SWEEX LW140 Manual

Wireless broadband router 140 nitro xm

Advertisement

Quick Links

English version
Introduction
First of all, many thanks for purchasing the Sweex Wireless Broadband Router 140 Nitro XM. With this wireless router you can set up a wireless
network fast and efficiently. You can also simply share an Internet connection by means of the built-in router.
To ensure this product operates correctly, we also advise you to carefully read this manual first. If despite this manual you still experience
problems during installation or operation of this product, go to our website, www.sweex.com for additional information and look under the
heading service & support.
Contents of the box
Prior to installation, check if all required parts are present. The following parts must be present in the box:
Sweex Wireless Broadband Router 140 Nitro XM
Mains supply adapter
CD-ROM with extensive English manual
Manual in 13 different languages

Specifications

Supports: PPTP, PPPoE, Static IP and DHCP Client
Supports: Nitro XM, IEEE 802, IEEE 802.11b
1 x 10Base-T/100Base-TX WAN port (10/100 Mbps)
4 x 10Base-T/100Base-TX LAN ports (10/100 Mbps)
Maximum connection speed: 140 Mbps
Protection: 64/128-bit WEP, WPA, and 802.1x encryption
Universal Plug and Play
Not operating system dependent
Additional specifications
Firewall
Wireless Distribution System (WDS)
Wireless LAN MAC filtering (ACL)
Supports Dynamic DNS (dydns.org)
DMZ
Port forwarding
Virtual server
2
LW140 Wireless Broadband Router 140 Nitro XM
LW140UK Wireless Broadband Router 140 Nitro XM
S W E E X . C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LW140 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SWEEX LW140

  • Page 1: Specifications

    Introduction First of all, many thanks for purchasing the Sweex Wireless Broadband Router 140 Nitro XM. With this wireless router you can set up a wireless network fast and efficiently. You can also simply share an Internet connection by means of the built-in router.
  • Page 2: Frontal View

    This is used to switch the router on or off. Connecting the Sweex Wireless Broadband Router We advise you to ensure the operating system is up-to-date before you start the installation. This is easy to check by starting up Internet Explorer and selecting the option Windows Update in the Extra menu.
  • Page 3: Windows 98Se

    “My Hot Spot”, and the WEP encryption must be disabled. Setting the computer(s) • Under network settings, you must select automatic IP number allocation for the network card (DHCP) through the Sweex Wireless Broadband • Router. Windows 98SE Click on “Start”...
  • Page 4: Windows Xp

    English version Windows 2000 Click on “Start” and then select the option “Control Panel”. Double-click on “Network Connections”. • Select the required LAN connection by clicking on it with the mouse. Then right-click and select “Properties” in the menu that appears. •...
  • Page 5 You can configure the Internet connection using the data your Internet provider has given you. For certain Internet providers, the configuration of the Sweex Wireless Router requires a so-called MAC address. A MAC address is the unique number of the network card and consists of a combination of numbers and letters (e.g. 00-02-A5-6C-11-D1). With the clone MAC address you can send this address to the router quickly.
  • Page 6: Advanced Settings

    In some cases, you must follow the steps below when no Internet connection is established. Close Internet Explorer. Then shut down the computer, wait for ten seconds and switch off the modem as well. Leave the Sweex Wireless Router switched on at all times. Wait another ten seconds and switch on the modem.
  • Page 7: Wireless Settings

    English version Wireless settings Select the option “Wireless Setup” in the left-hand side of the menu. You will see a total of four different tabs for the wireless settings. In principle, you can use the manufacturer’s settings shown on the “Basic Setup” tab. Make sure that the four Nitro options are ticked. On the Wireless Security tab you must indicate the encryption method.
  • Page 8: Warranty

    English version Important! Since the settings for the wireless network are changed, you must make these changes on a computer which is connected to the Sweex Wireless Router via a network cable. Click “OK” to save the data. The wireless network is now secured with a 64 or 128-bit WEP key. All stations trying to establish a wireless connection with the wireless router must have this key in order to be able to communicate.
