as following steps. Open the HDD door by unfastening the screw (x1). Disconnect the HDD connectors (x2) and replace the hard drive disk. 313. pSSD Card Module Replacing If your system is equipped with a pSSD card as storage device, please replace it as following steps. -
Page 13: Wall-Mount Module Installing
Turn the inside out and disconnect the SATA cable. Unscrew the screws (x2) to remove and replace the pSSD card from the inside of the top cover. 314. Wall-mount module installing You can assemble the system box with your wall-mount bracket, please refer to the steps below. -
Page 14: Power Adapter Replacing
315. Power Adapter Replacing The system is equipped with a 90W power adapter that is held securely in a power holding bracket. Please replace the power adapter as below steps. Disconnect the power cord from the adapter and the I/O panel. Slide the power adapter out of the holding bracket. -
Page 15: Wireless Lan Installing
313. Wireless LAN Installing If you install the wireless LAN module after manufacturer, please buy wireless LAN module with external antenna from your local distributor or dealer. The installation procedure is slightly different depending on which motherboard your system is equipped with. Please refer the location of motherboard layout on Chapter. -
Page 16: Cash Drawer Installing
317. Cash Drawer Installing You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer. Register Location: 48Ch Attribute: Read / Write Size: 8bit... - Page 17 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...
-
Page 18: Specification
Specification Mainboard Intel Pineview D525 Intel® Atom N270 Intel® Celeron® M 1.86G, dual core 1.8G L2 1M, Processor 1.6GHz L2 Core 2 Duo 1.66G, FSB800Mhz 512K FSB 533MHz Core Duo 2.0G Chipset CPU with Graphic built-in + ® Intel 945GSE + ICH 7M Intel® 945GME + ICH 7M ICH 8M System Memory 2 x DDR2 DIMM... - Page 19 Mainboard Power 19V /90W ext. power adapter Certificate EMC & Safety FCC / CE Class A, LVD, UL Environment Operating 5°C ~ 35°C (41°F ~ 95°F) Temperature Storage -20°C ~ 55°C (-4°F ~ 140°F) Temperature Operating Humidity 20% ~ 80% RH non-condensing Storage Humidity 20% ~ 85% RH non-condensing Communication...
-
Page 20: Jumper Setting
Jumper Setting 511. For C48 Motherboard 51111. Motherboard Layout... -
Page 21: Connectors & Functions
51112. Connectors & Functions Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN17 CD IN CN18 MIC IN CN19 Power LED CN20/JP10 System Indicator... -
Page 22: Jumper Setting
51113. Jumper Setting COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 & COM4 Power Setting COM3 and COM4 can be set to provide power to your serial device. - Page 23 4. To switch on the power, select "Power". Please save the change before exiting BIOS so as to go for physical jumper adjustment. COM3/COM4 Jumper setup Function JP18 ▲+5V COM3 +12V COM4 ▲+12V Cash Drawer Power Setting Function JP19 ▲+19V (for +24V Cash Drawer) +12V Power Mode Setting Function...
- Page 24 System Indicator Function JP10 ▲Disable Enable CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3.
-
Page 25: For B68 Motherboard
512. For B38 Motherboard 51211. Motherboard Layout JP11 JP12... -
Page 26: Connectors & Functions
51212. Connectors & Functions Connector Purpose BAT1 CMOS Battery Base ( Use CR2023) Power On Button Touch Sensor Power LED SATA1 HDD Power Connector SATA2 HDD Power Connector LCD Interface Connector IrDA Connector For External Touch Connector Inverter Connector CN10 Card Reader Connector CN11 Line Out CN12... - Page 27 Connector Purpose CRT Power/I2C Connector COM3/COM4 Power Setting VGA Power Setting JP5 / JP6 COM2 RS232/422/485 Setting LCD ID Setting COMS Operation Mode Power Mode Setting JP11 Cash Drawer Power Setting (+12V,+19V) JP12 Hardware Reset...
-
Page 28: Jumper Setting
51213. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 & COM4 Power Setting Function 5 7 9 11... - Page 29 Cash Drawer Power Setting Function JP11 +12V ▲+19V (for +24V Cash Drawer) Power Mode Setting Function ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset VGA Power Setting Function ▲No Power +12V LCD ID Setting Output Interface ▲CRT ▲ = Manufacturer Default Setting Jumper open Jumper short...
-
Page 30: For B98 Motherboard
513. For B98 Motherboard 51311. Motherboard Layout JP11 BAT3... -
Page 31: Connectors & Functions
51312. Connectors & Functions Connector Purpose BAT3 CMOS Battery Base (Use CR2023) Audio Line Out MIC In Internal Power On Switch Connector Speaker & MIC Connector CN11 CD-IN / Line-In Connector CN12 LCD Interface Connector CN14 Inverter Connector CN15 COM5 for Touch CN16 Power Connector For HDD CN18... -
Page 32: Jumper Setting
51313. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 11 5 7 9 ▲RS232 6 8 10 12 6 8 10 5 7 9 5 7 9 RS485 8 10 6 8 10 5 7 9 11 5 7 9 RS422 8 10 COM3 & COM4 Power Setting Function 5 7 9 11... - Page 33 Cash Drawer Power Setting Function +12V ▲+19V (for +24V Cash Drawer) Power Mode Setting Function JP11 ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset LCD ID Setting Output Interface ▲CRT ▲ = Manufacturer Default Setting Jumper open Jumper short...
-
Page 34: Appendix: Drivers Installation
Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.
