User's Manual
NOTE: This unit was designed for
indoor residential use and
DUCTED operation only.
DO NOT USE OVER A WOOD
GRILL OR MOUNT OUTDOOR
ENVIRONMENT.
Please read this operation manual thoroughly before
using your range hood. Store it in a safe location for
when you need to reference it in the future.
RA-3030SS
RA-3036SS
www.windsterhood.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Windster RA-3030SS
Summary of Contents for Windster RA-3030SS
- Page 1 User’s Manual RA-3030SS RA-3036SS NOTE: This unit was designed for indoor residential use and DUCTED operation only. DO NOT USE OVER A WOOD GRILL OR MOUNT OUTDOOR ENVIRONMENT. Please read this operation manual thoroughly before using your range hood. Store it in a safe location for...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents Safety Information .............. 2 – 3 Content Checklist ..............4 Measurements ................5 Preparation ................. 6 – 7 Installation ................. 8 Operation & Features ............... 9 Step by Step Diagram ............. 10 Cleaning & Maintenance ............11 Troubleshooting .............. -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION TO REDUCE THE RISK OF A FIRE, ELECTRICAL SHOCK, AND/OR INJURY OBSERVE THE FOLLOWING: Unit is intended for indoor residential use only. If you should have questions, contact the manufacturer at the address or telephone number listed in the warranty. -
Page 4: Safety Information
SAFETY INFORMATION TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: Regardless of heat level, never leave any surface materials unattended while operating an open flame. Always turn hood ON when cooking at high heat or when flambéing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé). -
Page 5: Content Checklist
CONTENT CHECKLIST CONTENT CHECKLIST CONTENTS INCLUDED (1) RA-30 series (30” or 36”) hood assembly (1) User’s manual (1) Black 6” to 7” conversion collar (2) Magnetic baffle filters (30” model only) (3) Magnetic baffle filters (36” model only) (1) Screw packet CONTENTS NOT INCLUDED RA-30CFMR (CFM reducer) 6”... -
Page 6: Measurements
MEASUREMENTS... -
Page 7: Preparation
PREPARATION PREPARATION BEFORE YOU START Be sure you have all the content of your purchase and required tools for this installation. Installation may take at least 2 to 3 hours from start to finish. Plan to use as few elbows or turns as possible for more efficient air flow. Collar size may need to be increased if utilizing a long duct run. - Page 8 PREPARATION For cabinet with recessed-bottom, use (2) 3” x 12” or 15” wood strips on both sides to balance the recession. Use (4) 1-1/4” long flat head screws to secure the wood strips to cabinet. (Fig. 1d) HOOD Inspect for any sign of defect or damage. (i.e. scratches, dents, loose seams, etc.) Power up the unit to make sure it is working properly.
-
Page 9: Installation
INSTALLATION INSTALLATION 1. UNDER CABINET INSTALLATION Make sure all preparation steps are completed. Feed the wires coming out of the hood through the bottom of the cabinet. Lift the unit up flesh against the wall and the bottom of the cabinet. Using the screws and washers provided, insert into each of the keyhole openings and tightly secure the unit against the bottom of the cabinet. -
Page 10: Operation & Features
OPERATION & FEATURES OPERATION & FEATURES EASY ACCESS CONTROL SWITCH (from left to right) Button 1 – ON / DELAY SHUTOFF / OFF Button 2 – Light control Button 3 – Speed control Blue color speed indicator BAFFLE FILTERS (2) 14-7/8” x 10-5/8” magnetic baffle filters (30” model only) (3) 14-7/8”... -
Page 11: Step By Step Diagram
STEP BY STEP DIAGRAM... -
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING & MAINTENANCE WARNING!!! To prevent the possibility of a fire and explosion, do not use flammable liquids or solvents to clean the unit or any of its parts. Check to make sure all power sources are disconnected before servicing or taking unit apart for cleaning. -
Page 13: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING!!! Check to make sure all power sources are disconnected before starting any troubleshooting. Safety gloves and glasses should be worn when working on the unit. Serious injury or death may occur if safety precautions are not followed. RA-30 Series Halogen light issue 1. -
Page 14: Parts List / Replacement
PARTS LIST / REPLACEMENT PARTS LIST / REPLACEMENT Description Description Hood body assembly Motor housing Halogen / LED light Motor Outer light ring Fan blade Control Switch Grills Motherboard Oil funnel Capacitor Baffle filter 6” – 7” Collar... -
Page 15: Warranty / Contact Us
For a period of one (1) year from the date of purchase, if the product is determined to be defective, Windster will attempt to repair the product, at its option, at no charge. After the warranty period, customer must pay for all labor charges. During the "labor"... - Page 16 WARRANTY / CONTACT US WHAT IS NOT COVERED BY MANUFACTURE WARRANTY Damages resulting from any of the following: Improper installation or maintenance Any repair, modification, alteration or adjustment not authorized by the manufacturer or an authorized service dealer Misuse and/or accidents Incorrect electric current, voltage or power supply Improper setting of any control (Pressing multiple selections at the same time)
