D-Link DAP-3520 Command Line Interface Reference Manual

Airpremier n dual band poe access point
Hide thumbs Also See for DAP-3520:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
DAP-3520
AirPremier N Dual Band PoE Access Point
Command Line Interface Reference Manual
First Edition (August 2008)
RECYCLABLE

Advertisement

Table of Contents
loading

Related Manuals for D-Link DAP-3520

Summary of Contents for D-Link DAP-3520

  • Page 1 DAP-3520 AirPremier N Dual Band PoE Access Point Command Line Interface Reference Manual First Edition (August 2008) RECYCLABLE...

  • Page 2: Table Of Contents

    Table of Contents Using the CLI................................................1 Wireless Commands..............................................9 LAN Commands ............................................... 12 WLAN Partition Commands ............................................ 13 VLAN Commands..............................................14 RADIUS and Accounting Server Commands ......................................15 SNMP Commands ..............................................16 SNTP Commands ..............................................17 TFTP Commands ..............................................18 DHCP Server Commands ............................................
  • Page 3 Schedule Commands ..............................................29 Utility and Miscellaneous Commands ........................................30 First-Time Configuration Examples ........................................31...

  • Page 4: Using The Cli

    The DAP-3520 can be accessed by Telnet. Using a Microsoft Windows system as an example, open the Command Prompt on the computer that will be used for configuring and managing the AP and enter telnet and the IP address of DAP-3520 in the first line. Using the default IP address as example, enter telnet 192.168.0.50 to cause the following screen to open: Press Enter in the screen above.
  • Page 5 AirPremier N Dual Band PoE Access Point Command Line Interface Manual Type admin for the D-Link Access Point login username in the screen above and press Enter. The following screen opens:...
  • Page 6 AirPremier N Dual Band PoE Access Point Command Line Interface Manual Press Enter as there is no initial password. The following screen opens to indicates you have successfully logged into the Access Point.
  • Page 7 AirPremier N Dual Band PoE Access Point Command Line Interface Manual Commands are entered at the command prompt, WAP¡ >...
  • Page 8 AirPremier N Dual Band PoE Access Point Command Line Interface Manual There are a number of helpful features included in the CLI. Entering the ? command and then pressing Enter will display a list of all of the top-level commands. The same information can also be displayed by entering help.
  • Page 9 AirPremier N Dual Band PoE Access Point Command Line Interface Manual When you enter a command without all of its required parameters, the CLI will prompt you with a list of possible completions. For example, if tftp was entered, the following screen opens:...
  • Page 10 AirPremier N Dual Band PoE Access Point Command Line Interface Manual This screen displays all the possible command completions for tftp. When you enter a command without a variable or value that needs to be specified, the CLI will prompt you with further information about what is needed to complete the command.
  • Page 11 AirPremier N Dual Band PoE Access Point Command Line Interface Manual The missing value for the snmp delcomm command, ¡CommunityString<string>,¡ is displayed in the screen above.

  • Page 12: Wireless Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual IRELESS OMMANDS Wireless Command Description del key Delete Encryption key (index:1--4) get acktimeout Display acknowledgement timeout get key Display Encryption Key (index:1--4) get apmode Display AP operation mode get assoclimitstatus Display association limit setting status get authentication Display authentication type...

  • Page 13: Display Service Set Id

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual get keylength Display encryption key length (in bits)[index: 1--4] get ssid Display Service Set ID get ssidhidden Display SSID hidden get txpower Display TX power get wdsinfo Display WDS info get wdsmac Display WDS MAC address list get wdsscaninfo...
  • Page 14 AirPremier N Dual Band PoE Access Point Command Line Interface Manual set defkeyindex Set default key Index [1--4] set dtim Set DTIM (1--15) set fixedrate Set fixerd rate set groupkeyupdate Set group key update interval (in secs: 0 (no update) or 300-99999) set key Set encryption key index [1--4][value] set keyentrymethod...

  • Page 15: Lan Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual LAN C OMMANDS LAN Command Description get ethernetcount Display Ethernet count get gateway Display gateway IP address get ipaddr Display IP address get ipmask Display IP subnet mask get ipmode Display IP mode set gateway Set gateway IP address...

  • Page 16: Wlan Partition Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual WLAN P ARTITION OMMANDS WLAN Partition Command Description get e_partition Display ethernet_partition get ethlink Display Ethernet integration get w_partition Display w_partition set e_partition Set ethernet_partition set ethlink Set Ethernet integration set w_partition Set w_partition...

  • Page 17: Vlan Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual VLAN C OMMANDS VLAN Command Description get vlanstate Display VLAN state get vlanmode Display VLAN mode get autosetpvid Display auto setting pvid by group VID get pvid_primary Display primary SSID PVID get pvid_eth Display ethernet PVID get pvid_sys...

  • Page 18: Radius And Accounting Server Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual RADIUS CCOUNTING ERVER OMMANDS RADIUS and Accounting Command Description get radiusip Display RADIUS server IP address get radiusport Display RADIUS port number...

  • Page 19: Snmp Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual SNMP C OMMANDS SNMP Command Description snmp addcomm Add Communication String snmp addgroup Add User Group snmp addhost Add Host To Notify List snmp adduser Add User To SNMP Agent snmp addview Add User View snmp delcomm...

  • Page 20: Sntp Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual SNTP C OMMANDS SNTP Command Description get daylightsaving Display daylight saving time get sntpserver Display SNTP/NTP server IP address get tzonelist Display time zone set daylightsaving Set daylight saving time set sntpserver x.x.x.x Set SNTP/NTP server IP address set tzone...

  • Page 21: Tftp Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual TFTP C OMMANDS SNTP Command Description tftp getconfig Use TFTP to get a configuration file from a PC tftp getfirmware Use TFTP to get firmware from a PC tftp putconfig Use TFTP to put configuration on a PC...

  • Page 22: Dhcp Server Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual DHCP S ERVER OMMANDS DHCP Server Command Description get dhcp_dns Display DHCP server DNS IP get dhcp_endip Display DHCP server end IP get dhcp_gateway Display DHCP server gateway IP get dhcp_leasetime Display DHCP server lease time get dhcp_netmask...
  • Page 23 AirPremier N Dual Band PoE Access Point Command Line Interface Manual set dhcp_server Set DHCP server state set dhcp_server_static_ip_mode Set dhcp server static ip mode states set dhcp_startip Set DHCP server start IP set dhcp_staticip_set_disable Set dhcp staticip disable set dhcp_staticip_set_enable Set dhcp staticip enable set dhcp_staticip_set_hostname Set DHCP static IP's host name...

  • Page 24: Limit Administrator Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual IMIT DMINISTRATOR OMMANDS Limit Administrator Command Description get ladtype Limited administration type get ladvid VLAN ID which can control device get ladippool Starting IP of the limited administration IP pool set ladtype Limited Administration Type set ladvid...

  • Page 25: Intrusion Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual NTRUSION OMMANDS Intrusion Command Description get intrusion Display intrusion set intrusion Set intrusion set rogue_set_type_mac Set rogue AP index type and MAC < type macaddradd macaddress>...

  • Page 26: Multiple Ssid And Vlan Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual SSID VLAN C ULTIPLE OMMANDS Multiple SSID and VLAN Description Command set multi-auth Set Authentication Type of Multi-SSID[index] set multi-groupvid Set Group VID of Multi-SSID[index] set multi-pri-state Set Multi-SSID priority state set multi-priority Set priority of Multi-SSID[index] set multi-cipher...

  • Page 27: Display Wmm

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual get multi-pvid Display PVID of Multi-SSID [index] get multi-wmm Display WMM state of Multi-SSID [index] set multi-defkeyindex Set default key index [1-4] of Multi-SSID [index] set multi-groupkeyupdate Set group key update interval (in Sec: 0 (no update) or 300-99999) of Multi-SSID [index] set multi-ind-state Set Multi-SSID [index] individual state set multi-passphrase...

  • Page 28: Igmp Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual IGMP C OMMANDS IGMP Command Description get igmpsnoop Display IGMP snooping set igmpsnoop Set igmp snooping states...

  • Page 29: Qos Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual OMMANDS QoS Command Description get qos Display Quality of Service set qos Set Quality of Service...

  • Page 30: System Log Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual YSTEM OMMANDS System Log Command Description get syslog Display system log information set syslog Set sysLog settings...

  • Page 31: Access Control List Commands

    AirPremier N Dual Band PoE Access Point Command Line Interface Manual CCESS ONTROL OMMANDS Access Control List Command Description get acl Display ACL get macaddress Display MAC address get macaddrlist Display MAC address list set acl Set ACL set macaddradd Add MAC address <macaddradd macaddress>...
  • Page 32 AirPremier N Dual Band PoE Access Point Command Line Interface Manual CHEDULE OMMANDS Schedule Command Description get scheduled Display scheduled set scheduled Set scheduled...
  • Page 33 AirPremier N Dual Band PoE Access Point Command Line Interface Manual TILITY AND ISCELLANEOUS OMMANDS Utility/Miscellaneous Command Description version Display software version help Display CLI command list ping Send ICMP ECHO_REQUEST to network hosts Print name of current/working directory reboot Reboot access point get country Display country...
  • Page 34 The following AP configuration examples are provided to help first-time users get started. The user commands are in bold for easy reference. Many users will want to set a new IP address for the DAP-3520. This will also require setting an IP mask and a gateway IP address. The following is an example in which the AP¡s default IP address of ¡192.168.0.50¡...
  • Page 35 AirPremier N Dual Band PoE Access Point Command Line Interface Manual If a TFTP server is being used to get the configuration file from a PC, to get firmware from a PC, or to put a configuration file on a PC, see the examples below. Please note that users must enable the TFTP server on the PC before using these commands.
  • Page 36 AirPremier N Dual Band PoE Access Point Command Line Interface Manual Once the user has determined what type of authentication is best for their wireless network, follow the appropriate instructions below. The following is an example in which authentication is set to Open System. WAP->...
  • Page 37 AirPremier N Dual Band PoE Access Point Command Line Interface Manual The following is an example in which the authentication is set to WPA-EAP. WAP-> set authentication wpa-eap WAP-> set cipher auto WAP-> set radiusip 192.168.0.88 WAP-> set radiussecret WAP-> set apply The following is an example in which the authentication is set to WPA2-EAP.
  • Page 38 AirPremier N Dual Band PoE Access Point Command Line Interface Manual The DAP-3520 doesn¡t need to be rebooted after making any changes to the configuration. Simply type set apply to enable the new configuration to take effect immediately.
