Quick Start

To attach the MultiSync FE Series monitor to your system,
follow these instructions:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information, refer to the
display card manual.
3. For the PC: Connect the 15-pin mini D-SUB of the captive signal cable
to the connector of the display card in your system (Figure A.1).
Tighten all screws.
For the Mac: Connect the Macintosh Cable Adapter (not included) to the
monitor connector on the Macintosh (Figure B.1). Attach the 15-pin mini
D-SUB end of the captive signal cable to the Macintosh cable adapter on
the computer (Figure B.1). Tighten all screws.
100
95
75
25
5
0
Computer
15-pin mini
D-SUB
Captive Signal
Cable
Figure A.1
Figure B.1
E - 2
Computer
Mac Adapter
(not included)
Captive Signal
Cable
