Interface
USB port, for connecting the 3G network card or other USB storage
USB1/2
devices.
Power Power interface, for connecting the power adapter.
On/Off
Power switch.
WiFi WiFi switch, for enabling or disabling the WiFi function.
This button is used for enabling WPS PBC mode. If WPS is enabled,
WPS press this button, and then the wireless router starts to accept the
negotiation of PBC mode.
Warning:
Do not press the Reset button unless you want to clear the current settings. The
Reset button is in a small circular hole on the rear panel. If you want to restore the
default settings, please press the Reset button gently for 1 second with a fine needle
inserted into the hole and then release the button. The system reboots and returns to
the factory defaults.

3.2 Hardware Installation

3.2.1

Choosing the Best Location for Wireless Operation

Many environmental factors may affect the effective wireless function of the DSL
Router. If this is the first time that you set up a wireless network device, read the
following information:
The access point can be placed on a shelf or desktop, ideally you should be able to
see the LED indicators in the front, as you may need to view them for troubleshooting.
Designed to go up to 100 meters indoors and up to 300 meters outdoors, wireless
LAN lets you access your network from anywhere you want. However, the numbers of
walls, ceilings, or other objects that the wireless signals must pass through limit signal
range. Typical ranges vary depending on types of materials and background RF
noise in your home or business.
3.2.2

Connecting the Device

Step 1 Connect the DSL port of the router and the Modem port of the splitter
with a telephone cable; connect the phone to the phone port of the
User Manual
Description
7
