- Page 1 PCAN-MicroMod Analog 2 Application-specific PCAN-MicroMod Motherboard User Manual V1.10.0...
- Page 2 PCAN-MicroMod Analog 2 – User Manual Products taken into account Product Name Model Part number PCAN-MicroMod Analog 2 Including casing and IPEH-002207 PCAN-MicroMod CANopen® and CiA® are registered community trade marks of CAN in Automation e.V. All other product names mentioned in this document may be the trademarks or registered trademarks of their respective companies.
-
Page 3: Table Of Contents
PCAN-MicroMod Analog 2 – User Manual Contents Introduction Properties at a Glance Prerequisites for Operation Scope of Supply Operation Port Assignment Configuration Program 2.2.1 System Requirements 2.2.2 Installing the Program 2.2.3 Creating a Configuration 2.2.4 Applicable MicroMod Services Correction Factor for Analog Inputs... -
Page 4: Introduction
PCAN-MicroMod Analog 2 – User Manual Introduction The motherboards for PCAN-MicroMod provide an application- oriented environment. Typical characteristics of this product group include a wide supply voltage range and the protective circuit for the inputs and outputs. CANopen® firmware is available for all PCAN-MicroMod motherboards. -
Page 5: Prerequisites For Operation
PCAN-MicroMod Analog 2 – User Manual 8 analog inputs: • Measuring range bipolar, -10 to +10 V, resolution 16 bit (other measuring range on request, also unipolar) • Protection against undervoltage and overvoltage • Hardware low-pass with τ = 1 ms •... -
Page 6: Operation
PCAN-MicroMod Analog 2 – User Manual Operation Port Assignment The motherboard has two connectors, J1/2 on the left and J3 on the right. The port assignment is as follows: Figure 1: Ports of the Analog 2 motherboard Port name Function... -
Page 7: Configuration Program
PCAN-MicroMod Analog 2 – User Manual Port name Function AGND Analog ground AGND AIn 7 AIn 6 AIn 5 AIn 4 Analog input -10 - +10 V (16 bit) AIn 3 AIn 2 AIn 1 AIn 0 Configuration Program In order to create and transfer MicroMod configurations, the Win- dows program PCAN-MicroMod Configuration is used. -
Page 8: Installing The Program
PCAN-MicroMod Analog 2 – User Manual 2.2.2 Installing the Program Under Windows install the program from the supplied CD. Start the corresponding installation routine by using the CD navigation going to Tools > PCAN-MicroMod Configuration 2.x.x. Note: In order to create a configuration for the module PCAN- MicroMod Analog 2 you need the program version 2.5.1.54 or... -
Page 9: Applicable Micromod Services
PCAN-MicroMod Analog 2 – User Manual Module No: 0 The module number of the MicroMod on the Analog 2 motherboard is set to 0 at delivery and is relevant if you want to configure more than one MicroMod on the same CAN bus. See also section 2.5 Several MicroMods on the CAN Bus on page 11. -
Page 10: Correction Factor For Analog Inputs
PCAN-MicroMod Analog 2 – User Manual Correction Factor for Analog Inputs The impedance of the voltage source being connected to an analog input affects the measurement with 0.2 % per kΩ. Because the resul- ting error of measurement is linear, it can be compensated in the MicroMod configuration by a matching correction factor (Scale value). -
Page 11: Several Micromods On The Can Bus
PCAN-MicroMod Analog 2 – User Manual Several MicroMods on the CAN Bus If you want to use several MicroMods on the same CAN bus and want to configure them, each one needs its own module number. That way the MicroMods are distinguishable for the program PCAN- MicroMod Configuration. - Page 12 PCAN-MicroMod Analog 2 – User Manual Remounting the MicroMod When you remount the MicroMod, take notice of the white triangu- lar marks on each the motherboard and the MicroMod (upper left corner). These marks must align. Figure 3: Positioning of the MicroMod...
-
Page 13: Technical Specifications
PCAN-MicroMod Analog 2 – User Manual Technical Specifications Power supply Operating voltage +U 11 - 30 V DC (±5 %), 8 - 30 V w/o AOut Current consumption max. 200 mA Ripple (5 V) < 50 mV (Vb = 12 V, 200 mA load) Ripple (analog) <... - Page 14 PCAN-MicroMod Analog 2 – User Manual Transmission standard High-speed CAN ISO 11898-2, typ. 500 kbit/s, setup with PCAN-MicroMod Configuration (Windows software) Termination none CAN ID reserved for 0x7E7 configuration transfer Module number at delivery (for configuration transfer) Peculiarity Interference Immunity...
-
Page 15: Appendix Ace Certificate
PCAN-MicroMod Analog 2 – User Manual Appendix A CE Certificate... -
Page 16: Appendix B Dimension Drawing
PCAN-MicroMod Analog 2 – User Manual Appendix B Dimension Drawing Figure 4: Top view and view of front side with connector. The figure does not show the actual size of the product.
