  • Page 1 74-9810-250 10/03 #787 Log Loader Owner’s Manual...
  • Page 2 Congratulations! ongratulations on your purchase of the American Flyer #787 Log Loader! Perfect for any American Flyer or Lionel layout, the Log Loader hooks a log, hoists it over the track, and drops it into a car waiting below. #787 Log Loader Inventory...

  • Page 3: Powering The #787 Log Loader

    Powering the #787 Log Loader our Log Loader accessory operates best at 12 to 18 volts (AC). Power this accessory using a separate accessory power supply or through track power using a Lockon or a FasTrack Accessory Power Wire. To make the proper connections, the ends of the wires must be stripped back 1/8”...

  • Page 4: Operating The #787 Log Loader

    Operating the #787 Log Loader osition the Log loader accessory next to the track, then follow these steps and refer to Figure 2 to operate the Log Loader using the separate controller. Position the logs on the platform and position a car directly below the boom. Press the button on the controller to activate the loader.

  • Page 5: Installing And Operating Your Accessory With Trainmaster Command Control

    Installing and operating your accessory with TrainMaster Command Control ou may choose to wire this accessory with an SC-2 Switch and Accessory Controller (available separately, 6-22980) or the Accessory Switch Controller (available separately, 6-14182) for operation in the TrainMaster Command Control environment. Refer to these manuals for additional information.

  • Page 6: Installing And Operating Your Accessory With Trainmaster Command Control

    Installing and operating your accessory with TrainMaster Command Control (continued) Accessory Switch Controller wiring and operation hree wires (not included) are needed to connect the accessory to the Accessory Switch Controller (ASC) and a separate accessory transformer. Refer to Figure 4. 1.

  • Page 7: Notes

    Notes...

  • Page 8: Warranty Information

    Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
