www.proform.com
Model No. PFTL17112.0
USER’'S MANUAL
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to www.proformservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.proformservice.com.
Or call 1-888-533-1333
Mon.––Fri. 6 a.m.––6 p.m. MT
Sat. 8 a.m.––4 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFTL17112.0 and is the answer not in the manual?

Questions and answers

Related Manuals for ProForm PFTL17112.0

Summary of Contents for ProForm PFTL17112.0

  • Page 1 Model No. PFTL17112.0 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decal is not shown at actual size. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    4. The treadmill is intended for home use only. PROFORM dealer, call the telephone number Do not use the treadmill in any commercial, on the front cover of this manual, or see your rental, or institutional setting.
  • Page 4 20. The heart rate monitor is not a medical 24. Inspect and properly tighten all parts of the device. Various factors, including the user’’s treadmill regularly. movement, may affect the accuracy of heart DANGER: rate readings. The heart rate monitor is Always unplug the power intended only as an exercise aid in determin- cord immediately after use, before clean-...
  • Page 6 STANDARD SERVICE PLANS...

  • Page 7: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this PROFORM ® PRO 7000 treadmill. The PRO 7000 manual. To help us assist you, please note the product treadmill offers an impressive selection of features model number and serial number before contacting us.

  • Page 8: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 9: Assembly

    ASSEMBLY •• To hire an authorized service technician •• Left parts are marked ““L”” or ““Left”” and right parts to assemble your exercise equipment, call are marked ““R”” or ““Right.”” 1-800-445-2480. •• To identify small parts, see page 8. •• Assembly requires two persons. ••...
  • Page 10 2. Make sure that the power cord is unplugged. Identify the Right Upright (81). Have a second person hold the Right Upright near the Frame (51). Wire See the inset drawing. Tie the wire tie in the Right Upright (81) securely around the end of the Upright Wire (78).

  • Page 11: Handrail, And Pull It Out Of The Front Of The Right

    4. Hold the right handrail assembly (B) near the Right Upright (81). Insert the Upright Wire (78) into the large hole in the bottom of the right handrail, and pull it out of the front of the right handrail. Set the right handrail assembly (B) onto the Right Upright (81), and attach the right handrail with two 5/16"...
  • Page 12 6. Remove and discard the four screws (E). Next, lift off the Pulse Bar Bottom (77). Console Remove and discard the four 5/16" x 5/8" Assembly Screws (3). 7. Slide the Pulse Bar Bottom (77) onto the right and left handrail assemblies (B, C) as far as pos- sible in the direction shown.
  • Page 13 8. With the help of a second person, hold the con- Console sole assembly near the Right Upright (81) and Assembly the Left Upright (not shown). Insert the Upright Wire (78) through the looped plastic ties on the bottom of the console assembly. Connect the Upright Wire (78) to the console wire.
  • Page 14 10. Tighten four #8 x 3/4" Screws (5) into the bottom of the Pulse Bar Bottom (77). Console Assembly 11. Attach the console assembly with four 5/16" x Console 5/8" Screws (3) and four 5/16" Star Washers Assembly (10). Start all four Screws, and then tighten them.
  • Page 15 12. Attach the Right Handrail Bottom (74) to the bot- tom of the right handrail assembly (B) with two #8 x 3/4" Screws (5). Attach the Left Handrail Bottom (73) to the bot- tom of the left handrail assembly (C) with two #8 x 3/4"...
  • Page 16 14. Firmly tighten the 3/8" x 2 3/4" Bolt (1) and the 3/8" x 4 1/4" Screw (2) on each side of the tread- mill (only one side is shown). 15. Identify the Right Outside Cover (83) and the Right Inside Cover (85). Slide the Right Inside Cover (85) onto the bracket between the Motor Hood (59) and the Right Upright (81).
  • Page 17 16. Slide the iPad Holder Cover (91) up on the iPad Holder (92). Attach the iPad Holder to the con- sole assembly with two 1/4" x 1/2" Screws (6). Slide the iPad Holder Cover (91) down against the console assembly. Console Assembly 17.

  • Page 18: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR •• Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it to The heart rate temperatures above 122° F (50° C) or below 14° F monitor consists of (-10°...

  • Page 19: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’’s...
  • Page 20 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 21. To use the manual mode, see page 21. To use the stereo The treadmill console offers an impressive array of sound system, see page 23. To use an onboard features designed to make your workouts more effec- workout, see page 24.
  • Page 21 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
  • Page 22 4. Change the incline of the treadmill as desired. The My Trail tab will show a track that represents 1/4 mile (400 m). As you exercise, the  ashing To change the incline of the treadmill, press the rectangle will show your progress. The My Trail tab Incline increase or decrease button or one of the will also show the number of laps you complete.
  • Page 23 6. Measure your heart rate if desired. 8. When you are finished exercising, remove the key from the console. Note: If you use the handgrip heart rate moni- tor and the chest heart rate monitor at the same Step onto the foot rails and press the Stop button. time, the console will not display your heart Next, remove the key from the console and put it in rate accurately.
  • Page 24 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the pro le  ashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 25 HOW TO USE A SET-A-GOAL WORKOUT The workout will continue until you reach the goal that you set. The walking belt will then slow to a 1. Insert the key into the console. stop. See HOW TO TURN ON THE POWER on Note: The calorie goal is an estimate of the page 21.
  • Page 26 HOW TO USE AN IFIT WORKOUT 5. Start the workout. Note: To use an iFit workout, you must have access to See step 3 on page 24. a wireless network (see page 28). An iFit account is also required. Go to www.iFit.com to register for an During some workouts, the voice of a personal iFit account.
  • Page 27 HOW TO CHANGE CONSOLE SETTINGS Default Menu——The default menu will appear when you insert the key into the console or when you The console features a settings mode that allows you press the Home button. Press the Enter button to view usage information, to personalize console set- repeatedly to select the manual main screen or the tings, and to set up and manage a wireless network iFit screen as the default menu.
  • Page 28 Clear WiFi Setting——To erase the console’’s Press the up, down, left, and right buttons to high- wireless network settings and have it forget the light the desired letter or number. Then, press the currently selected wireless network, follow the Enter button to select the letter, number, or symbol. instructions in the matrix.
  • Page 29 6. Use WiFi––Advanced to set up a wireless HOW TO USE THE IPAD HOLDER connection. IMPORTANT: The iPad Holder was designed for use This option will allow you to set up a wireless with most full-size iPads. Do not place an iPad mini network connection using your computer, smart or any other electronic device or object in the iPad phone, tablet, or other Wi-Fi device.

  • Page 30: How To Move The Treadmill

    HOW TO MOVE THE TREADMILL Due to the size and weight of the treadmill, moving 2. After the treadmill is placed in the location where it requires two or three persons. it will be used, make sure that the leveling feet rest firmly on the floor.

  • Page 31: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by follow- SYMPTOM: The console displays remain lit when ing the simple steps below. Find the symptom that you remove the key from the console applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual.
  • Page 32 Locate the Reed Switch (45) and the Magnet (44) SYMPTOM: The walking belt slows when walked on on the left side of the Pulley (46). Turn the Pulley until the Magnet is aligned with the Reed Switch. a. Use only a surge suppressor that meets all of the Make sure that the gap between the Magnet and specifications described on page 19.
  • Page 33 SYMPTOM: The walking belt is off-center or slips SYMPTOM: The iFit mode does not function when walked on correctly a. If the walking belt is off-center, first remove the a. If the iFit mode is not functioning correctly, make key and UNPLUG THE POWER CORD. If the sure that the treadmill has the most current firm- walking belt has shifted to the left, use the hex ware available (see step 3 on page 27).

  • Page 34: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 35: Part List

    PART LIST Model No. PFTL17112.0 R1212A Key No. Qty. Description Key No. Qty. Description 3/8" x 2 3/4" Bolt 1/2" Rear Leveling Foot Nut 3/8" x 4 1/4" Screw Rear Leveling Foot Cover 5/16" x 5/8" Screw Warning Decal #8 x 1/2" Screw Rear Frame Cover #8 x 3/4"...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL17112.0 R1212A...
  • Page 37 EXPLODED DRAWING B Model No. PFTL17112.0 R1212A...
  • Page 38 EXPLODED DRAWING C Model No. PFTL17112.0 R1212A...
  • Page 39 EXPLODED DRAWING D Model No. PFTL17112.0 R1212A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
