Page 1 ® TransTalk 9000 Digital Wireless System MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 Comcode 108626532 Issue 3 October 1999...
Page 2: Copyright And Legal Notices
Lucent Technologies does not warrant that this product is immune from or will prevent unauthorized use of common-carrier telecommunication services or facilities accessed through or connected to it.
Page 3 2121. Consultation charges may apply. For all other systems, follow the procedure you normally use to obtain support for your communications system. Outside the continental U.S., contact your Lucent Technologies Representative or local Authorized Dealer. MDW 9031/9031DCP Wireless Pocket Phone Installation and Use...
Page 4: Table Of Contents
TransTalk 9000 System ........1...
Page 5 Contents Handset ..............60 Inserting and Removing the Handset’s Battery Pack .
Page 6 Appendix A: Warranty and Repair Information Lucent Technologies Limited Warranty and Limitation of Liability..... . 141 Limitation of Liability ........142 Repair Information .
Page 7 Contents MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 8: Introduction
DEFINITY), you can link up to five carriers, supporting up to 30 wireless phones in a single zone. Linked carriers are automatically synchronized with each other. The TransTalk 9000 System enables you to use several different phone and carrier models in the same zone; however, there are some compatibility issues to consider. You need to know the following: The name of the MDW phone (9000, 9010, 9030P, or 9031, 9031DCP, 9031 Dual •...
Page 9 ® About TransTalk 9000 Products Introduction The following illustrations show which phone models and carriers can be used together: Single Carrier Installation If you have a Model 117A1 Carrier... If you have a Model 117A3 Carrier, or Model 117A4 Carrier... Note: 117A1, 117A1A, and 117A2 Carriers should...
Page 10: About The Mdw 9031/9031Dcp Pocket Phone
About the MDW 9031/9031DCP Pocket Phone Introduction About the MDW 9031/9031DCP Pocket Phone The MDW 9031/9031DCP Pocket Phone is not only wireless, but it is also lightweight and pocket-sized. A removable carrying clip and a lanyard are provided with the handset. You can use either the clip or the lanyard for hands-free portability.
Page 11: Parts List
About the MDW 9031/9031DCP Pocket Phone Introduction Parts List Along with this book and the MDW 9031/9031DCP Pocket Phone Quick Reference, the box should contain the items shown below. If it does not, call for customer support as described in the Copyright and Legal Notices the beginning of this book.
Page 12: Additional Parts
About the MDW 9031/9031DCP Pocket Phone Introduction Additional Parts The following parts may be necessary, depending upon your installation. This Kit of Parts is required only when a single (stand-alone) MDW 9031/9031DCP Pocket Phone is installed: Rubber Feet (4) Radio Module 11-foot (3.4 m) Philips Head Wall Mounting Power Cord/AC Adapter...
Page 13: Spare Battery And Headset
About the MDW 9031/9031DCP Pocket Phone Introduction Spare Battery and Headset One nickel metal hydride battery pack, which provides up to 3 hours of talk time, comes with your MDW 9031/9031DCP Pocket Phone. For extended phone usage, you should purchase an additional battery pack. If you require full business-day use, you can purchase an extended battery pack.
Page 14: Installing The Mdw 9031/9031Dcp Pocket Phone
Installing the MDW 9031/9031DCP Pocket Phone Important Safety Instructions This book contains instructions related to safety labels on the product: WARNING: WARNING indicates the presence of a hazard that can cause severe or fatal personal injury if the hazard is not avoided. CAUTION: CAUTION indicates the presence of a hazard that will or can cause minor personal injury or property damage if not avoided.
Page 15: Basic Safety Precautions For Installation And Use
See the documentation that came with your communications system for more information. CAUTION: This equipment is for installation on Lucent Technologies PARTNER, PARTNER Plus, PARTNER II, PARTNER Advanced Communications System, MERLIN, MERLIN Plus, MERLIN II, MERLIN LEGEND, System 25, System 75, System 85, and DEFINITY Communications Systems only.
Page 16 Important Safety Instructions Installing the MDW 9031/9031DCP Pocket Phone Read and understand all instructions in this book before using this product. • Observe all warnings and instructions marked on the product. • • Do not use the product near water or when you are wet. If the product comes in contact with any liquids, unplug the power cord and telephone line cords immediately.
Page 17: Additional Safety Instructions For Installation Personnel
Important Safety Instructions Installing the MDW 9031/9031DCP Pocket Phone WARNING: The rechargeable battery pack may contain elements that are harmful to the environment (for example, nickel). Do not burn or puncture the battery pack. As with other batteries of this type, burning or puncturing could release toxic material which could cause injury.
Page 18: Ac Outlet Check
Important Safety Instructions Installing the MDW 9031/9031DCP Pocket Phone This product uses a 3-prong plug. Such plugs are designed for your safety. Do not • attempt to defeat this purpose. If your wall outlet will not accept the plug, the outlet should be replaced by an electrician.
Page 19: Installation Overview For Radio Modules And Carriers
Installation Overview for Radio Modules and Carriers Installing the MDW 9031/9031DCP Pocket Phone Installation Overview for Radio Modules and Carriers This section explains how to install radio modules and carriers. You should proceed through this section in the following order: “Radio Module/Switch Wiring”...
Page 20: Key Components
Installation Overview for Radio Modules and Carriers Installing the MDW 9031/9031DCP Pocket Phone Key Components Each radio module communicates with a corresponding handset. The matching sets are identified by a serial number located on the bottom of the radio module and in the battery compartment of the handset. Antenna Mounting Hook...
Page 21 Installation Overview for Radio Modules and Carriers Installing the MDW 9031/9031DCP Pocket Phone Radio RANS Module Mounting Rods Wall Mount Wall Mount Hole Hole Label with Model Number (not shown) IN Jack Power Cord I O N C A U T OUT Jack Connector O N LY...
Page 22: Positioning A Radio Module Or Carrier(S)
Installation Overview for Radio Modules and Carriers Installing the MDW 9031/9031DCP Pocket Phone Positioning a Radio Module or Carrier(s) Each of your handsets and its corresponding radio module operates within a single zone of coverage: Approximately 500 to 900 feet in a typical office building;...
Page 23 Installation Overview for Radio Modules and Carriers Installing the MDW 9031/9031DCP Pocket Phone Never install the radio module or carrier(s) above a drop, suspended ceiling. • Do not locate the radio module or carrier(s) within 3 feet (0.9 m) of any large •...
Page 24: Installing A Single Radio Module
Installing a Single Radio Module Installing the MDW 9031/9031DCP Pocket Phone Additional Rules for • Install carrier(s) within 15 feet (5 m) of either side of, and within 6 to 8 feet (1.8 Installing One or More to 2.4 m) above, a properly grounded, 3-prong electrical outlet that is not Carriers controlled by an on/off switch.
Page 25 Installing a Single Radio Module Installing the MDW 9031/9031DCP Pocket Phone Detach the rubber feet from the shipping card. Apply them to marked areas on the underside of the radio module. Place the wall-mounting plate against the wall. Choose a location backed by a wooden stud (if unavailable, use toggle bolts instead of the supplied wood screws).
Page 26 Installing a Single Radio Module Installing the MDW 9031/9031DCP Pocket Phone Insert one end of the telephone line cord into an extension jack or terminal/station connector on your communications system switch/control unit (refer to your communications system manual for the proper location). MUSIC HOLD PAGE...
Page 27: Single Radio Module Installation Self-Test
Installing a Single Radio Module Installing the MDW 9031/9031DCP Pocket Phone Plug the power cord/AC adapter into a properly grounded, 3-prong wall outlet that is not controlled by an on/off switch. CAUTION: Never connect or disconnect the telephone line cord while the radio module is plugged into the wall outlet.
Page 28: Understanding Carriers
Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone Note: The RADIO LED also may light upon installation; however, since the RADIO LED has no significance during installation, ignore its operation. The RADIO LED indicates a connection between the handset and the radio module;...
Page 29 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone As the following illustration shows, each Model 117A3 carrier has two user-adjustable DIP switches—one in Slot 2 that controls the power levels, and another in Slot 4 that specifies whether this particular carrier is functioning as a control or an expansion carrier.
Page 30 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone Setting the 117A3 If your MDW 9031/9031DCP Pocket Phones are interfering with other wireless Carrier Power Level products in use or if you anticipate that they will, you can adjust the carrier’s range by setting each 117A3 carrier’s power DIP switch, located in Slot 2.
Page 31 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone Use a nonmetallic, pointed object to set each 117A3 carrier’s DIP switch according to the following table. Note: You must set the DIP switch for all of the 117A3 carriers to the same setting.
Page 32 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone Setting the 117A3 The Model 117A3 carrier can serve as either a control or an expansion carrier. Carrier Whether you install one or more 117A3 carriers, you must set the Control/Expansion Control/Expansion DIP DIP switch in Slot 4 of each 117A3 carrier to indicate which role that carrier is filling.
Page 33 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone Use a nonmetallic, pointed object to set each 117A3 carrier’s DIP switch according to the following table. Note: Only one carrier (the leftmost carrier) can be the control carrier; the other carriers must be expansion carriers. To designate the carrier as a...
Page 34: Understanding Your Model 117A4 Carrier
Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone Understanding Your Model 117A4 Carrier The Model 117A4 carrier differs from the 117A3 in that it does not require that Slot 6 contain a radio module in order to pass the signal from the control carrier to the next carrier. It also does not have Power and Control/Expansion DIP switches to set.
Page 35 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone The following chart explains the label that identifies the jacks and LEDs on the 117A4 carrier. (The IN and OUT jacks and the OUT OF SYNC LED also appear on the 117A3 carrier.) Label Explanation Designates the modular jack that accepts the...
Page 36 Understanding Carriers Installing the MDW 9031/9031DCP Pocket Phone The label at the top of the right side of the carrier is provided to help you interpret the LED lights. The first three lines on this label refer to LEDs on the control carrier, the next three lines refer to the LEDs on each of the expansion carriers, and the last two lines apply to all carriers.
Page 37: Installing A Single Carrier
Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Installing a Single Carrier If you are installing a Model 117A3 carrier, be sure you have read the following sections and have set the DIP switches: • “Understanding Your Model 117A3 Carrier” •...
Page 38: Installing A Single Carrier On A Shelf Or Desk
Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Installing a Single Carrier on a Shelf or Desk You will not receive optimum performance if the unit is placed on a desk or low • shelf. • Install the unit as high as possible, leaving 6 to 12 inches (15.2 to 30.5 cm) between the top of the antenna and the ceiling, if on a high shelf.
Page 39 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Starting from the leftmost slot (#1), insert each radio module into the carrier by hooking it onto the radio module mounting rod. Slowly swing the radio module’s card edge into the card edge connector on the back of the carrier. When the card edge is fully seated, a snap lock on the bottom of the radio module will engage.
Page 40 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Insert a telephone line cord into the bottom of each radio module. Slide the telephone line cords through the rear exit slots on the bottom of the carrier. Cords originating from Modules 1 and 6 can share exit slots with cords from Modules 2 and 5, respectively.
Page 41 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Insert the free end of the telephone line cord into the appropriate extension jack or terminal/station connector on your communications system switch/control unit (refer to your communications system manual for the proper location). MUSIC HOLD PAGE...
Page 42 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Place the carrier on its feet towards the back of the shelf or desk, making sure it is in a stable position. Be sure the telephone line cords come out the rear exit slots in the back of the unit.
Page 43: Installing A Single Carrier On A Wall
Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Installing a Single Carrier on a Wall Install the unit high on a wall, leaving 6 to 12 inches (15.2 to 30.5 cm) between • the top of the antenna and the ceiling. •...
Page 44 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone ’ Remove the plastic cap covering each radio module s card edge before inserting the radio modules into the carrier. Starting from the leftmost slot (#1), insert each radio module into the carrier by hooking it onto the radio module mounting rod.
Page 45 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Insert a telephone line cord into the bottom of each radio module. Slide the telephone line cords through the cable manager slot on the left front of the carrier. Insert the free end of each telephone line cord into the appropriate extension jack or terminal/station connector on your communications system switch/control unit (refer to your communications system manual for the proper location).
Page 46 Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Plug the carrier’s AC adapter cord into the left side of the carrier. Insert the carrier’s power cord into the AC adapter, then plug the power cord into a properly grounded, 3-prong wall outlet that is not controlled by an on/off switch.
Page 47: Single Carrier Installation Self-Test
Installing a Single Carrier Installing the MDW 9031/9031DCP Pocket Phone Single Carrier Installation Self-Test To perform a single carrier self-test: A single carrier must always function as a control carrier. Wait a few seconds, then check the LED(s) on the right side of the carrier: Model 117A4: Compare the OUT OF SYNC and CONTROL/EXPANSION LEDs against the top three lines on the “SYNC and CONTROL/EXP LED Codes”...
Page 48: Installing Multiple Carriers
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone If you are using a Model 117A4 carrier, verify that the carrier’s CONTROL/EXPANSION LED is lit and that its color is green. This is correct for a single-carrier installation. Verify that the POWER and PASS LEDs on each radio module are lit. If a radio module’s PASS LED does not light, power down the carrier and the module, wait 15 seconds, and repower the module and then the carrier.
Page 49: Mounting And Cabling Multiple Carriers
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Multiple-carrier installation involves several stages: Mounting the carriers on the wall and cabling them. • • Installing a single radio module in each carrier. • Installing the remaining radio modules. The most efficient method for installing carriers and their radio modules is to perform self-tests after each stage of the installation.
Page 50 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Place the carrier assembly over the screws, then slide it downward to lock it into place. Be sure that the leftmost carrier is the control carrier. Tighten the screws. Repeat for each carrier. Connect an expansion cable to the OUT jack of the control carrier.
Page 51 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Plug an AC adapter cord into the left side of each carrier. Insert each carrier’s power cord into its AC adapter. If appropriate, you can wall-mount each AC adapter using its attached wall- mounting bracket.
Page 52 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Plug each carrier’s power cord into one of the following power sources that is not controlled by an on/off switch: Surge-suppressor strip. Properly grounded, 3-prong wall outlets. (See “wall outlets” in the following chart for the order in which to power up the carriers.) Power the carriers as follows: If the carriers are plugged...
Page 53: Multiple Carrier Mounting And Cabling Self-Test
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Multiple Carrier Mounting and Cabling Self-Test To perform a multiple carrier mounting and cabling self-test: Wait a few seconds after powering up the carriers, then verify that the red OUT OF SYNC LEDs on all carriers are lit. This is normal when no radio modules have yet been installed.
Page 54 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone At this stage of your installation, verify the LEDs displayed match the third of the SYNC and CONTROL/EXP LED Codes label, depending on whether the carrier is the control or an expansion carrier. If the LEDs on your installation do not reflect this pattern, there is probably a mistake in the cabling.
Page 55: Installing A Single Radio Module In Each Carrier
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Installing a Single Radio Module in Each Carrier To install a single radio module in each carrier: Power down the carriers. ’ Remove the plastic cap covering each radio module s card edge before inserting the radio modules into the carriers.
Page 56 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone When the card edge is fully seated, a snap lock on the bottom of the radio module will engage. Insert a telephone line cord into the bottom of each radio module. Slide the telephone line cords through the cable manager slot on the left front of each carrier.
Page 57 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Insert the free end of each telephone line cord into the appropriate extension jack or terminal/station connector on your communications system switch/control unit (refer to your communications system manual for the proper location). MUSIC HOLD PAGE...
Page 58: Installation Self-Test With A Single Radio Module In Each Carrier
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Installation Self-Test with a Single Radio Module in Each Carrier To perform an installation self-test with a single radio module in each carrier: Wait a few seconds after powering up the carriers, then verify that the carriers’ OUT OF SYNC LEDs are not lit.
Page 59 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone At this stage of your installation, verify that the LEDs displayed match the first or fourth lines of the SYNC and CONTROL/EXP LED Codes label. If an OUT OF SYNC LED is lit, power down, wait at least 15 seconds, and then repower the carriers in order from left to right, as described in Step 8 in “Installing a Single Radio Module in Each Carrier.”...
Page 60 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone The PASS and POWER LEDs on all radio modules should be lit and green. If a radio module’s PASS LED is not lit: Power down the carriers. From the wall outlet, unplug the power cord/AC adapter of the radio module that did not light.
Page 61: Installing The Remaining Radio Modules
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Installing the Remaining Radio Modules To install the remaining radio modules: Power down the carriers. Remove the plastic cap covering each radio module’s card edge before inserting the radio modules into the carriers. Beginning with the first empty slot and working from left to right, insert a radio module into each slot of the control carrier.
Page 62 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone When the card edge is fully seated, a snap lock on the bottom of the radio module will engage. Repeat Steps 3 and 4 for each expansion carrier, until each radio module is inserted into a carrier.
Page 63 Installing the MDW 9031/9031DCP Pocket Phone Installing Multiple C Slide the telephone line cords through the cable manager slot on the left f the carrier. Insert the free end of each telephone line cord into the appropriate extens or terminal/station connector on your communications system switch/con (refer to your communications system manual for the proper location).
Page 64 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Power the carriers as follows: If the carriers are plugged into... Then... one surge suppressor strip Power the strip. Result: All the carriers will turn on simultaneously. wall outlets Plug in the power for the carriers in this order: RANS RANS RANS...
Page 65: Installation Self-Test For Remaining Radio Modules
Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone Installation Self-Test for Remaining Radio Modules To perform an installation self-test for the remaining radio modules: Wait a few seconds after powering up the carriers, then verify that the carriers’ OUT OF SYNC LEDs are not lit. Y N C O F S O U T...
Page 66 Installing Multiple Carriers Installing the MDW 9031/9031DCP Pocket Phone If an OUT OF SYNC LED is lit, power down, wait at least 15 seconds, and then repower the carriers in order from left to right, as described in Step 9 in “Installing the Remaining Radio Modules.”...
Page 67: Handset
Handset Installing the MDW 9031/9031DCP Pocket Phone Handset This section explains how to install the handset battery pack, change the communications system setting, and fill out the handset label. Inserting and Removing the Handset’s Battery Pack To insert and remove the battery pack: To insert the battery pack into the handset, insert the two small rectangular tabs located along the bottom back edge of the handset into the two rectangular holes along the bottom front edge of the battery pack.
Page 68: Changing The Communications System Setting
Handset Installing the MDW 9031/9031DCP Pocket Phone To remove the battery pack, slide the spring latch upward (away from the battery pack). While holding the latch up, grasp both sides of the battery pack, then gently pull the battery pack upward and out. Changing the Communications System Setting The communications system you use determines what information the MDW 9031/9031DCP Pocket Phone can display and how the phone lines and programmable/intercom/drop buttons are identified.
Page 69 Handset Installing the MDW 9031/9031DCP Pocket Phone Press and hold “M” (6) for three seconds to enter Button Mapping Mode. The handset display shows one of the following: MAP:P PARTNER Systems MAP:D DEFINITY Systems, System 25, System 75, and System 85 Note: The MDW 9031DCP should only be set to MAP:D for DEFINITY.
Page 70: Filling Out The Handset Label
Handset Installing the MDW 9031/9031DCP Pocket Phone Filling Out the Handset Label MDW 9031/9031DCP Pocket Phone display shows the status of up to 12 lines or programmable/intercom/drop buttons. Since the MDW 9031/9031DCP is compatible with several different communications systems, diagrams of the button mappings for these systems are provided in Chapter 6.
Page 71: Battery Charger
Battery Charger Installing the MDW 9031/9031DCP Pocket Phone Battery Charger This section explains how to choose a location for the battery charger and install it. It also explains how to insert and remove a battery pack. Positioning the Battery Charger The battery charger can be placed on a desk, or it can be mounted on a wall.
Page 72 Battery Charger Installing the MDW 9031/9031DCP Pocket Phone Insert the battery charger’s power cord/AC adapter into the battery charger. If you are desk-mounting the battery charger, skip to Step 7. Place the keyhole-shaped openings in the back of the battery charger over the screw heads and wall spacers, then slide the battery charger downward into the groove in the wall spacers to lock it into place.
Page 73: Inserting A Battery Pack Into The Spare Battery Compartment
Battery Charger Installing the MDW 9031/9031DCP Pocket Phone Inserting a Battery Pack into the Spare Battery Compartment Slide the battery pack (or an optional extended battery pack) into the spare battery compartment until it is firmly seated with the back of the battery pack against the back of the spare battery compartment. Do not force the battery pack down.
Page 74: Removing A Battery Pack From The Spare Battery Compartment
Battery Charger Installing the MDW 9031/9031DCP Pocket Phone The extended battery pack slides down into the spare battery compartment. Extended Spare Battery Pack Handset Cradle Spare Battery Pack Guide Pin Battery Charger Contacts Spare Battery Compartment SPARE LED Removing a Battery Pack from the Spare Battery Compartment To remove a battery pack from the spare battery compartment of the charger, lift the battery pack up and out.
Page 75: Inserting The Handset Into The Battery Charger's Handset Cradle
Battery Charger Installing the MDW 9031/9031DCP Pocket Phone Inserting the Handset into the Battery Charger’s Handset Cradle Correct positioning of the handset in the charger is important to ensure proper charging: Position the handset (with either battery pack attached) so that the two small round holes in the bottom of the handset fit over the two guide pins on the bottom of the handset cradle.
Page 76: Using The Mdw 9031/9031Dcp Pocket Phone
Using the MDW 9031/9031DCP Pocket Phone Important Safety Instructions Please see “Important Safety Instructions” at the beginning of Chapter 2. Handset The MDW 9031/9031DCP Pocket Phone supports normal operation of all of the features of the switch as far as is practical within the limitations of its reduced size and power and the nature of wireless operation.
Page 77: Handset Controls
Handset Using the MDW 9031/9031DCP Pocket Phone Handset Controls Receiver Receives the sound of your Headset On/Off caller’s voice, unless a Press to turn the headset on if the headset is connected. headset is plugged in. appears in handset display. To Antenna turn off, press again.
Page 78: Column And Select Buttons
Handset Using the MDW 9031/9031DCP Pocket Phone Column and Select Buttons The MDW 9031/9031DCP Pocket Phone can display the status of up to 10 lines/intercom/programmable buttons, but the number of lines supported by compatible communications system switches varies. However, it has only 4 selection buttons (the Column buttons).
Page 79: Handset Display (With Backlighting)
Handset Using the MDW 9031/9031DCP Pocket Phone Handset Display (with Backlighting) The MDW 9031/9031DCP Pocket Phone display has one 16-alphanumeric-character line and four lines of icons to provide you with status information. The display provides Backlighting (a programmable option) either when the handset is turned on or when the "...
Page 80 Handset Using the MDW 9031/9031DCP Pocket Phone When the display is blank, the handset is either turned off or in the power-saving “sleep” mode. You can activate the display and Backlighting (if programmed) by pressing O, turning the handset on, or by pressing " “wake it up.”...
Page 81 Handset Using the MDW 9031/9031DCP Pocket Phone Line Status Indicators There are 12 status indicators; each one corresponds to a specific outside line or programmable/intercom/drop button. (The function of these status indicators varies, depending on the communications system you are using—see the Button Mapping topic for the appropriate communications system switch in Chapter 6, “MDW 9031/9031DCP Pocket Phone Compatibility.”) The status indicators show either a truncated triangle or a rectangle, signifying the following activity:...
Page 82: Volume Control
Handset Using the MDW 9031/9031DCP Pocket Phone Low Battery Indicator The standard battery pack has approximately three hours of continuous talk time after being fully charged. The optional extended battery pack has approximately eight hours of continuous talk time after being fully charged. When the handset is On and the battery power is low, the handset will emit two beeps and the Battery icon in the handset display will flash.
Page 83 Handset Using the MDW 9031/9031DCP Pocket Phone Attaching the Metal To attach the metal carrying clip to the battery pack, do the following: Carrying Clips Remove the battery pack from the handset, as described in “Inserting and Removing the Handset's Battery Pack” in Chapter 2. Standard Spare Battery Pack Extended Spare...
Page 84: Antenna
Handset Using the MDW 9031/9031DCP Pocket Phone Standard Spare Battery Pack Extended Spare Battery Pack Latch the right edge of the clip into the corresponding groove on the inner side of the battery pack. Push the left edge of the belt clip and snap it into the corresponding groove on the inner side of the battery pack.
Page 85 Handset Using the MDW 9031/9031DCP Pocket Phone Line Preselection • Backlighting • • Alerter Local Mode also gives you access to Local Test Mode (which enables you to test the alerter, vibrator, and display) and Wireless Test Mode (which enables you to test sound clarity, signal strength, and voice quality). While in Local Mode, the MDW 9031/9031DCP can still receive notification of incoming calls.
Page 86 Handset Using the MDW 9031/9031DCP Pocket Phone While still holding ", press O. The handset beeps twice, and the display shows the handset settings, indicating that you are now in Local Mode. (While in Local Mode, the MDW 9031/9031DCP can still receive notification of incoming calls.) If the vibrator is enabled, the VIBR icon appears in the display.
Page 87 Handset Using the MDW 9031/9031DCP Pocket Phone While still holding ", press O. The handset beeps twice, and the display shows the handset settings, indicating you are in Local Mode. (While in Local Mode, the MDW 9031/9031DCP can still receive notification of incoming calls.) If Line Preselection is enabled, PSEL appears on the top line of the display.
Page 88 Handset Using the MDW 9031/9031DCP Pocket Phone Enabling or Disabling The alerter is an audible signal to notify you of an incoming call. If a call comes in the Alerter while the phone is idle, the handset rings. If you are already on a call, the handset chirps softly.
Page 89: Test Modes
Handset Using the MDW 9031/9031DCP Pocket Phone Test Modes You can use Local Test Mode and Wireless Test Mode to verify that your handset is working properly and that the MDW 9031/9031DCP System is performing optimally. Using Local Test Mode You can use Local Test Mode to activate the audio warning signal, the vibrator, and all visual indicators on the handset display, enabling you to test the following: Does the audio warning signal work?
Page 90: Using Wireless Test Mode
O. Note: Ignore anything that displays if you press 4 while in Wireless Test Mode. These displays are for Lucent Technologies technicians’ use only. To use Wireless Test Mode: Make sure the handset is turned off.
Page 91 Handset Using the MDW 9031/9031DCP Pocket Phone To determine sound clarity, listen to the simulated dial tone as you walk around. A clear, steady tone indicates good sound clarity. To determine signal strength, press 1. The display shows the signal strength (SIG) for both the handset (HS) and the base (B) (the radio module) at the moment that 1 was pressed, using a number from 1 to 10, as shown in the following display: The higher the number, the stronger the signal, as shown in the following table.
Page 92 Handset Using the MDW 9031/9031DCP Pocket Phone The higher the number, the better the voice quality, as shown in the table below. A low number may indicate potential interfering devices (such as another radio transmitter) in the area. You can press 2 again to show a subsequent voice- quality reading.
Page 93 Handset Using the MDW 9031/9031DCP Pocket Phone Close Up Test At no more than 5 to 10 feet (1.5 to 3.1 m) from its radio module, use the following procedure: Make sure the handset is turned off. Press and hold the Select button ( " ) for three seconds. While still holding ", press O.
Page 94: Waking Up" The Phone
Handset Using the MDW 9031/9031DCP Pocket Phone With a signal strength of 3, press 2 to check the voice quality. When the voice quality is 7 or 8, the voice connection should be satisfactory. This is the edge of your usable range. The following diagram illustrates this Performance/Range test.
Page 95: Making A Call
Handset Using the MDW 9031/9031DCP Pocket Phone Making a Call To make a call using your MDW 9031/9031DCP, use the following procedure: Press the handset O button (or the headset O button if you have the headset attached) to turn the phone on. The MDW 9031/9031DCP seizes an available line and a truncated triangle or a small rectangle (depending on your communications system) appears around that line in the handset display.
Page 96: Preselecting A Line
Using a Headset Lucent Technologies offers the Supra 9031 headset, which is specifically designed for use with your MDW 9031/9031DCP wireless phone or the Radium (over-the-ear) headset. A headset assists in call answering and provides hands-free operation.
Page 97 Handset Using the MDW 9031/9031DCP Pocket Phone CAUTION: Plug ONLY the Supra 9031 headset cord or the Radium headset cord into the headset adapter. Note: Calls cannot be heard on the handset receiver when the headset is plugged in to the headset adapter. The handset microphone is also deactivated.
Page 98: Battery Charger
Battery Charger Using the MDW 9031/9031DCP Pocket Phone Battery Charger The battery charger charges battery packs in the spare battery compartment and in the handset. If both are present at the same time, charging in the spare battery compartment is suspended until the battery pack in the handset is fully charged.
Page 99: Extending Battery Life
Battery Charger Using the MDW 9031/9031DCP Pocket Phone The color of the battery charger’s LEDs indicates the state of the corresponding battery pack, as shown in the following table: If it is the SPARE LED, If it is the REFRESH LED, the battery pack in If it is the HANDSET the Refresh button was...
Page 100 Battery Charger Using the MDW 9031/9031DCP Pocket Phone Note that your handset will consume power both during talk time (when the handset is turned on) and during standby time (when the handset is turned off, but out of the battery charger). The following chart illustrates typical power usage: Battery Use at Full Charge Approximate...
Page 101 Battery Charger Using the MDW 9031/9031DCP Pocket Phone MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 102: Maintaining The Mdw 9031/9031Dcp Pocket Phone
Maintaining the MDW 9031/9031DCP Pocket Phone Important Safety Instructions Please see “Important Safety Instructions” at the beginning of Chapter 2. Removing Radio Module from Carrier • Slot 6 of a Model 117A3 control carrier must always contain a radio module to pass the synchronization signal to the next carrier.
Page 103 Removing Radio Module from Carrier Maintaining the MDW 9031/9031DCP Pocket Phone Unplug the telephone line cord from the bottom of the radio module. Press up and hold the snap lock on the bottom rear of the radio module. Slowly swing the radio module’s card edge out of the card edge connector on the back of the carrier, releasing the snap lock when clear.
Page 104 Removing Radio Module from Carrier Maintaining the MDW 9031/9031DCP Pocket Phone If you removed a radio module from Slot 6 of an 117A3 control carrier, you must insert another radio module into this slot. Failure to do so will cause the carriers to be unsynchronized.
Page 105: Swapping Extensions
Swapping Extensions Maintaining the MDW 9031/9031DCP Pocket Phone Swapping Extensions If you want to change your phone’s extension number assignment, make sure the radio module or carrier(s) is unplugged before you unplug the telephone line cord from the communications system switch/control unit. Power down and then repower the carrier(s) after all extension changes are made.
Page 106 Swapping Extensions Maintaining the MDW 9031/9031DCP Pocket Phone Repower the carrier. If you have multiple carriers, repower them in order from left to right, as shown below: RANS RANS RANS RANS RANS CAU TI CAU TI CAU TI CAU TI CAU TI ONLY ONLY...
Page 107: Replacing Antenna
Replacing Antenna Maintaining the MDW 9031/9031DCP Pocket Phone Replacing Antenna If the antenna on your MDW 9031/9031DCP Pocket Phone handset becomes damaged, you can order a replacement antenna (see “Ordering Replacement and Optional Parts” later in this chapter), and replace it yourself.
Page 108 107586828 includes Power Cord/AC Adapter for Radio Module [11 foot (3.4 m)] Outside the continental U.S., contact your Lucent Technologies Representative or local Authorized Dealer. MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 109 Ordering Replacement and Optional Parts Maintaining the MDW 9031/9031DCP Pocket Phone MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 110: Troubleshooting
Troubleshooting Procedures If you have a problem with your MDW 9031/9031DCP Pocket Phone, you may be able to solve it by following the procedures included in this chapter. If you cannot resolve the problem, call Customer Support as described in the Copyright and Legal Notices at the beginning of this book.
Page 111: Installation Problems
Procedures Troubleshooting Installation Problems Symptom Possible Causes Possible Solutions One or more OUT Expansion cable is installed in the Verify that all expansion cables are fully OF SYNC LEDs is wrong IN or OUT jack, or it is not inserted in the correct IN and OUT lit, radio module fully inserted into the correct jack.
Page 112 Procedures Troubleshooting Symptom Possible Causes Possible Solutions After you plug the Radio module is malfunctioning. Replace the radio module. radio module into an electrical outlet, the radio module’s POWER LED lights, but the PASS LED does not light. After you plug the Radio modules are out of Power down the carrier, wait 15 seconds, carrier into an...
Page 113 Procedures Troubleshooting Symptom Possible Causes Possible Solutions LEDs on the carriers Radio module is malfunctioning. Locate the malfunctioning radio module by were displaying using the following procedure: correctly according Power down all carriers. to the three self tests Remove the rightmost radio module. in “Installing Multiple Carriers”...
Page 114: Handset Problems
Procedures Troubleshooting Handset Problems Symptom Possible Causes Possible Solutions After you press O, There is no battery pack in the Insert a battery pack in the handset. display does not show handset. anything. Battery pack is not inserted properly Reinsert the battery pack in the in the handset.
Page 115 Procedures Troubleshooting Symptom Possible Causes Possible Solutions You can hear the party M button was pressed Press M again to turn off the on the other end, but inadvertently. mute feature. they cannot hear you. MUTE appears in the handset display. When placed in the Battery charger is plugged into an Plug the battery charger into an...
Page 116: Battery Problems
Procedures Troubleshooting Battery Problems Symptom Possible Causes Possible Solutions Battery icon appears in This is normal operation for the No action is required. the handset display. MDW 9031 Pocket Phone. Battery icon flashes in Battery power is low. You have 5 minutes or less of talk the handset display and time left.
Page 117 Procedures Troubleshooting Symptom Possible Causes Possible Solutions The SPARE LED in the The battery pack was jostled while in Remove then replace the battery spare battery charging the battery charger. pack in the charger. compartment turns amber instead of red. The power cord does The model 40B battery charger is not Check the label of the power cord...
Page 118: Voice Quality Problems
Procedures Troubleshooting Voice Quality Problems Symptom Possible Causes Possible Solutions Handset voice quality A competing radio device (for Place the handset in Wireless Test and range are not as example, a wireless bar-code scanner) Mode as described in Chapter 3. If good as they were has been installed in the area.
Page 119 (See “General Positioning Rules” in Chapter 2 for more information.) You are using different models of See “TransTalk 9000 System” in handsets and the mix is incompatible Chapter 1. with the carrier. MDW 9031/9031DCP Wireless Pocket Phone Installation and Use...
Page 120 Procedures Troubleshooting Symptom Possible Causes Possible Solutions Volume is too low at Handset or radio module is not Place the handset in Wireless Test any setting and there is working properly. Mode and determine the signal noise on the line. strength and voice quality as described in Chapter 3.
Page 121: Range Problems
Procedures Troubleshooting Range Problems Symptom Possible Causes Possible solutions Handset voice quality A competing radio device (for Place the handset in Wireless Test and range are not as example, a wireless bar-code scanner) Mode as described in Chapter 3. If good as they were has been installed in the area.
Page 122 (See “General Positioning Rules” in Chapter 2 for more information.) You are using different models of See “TransTalk 9000 System” in handsets and the mix is incompatible Chapter 1. with the carrier. MDW 9031/9031DCP Wireless Pocket Phone Installation and Use...
Page 123 Procedures Troubleshooting Symptom Possible Causes Possible solutions No ring on an incoming Handset is out of range of its Move the handset closer to the radio call. matching radio module. module. • Station wiring is incorrect. Check your station wiring, referring to the table in “Radio Module/Switch •...
Page 124: Battery Charger Problems
Procedures Troubleshooting Battery Charger Problems Symptoms Possible Causes Possible Solutions No LEDs on battery Battery charger is plugged into an Plug the battery charger into an charger light. electrical outlet controlled by a switch outlet not controlled by a switch. and the switch is turned off.
Page 125 Procedures Troubleshooting Symptoms Possible Causes Possible Solutions HANDSET LED Battery pack is defective. If you have a battery pack in the flashes red. handset and one in the spare battery compartment, remove both battery packs from the charger to clear the red flashing LED.
Page 126 Procedures Troubleshooting Symptoms Possible Causes Possible Solutions SPARE LED on battery Battery pack is defective. If you have a battery pack in the charger flashes red. handset and one in the spare battery compartment, remove both battery packs from the charger to clear the red flashing LED.
Page 127 Procedures Troubleshooting MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 128: Mdw 9031/9031Dcp Pocket Phone Compatibility
MDW 9031/9031DCP Pocket Phone Compatibility Overview This chapter provides compatibility information for your Pocket Phone. 9031 Compatibility If you are using an MDW 9031 Pocket Phone, go to the “MDW 9031 Compatibility” section for compatibility information. 9031DCP Compatibility If you are using an MDW 9031DCP Pocket Phone, go to the “MDW 9031DCP Compatibility”...
Page 129 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility For this release... Of this communications system... Use the instructions for a... R1, R2, R3, R4 PARTNER MLS-12D phone R1, R3, R4, R4.1 PARTNER II (Apparatus code 7311H) R1, R2, R3, R4, R4.1 PARTNER Plus R1, R2 PARTNER Advanced Communications...
Page 130: Programming Features For Partner, Merlin, And Merlin Legend Systems
MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility Programming Features for PARTNER, MERLIN, and MERLIN LEGEND Systems On all PARTNER, MERLIN, and MERLIN LEGEND systems, you can assign a feature to an available button (a button that does not have a line or another feature assigned to it): To enter programming mode, turn on the handset, press i, then press / followed by 0 0.
Page 131 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility PARTNER Systems Button Mapping for On PARTNER Systems, the MDW 9031 emulates an MLS-12D telephone. The PARTNER Systems following diagram illustrates the button assignments on an MLS-12D phone and the corresponding assignments on the MDW 9031 Pocket Phone. MLS-12D 09/10 TUE 10:24a...
Page 132 Ringing options as described in the following table if more than six MDW 9031 Pocket Phone handsets have the same pooled line appearance. Telephone TransTalk 9000 System with TransTalk 9000 System with Three Communications Two Carriers (one control and Carriers (one control and two System...
Page 133 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility To program the Ringing Option feature, use the “triangle” and “rectangle” • indicators in the display as the equivalent of red and green LEDs, respectively. • For MERLIN II System users, if you program an Auto Intercom button, idle line preference must be set to intercom.
Page 134 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility Button Mapping for On all MERLIN Systems, the MDW 9031 emulates a Model BIS-22D phone MERLIN Systems (Apparatus Code 7315H). The BIS-22D button assignments, however, differ except MERLIN 410 and depending on the MERLIN System used. The following diagram illustrates the BIS- MERLIN 820 22D button assignments and the corresponding assignments on the MDW 9031 for all MERLIN Systems except MERLIN 410 and MERLIN 820.
Page 135 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility Button Mapping for The following diagram illustrates the button assignments on a BIS-22D phone used MERLIN 410 and for MERLIN 410 and 820 Systems and the corresponding assignments on the MDW MERLIN 820 Systems 9031 Pocket Phone.
Page 136 Use the following guidelines to ensure optimal voice quality when using MDW 9031 Ringing Options for Pocket Phones with MERLIN, MERLIN Plus, and MERLIN II: MERLIN Systems Telephone TransTalk 9000 System with TransTalk 9000 System with Three Communications Two Carriers (one control and Carriers (one control and two System one expansion carrier)
Page 137 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility Consult your System Administration manuals for this compatibility. If your system does not support the items above, consult the System Administration manual for the BIS-10 phone (Apparatus Code 7303S). Accessing Certain Voice Mail Systems with a DEFINITY System •...
Page 138 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility If you are programming numbers for the Station Speed Dial feature, dial the numbers to be stored and then dial the Personal Speed Dialing code (#20 through #39), including the #. Listen for a confirmation tone followed by a dial tone.
Page 139 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility The 7315H phones are programmed for DEFINITY systems using four STATION Administration screens. Enter 7315H in the Type field on the first screen to bring up the following two screens. add station next Page 1 of SPE B...
Page 140 MDW 9031 Compatibility MDW 9031/9031DCP Pocket Phone Compatibility The following illustrations show in parentheses the MDW 9031 Pocket Phone button assignments on Pages 3 and 4 of the STATION Administration screens. The button labeled D on the MDW 9031 Pocket Phone display automatically defaults to the button labeled D (Drop) on the 7315H phones.
Page 141 Pocket Phones with System 25, System 75, System 85, and DEFINITY Systems: System 25, System 75, System 85, and DEFINITY Systems Telephone Communications TransTalk 9000 System with Two Carriers (One System Control and One to Four Expansion Carriers) System 25 When TransTalk handsets are configured as individual...
Page 142: Mdw 9031Dcp Compatibility
MDW 9031DCP Compatibility MDW 9031/9031DCP Pocket Phone Compatibility MDW 9031DCP Compatibility Programming and Call Handling Instructions The MDW 9031DCP Pocket Phone can display the status of up to 10 lines/intercom/programmable buttons, but the number of lines supported by compatible communications system switches varies. After you have installed your MDW 9031DCP and understand the controls and displays, use the programming and call handling instructions that came with your communications system;...
Page 143 MDW 9031DCP Compatibility MDW 9031/9031DCP Pocket Phone Compatibility DEFINITY Systems This phone must be administered as an 8410D phone for the DEFINITY Systems. The 8410D phones are programmed for DEFINITY Systems using four STATION Administration screens. Enter 8410D in the Type field on the first screen to bring up the following two screens.
Page 144 MDW 9031DCP Compatibility MDW 9031/9031DCP Pocket Phone Compatibility The following illustrations show in parentheses the MDW 9031DCP Pocket Phone button assignments on Pages 3 and 4 of the STATION Administration screens. The button labeled D on the MDW 9031DCP Pocket Phone display automatically defaults to the button labeled 04 (Drop) on the 8410D phones.
Page 145 MDW 9031DCP Compatibility MDW 9031/9031DCP Pocket Phone Compatibility Button Mapping for On DEFINITY Systems, the MDW 9031DCP should be aliased as an 8410D phone. DEFINITY Systems The following diagram illustrates the 8410D button assignment, and the corresponding assignments on the MDW 9031DCP for DEFINITY systems. Menu Exit Prev...
Page 146 Use the following guidelines to ensure optimal voice quality when using MDW Ringing Options for 9031DCP Pocket Phones with DEFINITY Systems: DEFINITY Systems Telephone Communications TransTalk 9000 System with Two Carriers (One System Control and One to Four Expansion Carriers) DEFINITY Systems When TransTalk 9031DCP handsets are configured as individual PBX extensions, no Line Ringing options are necessary.
Page 147 MDW 9031DCP Compatibility MDW 9031/9031DCP Pocket Phone Compatibility MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 148: Appendix A: Warranty And Repair Information
(“Warranty Date”). If you notify Lucent Technologies or its Authorized Dealer within one year of the Warranty Date that your system is not in good working order, Lucent Technologies will without charge to you, repair or replace, at its option, the system components that are not in good working order. Repair or replacement parts may be new or refurbished and will be provided on an exchange basis.
Page 149: Limitation Of Liability
Warranty and Repair Information Limitation of Liability Except as provided below, the liability of Lucent Technologies and its affiliates and suppliers for any claims, losses, damages, or expenses from any cause whatsoever (including acts or omissions of third parties), regardless of the form of action, whether in contract, tort, or otherwise, shall not exceed the lesser of: (1) the direct damages proven;...
Page 150: Appendix B: Regulatory Information
This appendix contains information about the Federal Communications Commission and Industry Canada. FCC Part 15 Rules The Lucent Technologies MDW 9031/9031DCP Wireless Pocket Phone has been tested and has been found to comply with FCC Part 15 Rules. These specifications are designed to provide reasonable protection against harmful interference in a commercial or residential installation.
Page 151 Hearing Aid Compatibility Regulatory Information MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 152: Appendix C: Specifications
Specifications GENERAL MDW 9031/9031DCP Wireless Pocket Phone Model: Dimensions Handset 6.0"(L) x 1.0"(D) x 2.25"(W) 0.33 lb and Weights: 15.24 x 2.54 x 5.71 cm 0.15 kg Handset w/Battery Pack 6.0"(L) x 1.0"(D) x 2.25"(W) 0.55 lb 15.24 x 2.54 x 5.71 cm 0.25 kg Battery Charger (BC) 9.75"(L) x 5.13"(H) x 3.94"(W)
Page 153 • MDW 9031/9031DCP Pocket Phone: Lucent Technologies SYSTIMAX or at least 2-pair (4-wire) star (“home run” not “loop”) ETR Lucent Technologies SYSTIMAX or at least 4-pair (8-wire) star (“homerun” not • “loop”) ATL Bridging Adapter: Lucent Technologies 267F2 (ETR) •...
Page 154: Index
Index Carrier, (continued) installation Alerter multiple carriers Answering a call single carrier on a wall headset single carrier on shelf or desk Antenna positioning replacement power supply Attaching carrying clips powering multiple powering single Removing a Radio Module from replacement required for multiple radio modules Backlighting retired models...
Page 155 Index Electrical requirements Icons Environmental requirements Illustrations Expansion cable battery charger Expansion carrier battery pack Extended battery pack inserting/removing about Battery pack clip inserting/removing from battery charger carrier refreshing CONTROL/EXPANSION LED talk time extended spare Extended battery pack clip handset illustration headset Extension labels...
Page 156 Index CONTROL/EXPANSION HANDSET ON icon OUT OF SYNC On/Off buttons headset PASS Ordering parts POWER OUT jack RADIO cabling illustration REFRESH description SPARE OUT OF SYNC LED Line Preselection Line ringing options DEFINITY Systems MERLIN Systems PARTNER Systems Line ringing options, System 25 PARTNER Systems Line ringing options, System 75 Parts...
Page 157 Index Standard battery pack about RADIO LED inserting/removing from battery charger Radio module refreshing identification replacing illustration talk time installation in carrier Standby time installation of a single module System 25 matching with handset System 75 positioning System 85 power level power supply removing from carrier Range...
Page 158 Index Wake up Warranty information Wireless Test Mode MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 159 Index MDW 9031/9031DCP Wireless Pocket Phone Installation and Use 503-801-166 — Issue 3 — October 1999...
Page 160: Battery Charger Wall-Mounting Template
Battery Charger Wall-Mounting Template Use the template below to position the screws for mounting your MDW 9031/ 9031DCP Pocket Phone battery charger: Cut out the template along the dotted line. Lightly affix the template to the wall with tape where you want to attach the battery charger.
