Ref. No. Part No.
CPCi-A005WJ75
PC I/F UNIT (AVC System) (Continued)
R10743 9DK001-50349 J 1.8k 1/16W Metal Oxide
R10745 9DK001-50330 J 0
R10747 9DK001-50330 J 0
R10749 9DK001-50330 J 0
R10867 9DK001-50330 J 0
R10868 9DK001-50330 J 0
R10869 9DK001-50330 J 0
R10877 9DK001-50350 J 10k 1/16W Metal Oxide
R10911 9DK001-50338 J 10
R10912 9DK001-50338 J 10
R10920 9DK001-50344 J 100 1/16W Metal Oxide
R10921 9DK001-50330 J 0
R10922 9DK001-50350 J 10k 1/16W Metal Oxide
R10924 9DK001-50353 J 4.7k 1/16W Metal Oxide
R10925 9DK001-50353 J 4.7k 1/16W Metal Oxide
R10927 9DK001-50344 J 100 1/16W Metal Oxide
R10928 9DK001-50344 J 100 1/16W Metal Oxide
R10929 9DK001-50344 J 100 1/16W Metal Oxide
R10930 9DK001-50344 J 100 1/16W Metal Oxide
R10934 9DK001-51056 J 68
R10936 9DK001-51056 J 68
R10937 9DK001-51056 J 68
R10939 9DK001-51056 J 68
R10940 9DK001-51056 J 68
R10941 9DK001-51056 J 68
R10947 9DK001-51055 J 56
R10950 9DK001-51057 J 6.8k 1/16W Resistor Array AB
R10951 9DK001-51057 J 6.8k 1/16W Resistor Array AB
R10955 9DK001-51057 J 6.8k 1/16W Resistor Array AB
R10959 9DK001-51056 J 68
R10960 9DK001-51056 J 68
R10961 9DK001-51056 J 68
R10962 9DK001-51056 J 68
R10963 9DK001-51056 J 68
R10964 9DK001-51056 J 68
R10965 9DK001-51056 J 68
R10966 9DK001-51056 J 68
R10967 9DK001-51056 J 68
R10968 9DK001-51056 J 68
R10969 9DK001-51056 J 68
R10970 9DK001-51056 J 68
R10971 9DK001-51051 J 33
R10972 9DK001-51051 J 33
R10973 9DK001-51051 J 33
R10974 9DK001-51051 J 33
R10975 9DK001-51051 J 33
R10976 9DK001-51051 J 33
R10977 9DK001-50350 J 10k 1/16W Metal Oxide
R10978 9DK001-50330 J 0
R10979 9DK001-50330 J 0
R10980 9DK001-50330 J 0
R10999 9DK001-50392 J 510 1/16W Metal Oxide
R11002 9DK001-50344 J 100 1/16W Metal Oxide
R11003 9DK001-50344 J 100 1/16W Metal Oxide
R11006 9DK001-50396 J 2.2k 1/16W Metal Oxide
R11007 9DK001-50351 J 1k
R11008 9DK001-50351 J 1k
R11009 9DK001-50396 J 2.2k 1/16W Metal Oxide
R11011 9DK001-50397 J 33k 1/16W Metal Oxide
R11012 9DK001-50351 J 1k
R11042 9DK001-50394 J 820 1/16W Metal Oxide
R11043 9DK001-50394 J 820 1/16W Metal Oxide
R11044 9DK001-50394 J 820 1/16W Metal Oxide
R11058 9DK001-50353 J 4.7k 1/16W Metal Oxide
R11059 9DK001-50353 J 4.7k 1/16W Metal Oxide
R11060 9DK001-50353 J 4.7k 1/16W Metal Oxide
R11061 9DK001-50353 J 4.7k 1/16W Metal Oxide
R11062 9DK001-50353 J 4.7k 1/16W Metal Oxide
R11076 9DK001-51050 J 10k 1/16W Resistor Array AB
R11077 9DK001-50383 J 150 1/16W Metal Oxide
R11079 9DK001-51055 J 56
Description Code
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/10W Metal Oxide AA
1/10W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
1/16W Resistor Array AB
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Resistor Array AB
239
Ref. No. Part No.
R11080 9DK001-50330 J 0
R11081 9DK001-50330 J 0
R11082 9DK001-50389 J 22
R11083 9DK001-50351 J 1k
R11084 9DK001-50350 J 10k 1/16W Metal Oxide
R11085 9DK001-50350 J 10k 1/16W Metal Oxide
R11089 9DK001-50344 J 100 1/16W Metal Oxide
R11099 9DK001-50330 J 0
R11101 9DK001-51055 J 56
R11102 9DK001-51055 J 56
R11104 9DK001-50344 J 100 1/16W Metal Oxide
R11106 9DK001-50350 J 10k 1/16W Metal Oxide
R11110 9DK001-50353 J 4.7k 1/16W Metal Oxide
R11126 9DK001-50387 J 10
R11127 9DK001-50350 J 10k 1/16W Metal Oxide
R11128 9DK001-50342 J 47
R11129 9DK001-50350 J 10k 1/16W Metal Oxide
R11130 9DK001-50350 J 10k 1/16W Metal Oxide
R11131 9DK001-50350 J 10k 1/16W Metal Oxide
R11132 9DK001-50344 J 100 1/16W Metal Oxide
R11134 9DK001-50330 J 0
R11135 9DK001-50350 J 10k 1/16W Metal Oxide
R11201 9DK001-50344 J 100 1/16W Metal Oxide
R11202 9DK001-50341 J 33
R11203 9DK001-50350 J 10k 1/16W Metal Oxide
R11204 9DK001-50333 J 1k
R11205 9DK001-50350 J 10k 1/16W Metal Oxide
SWITCH
S10001 9DK001-70012 J Slide Switch
MISCELLANEOUS PARTS
FB10016 9DK001-81081 J Ferrite Bead
FB10018 9DK001-50382 J 0
FB10019 9DK001-50382 J 0
FB10050 9DK001-81060 J Ferrite Bead
FB10051 9DK001-81060 J Ferrite Bead
FB10052 9DK001-81060 J Ferrite Bead
FB10053 9DK001-81060 J Ferrite Bead
FB10054 9DK001-81081 J Ferrite Bead
CN10001 9DK001-60074 J Connector, 15-pin
CN10003 9DK001-60121 J Connector, 50-pin
CN10005 9DK001-60066 J Connector, 9-pin
CN10006 9DK001-60067 J Connector, 30-pin
CN10007 9DK001-60058 J Connector, 50-pin
CN10008 9DK001-60070 J Connector, 12-pin
CN10009 9DK001-60071 J Connector, 13-pin
FR10001 LANGTA083WJFW J Angle
PLT10001 9DK001-89009 J GND Plug
PLT10002 9DK001-89009 J GND Plug
PLT10003 9DK001-89009 J GND Plug
PLT10004 9DK001-89009 J GND Plug
PLT10005 9DK001-89009 J GND Plug
PLT10006 9DK001-89009 J GND Plug
PLT10008 9DK001-89009 J GND Plug
PLT10009 9DK001-89009 J GND Plug
PLT10010 9DK001-89009 J GND Plug
PLT10011 9DK001-89009 J GND Plug
PLT10012 9DK001-89009 J GND Plug
PLT10013 9DK001-89009 J GND Plug
TP10004 9DK001-84015 J Lug
XJPSN30P08XS0 J Screw, x6
LC-37HV6U
Description Code
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Resistor Array AB
1/16W Resistor Array AB
AA
AA
AA
1/4W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AL
AC
1/10W Metal Oxide AA
1/10W Metal Oxide AA
AF
AF
AF
AF
AC
AL
AQ
AT
AK
AS
AH
AH
AW
AF
AF
AF
AF
AF
AF
AF
AF
AF
AF
AF
AF
AA
AA
