PCAN-MicroMod Mix 1
Application-specific PCAN-MicroMod
Motherboard

User Manual

Document version 1.11.2 (2017-02-03)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCAN-MicroMod Mix 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Peak PCAN-MicroMod Mix 1

Summary of Contents for Peak PCAN-MicroMod Mix 1

  • Page 1: User Manual

    PCAN-MicroMod Mix 1 Application-specific PCAN-MicroMod Motherboard User Manual Document version 1.11.2 (2017-02-03)

  • Page 2: Document Version 1.11.2 (2017

    PCAN-MicroMod Mix 1 – User Manual Relevant products Product Name Model Part number PCAN-MicroMod Mix 1 Including casing and IPEH-002202 PCAN-MicroMod PCAN-MicroMod Configuration Version 2.5 (Windows software) CANopen® and CiA® are registered community trade marks of CAN in Automation e.V.

  • Page 3: Table Of Contents

    PCAN-MicroMod Mix 1 – User Manual Contents Introduction Properties at a Glance Prerequisites for Operation Scope of Supply Hardware Configuration Modification on Nominal Supply Voltages > 12 V Pull-up/Pull-down Circuits for the Digital Inputs Measuring Range Extension of the Analog...

  • Page 4: Introduction

    PCAN-MicroMod Mix 1 – User Manual Introduction The motherboards for PCAN-MicroMod provide an application- oriented environment. Typical characteristics of this product group include a wide supply voltage range and the protective circuit for the inputs and outputs. CANopen® firmware is available for all PCAN-MicroMod motherboards.
  • Page 5 PCAN-MicroMod Mix 1 – User Manual 6 digital inputs:  Pull-up or pull-down circuit selectable (in 3 groups)  High state at 5 to 18 V input voltage  Schmitt trigger behavior, inverting  Low-pass behavior  Parallel connection of a frequency input (for each digital input 0 to 3) for alternative use (e.g.

  • Page 6: Prerequisites For Operation

    PCAN-MicroMod Mix 1 – User Manual Prerequisites for Operation Power supply in the range of 8 to 26 V DC For creating and transferring configurations: computer with Windows 10, 8.1, 7 (32-bit or 64-bit) and a CAN interface from the PCAN series...

  • Page 7: Hardware Configuration

    PCAN-MicroMod Mix 1 – User Manual Hardware Configuration You can customize the motherboard by modifying the hardware. The following subsections contain descriptions about possible modifications. Accessing the Motherboard In order to carry out the modifications described in the following sections, unscrew the lid of the casing and pull off the MicroMod from the motherboard.

  • Page 8: Modification On Nominal Supply Voltages

    PCAN-MicroMod Mix 1 – User Manual Modification on Nominal Supply Voltages > 12 V If you want to supply the Mix 1 motherboard with a nominal voltage > 12 V (usually 24 V), then you must do the following modification: 1.

  • Page 9: Pull-Up/Pull-Down Circuits For The Digital Inputs

    PCAN-MicroMod Mix 1 – User Manual Figure 3: Position R33 (bottom side of the PCB) Note: You do not need to consider voltage fluctuations that might occur. A modification isn't required in that case. Exam- ple: In the automotive sector up to 18 V may occur at a nominal voltage of 12 V.
  • Page 10 PCAN-MicroMod Mix 1 – User Manual Figure 4: Positions R31, R53/R55, R54/R56 (top side of the PCB) Figure 5: Position R12 (bottom side of the PCB) Attention! Double-check for inadvertent short circuits after altering the setup, especially at positions R53/R55 and R54/R56.

  • Page 11: Measuring Range Extension Of The Analog Inputs

    PCAN-MicroMod Mix 1 – User Manual Measuring Range Extension of the Analog Inputs You can extend the measuring range of each analog input to a higher maximum voltage than 5 Volts by using a voltage divider. On delivery of the motherboard the resistor positions R30 and R43 on the bottom side of the PCB are not equipped.

  • Page 12: Operation

    PCAN-MicroMod Mix 1 – User Manual Operation Port Assignment The motherboard has two connectors, J1/2 on the left and J3 on the right. The port assignment is as follows: Figure 7: Ports of the Mix 1 motherboard Port name Function...

  • Page 13: Configuration Program

    PCAN-MicroMod Mix 1 – User Manual Port name Function Digital ground FOut 2 Frequency output FOut 0 DIn 5 Digital input DIn 4 DIn 3 DIn 2 Digital input, frequency input parallel DIn 1 DIn 0 Configuration Program In order to create and transfer MicroMod configurations the Win- dows software PCAN-MicroMod Configuration is used.

  • Page 14: Installing The Program

    PCAN-MicroMod Mix 1 – User Manual 3.2.2 Installing the Program Under Windows install the program from the supplied CD. Start the corresponding installation routine by using the CD navigation going to Tools > PCAN-MicroMod Configuration 2.5.x. 3.2.3 Creating a Configuration...

  • Page 15: Applicable Micromod Services

    PCAN-MicroMod Mix 1 – User Manual Bitrate MicroMod: 500 kbit/s At delivery the MicroMod is set to a bit rate of 500 kbit/s. A change of this setting will take effect after sending the completed configura- tion to the MicroMod.

  • Page 16: Status Leds

    PCAN-MicroMod Mix 1 – User Manual Status LEDs The motherboard including the MicroMod has three LEDs with the following status indications: Indication Power (green) Power is applied. DOut 7 (red) Is linked to the digital output DO 7 of the MicroMod and can be configured freely.
  • Page 17 PCAN-MicroMod Mix 1 – User Manual Attention! Electrostatic discharge (ESD) can damage or destroy components on the motherboard or the PCAN-MicroMod. Take precautions to avoid ESD when handling the boards. Remounting the MicroMod When you remount the MicroMod, take notice of the white triangu- lar marks on each the motherboard and the MicroMod (upper left corner).

  • Page 18: Technical Specifications

    PCAN-MicroMod Mix 1 – User Manual Technical Specifications Power supply Operating voltage +U 8 - 26 V DC (±5 %) Current consumption max. 200 mA, typ. 35 mA at 12 V w/o load Ripple 5 V < 50 mV (U...
  • Page 19 PCAN-MicroMod Mix 1 – User Manual Analog inputs Count Measuring range 0 to 5 V, extendable Resolution 10 bits Sampling rate 1 kHz Source impedance < 5 k Overvoltage protection extant Low-pass = 66 Hz Temperature inputs Count Reference sensor type Thermistor EC95F103W (e.g.
  • Page 20 PCAN-MicroMod Mix 1 – User Manual Environment Operating temperature -40 - +85 °C (-40 - +185 °F) Temperature for storage -40 - +100 °C (-40 - +212 °F) and transport Relative humidity 15 - 90 %, not condensing Ingress protection...

  • Page 21: Appendix Ace Certificate

    PCAN-MicroMod Mix 1 – User Manual Appendix A CE Certificate...

  • Page 22: Appendix B Dimension Drawing

    PCAN-MicroMod Mix 1 – User Manual Appendix B Dimension Drawing Figure 10: Top view and view of front side with connector. The figure does not show the actual size of the product.
