CLiQ

1. To turn the iQ CLiQ into a 2-dog system, start with the handheld

transmitter with the stimulation set to level 0. Hold down buttons

1 and 2 simultaneously for 5 seconds. You should now see that the

LED indicator is blinking rapidly.

2. With the receiver/collar turned off, take the handheld transmitter and

hold the two red on/off dots together for 5 seconds. The LED

indicator should now be blinking rapidly.

3. While both the handheld transmitter and receiver/collar LED

indicators are rapidly blinking, press button 2 to code that button to

the receiver/collar you desire. The LED indicators on both the

handheld transmitter and receiver/collar will blink rapidly for 15

seconds or until they have been coded together.

4. When the iQ CLiQ has been coded with an additional receiver/collar,

button 1 will function as the Nick and Pulsating Nick stimulation on

the first receiver/collar. Button 2 will function as the Nick and

Pulsating Nick stimulation on the newly coded second receiver/collar.

5. To go back to a 1-dog system, repeat steps 1 and 2. While both the

handheld transmitter and receiver/collar LED indicators are rapidly

blinking, press button 1 on the handheld transmitter.

6. When done correctly, both buttons 1 and 2 will now only operate

the one receiver/collar you have coded. To check that the handheld

transmitter is coded to the receiver/collar, press a button on the

handheld transmitter, and the corresponding receiver/collar LED

indicator will blink.

22912 Lockness Avenue Torrance, CA 90501 U.S.A.

Tel) 310.534.0101 Fax) 310.534.9111 Toll free) 1.888.811.9111

Website) www.iqpetcollar.com

Code Setting Guide

Table of Contents

Need help?

Do you have a question about the IQ CLIQ and is the answer not in the manual?

Page 1 CLiQ Code Setting Guide 1. To turn the iQ CLiQ into a 2-dog system, start with the handheld transmitter with the stimulation set to level 0. Hold down buttons 1 and 2 simultaneously for 5 seconds. You should now see that the LED indicator is blinking rapidly.
Page 2 CLiQ Warranty and Repair Information iQ Pet provides the original purchaser with a 1-YEAR WARRANTY for all products in the iQ Pet Series. The warranty begins from the date of purchase. For the first year, coverage is for Parts, Labor, and Accessories.
