Sharp LC-37HV6U Service Manual page 220

LC-37HV6U
Ref. No. Part No.
DUNTKC009FE04
MAIN UNIT (AVC System) (Continued)
Q409 VS2SC3928AR-1Y
Q410 VS2SC3928AR-1Y
Q416 VS2SA1530AR-1Y
Q417 VS2SA1530AR-1Y
Q418 VS2SA1530AR-1Y
Q801 VS2SA1530AR-1Y
Q802 VS2SA1530AR-1Y
Q803 VS2SA1530AR-1Y
Q804 VS2SA1530AR-1Y
Q809 VS2SC3928AR-1Y
Q814 VS2SA1530AR-1Y
Q815 VS2SA1530AR-1Y
Q816 VS2SA1530AR-1Y
Q818 VS2SA1530AR-1Y
Q819 VS2SA1530AR-1Y
Q820 VS2SA1530AR-1Y
Q821 VS2SC2735//1EY
Q822 VS2SC2735//1EY
Q823 VS2SC2735//1EY
Q824 VS2SA1530AR-1Y
Q825 VS2SA1530AR-1Y
Q826 VS2SA1530AR-1Y
Q827 VS2SA1530AR-1Y
Q828 VS2SA1530AR-1Y
Q830 VS2SC3928AR-1Y
Q837 VS2SC3928AR-1Y
Q838 VS2SA1530AR-1Y
Q839 VS2SC2735//1EY
Q840 VS2SC2735//1EY
Q841 VS2SC2735//1EY
Q842 VS2SC3928AR-1Y
Q843 VS2SC3928AR-1Y
Q844 VS2SC3928AR-1Y
Q901 VS2SA1530AR-1Y
Q902 VS2SA1530AR-1Y
Q903 VS2SA1530AR-1Y
Q904 VS2SA1530AR-1Y
Q905 VS2SA1530AR-1Y
Q906 VS2SA1530AR-1Y
Q1502 VSDTC144EE/-1Y
Q1503 VS2SB1132Q/-1Y
Q1504 VS2SC3928AR-1Y
Q1507 VSDTC144EE/-1Y
Q1508 VSiMD2A////-1Y
Q1509 VSiMD2A////-1Y
Q1512 VSiMD2A////-1Y
Q1801 VS2SB1132Q/-1Y
Q1802 VSDTC124EKA-1Y
Q7001 VS2SA1530AR-1Y
Q7002 VS2SC3928AR-1Y
Q7003 VS2SA1530AR-1Y
Q7004 VS2SC3928AR-1Y
Q7005 VS2SA1530AR-1Y
Q7006 VS2SA1530AR-1Y
Q7007 VS2SA1530AR-1Y
Q7008 VS2SA1530AR-1Y
Q7013 VS2SK536///-1Y
Q7014 VS2SK536///-1Y
Q7051 VS2SC3928AR-1Y
Q7201 VS2SC3928AR-1Y
Q7206 VS2SC3928AR-1Y
Q7207 VSDTC144EE/-1Y
DIODES
D801 VHDDAN222//-1Y
D1502 VHDDAN222//-1Y
D1503 VHDDAN222//-1Y
D1505 VHD1SS355//-1Y
D7001 VHD1SS355//-1Y
D7201 VHD1SS355//-1Y
D7202 VHD1SS355//-1Y
Description Code
J 2SC3928AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SC2735 AC
J 2SC2735 AC
J 2SC2735 AC
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC2735 AC
J 2SC2735 AC
J 2SC2735 AC
J 2SC3928AR AB
J 2SC3928AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J DTC144EE AA
J 2SB1132Q AC
J 2SC3928AR AB
J DTC144EE AA
J IMD2A AC
J IMD2A AC
J IMD2A AC
J 2SB1132Q AC
J DTC124EKA AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SA1530AR AB
J 2SK536 AE
J 2SK536 AE
J 2SC3928AR AB
J 2SC3928AR AB
J 2SC3928AR AB
J DTC144EE AA
J Diode AA
J Diode AA
J Diode AA
J Diode AB
J Diode AB
J Diode AB
J Diode AB
Ref. No. Part No.
PACKAGED CIRCUITS
X601 RFiLA0034CEZZ
X801 RCRSB0244CEZZ+ J Crystal
X802 RCRSB0244CEZZ+ J Crystal
X1901 RCRSZ0093CEZZY J Crystal
X7001 RCRSC0026CEZZY J Crystal
FILTERS AND COILS
CF7201 RFiLA0098CEZZ+
FL7002 RFiLN0097GEZZY
FL7004 RCiLF0306CEZZY
FL7005 RCiLV0108GEZZY
L406 VPD9M4R7MR53NY J Peaking 4.7µH
L407 VPD9M220J2R7NY J Peaking 22µH
L408 VPD9M270J3R2NY J Peaking 27µH
L410 VPD9M4R7MR53NY J Peaking 4.7µH
L805 VPD9M2R2MR32NY J Peaking 2.2µH
L808 VPD9M220J2R7NY J Peaking 22µH
L809 VPD9M220J2R7NY J Peaking 22µH
L810 VPD9M220J2R7NY J Peaking 22µH
L7001 VPD9M5R6J1R6NY J Peaking 5.6µH
L7002 VPD9M220J2R7NY J Peaking 22µH
L7003 VPD9M820J9R5NY J Peaking 82µH
CAPACITORS
C415 VCKYCY1EF104ZY J 0.1
C416 VCEASX1CN476MY J 47
C425 VCCCCY1HH120JY J 12p
C426 VCCCCY1HH100DY J 10p
C427 VCCCCY1HH120JY J 12p
C428 VCKYCY1EF104ZY J 0.1
C429 VCKYCY1HB103KY J 0.01
C430 VCKYCY1HB103KY J 0.01
C431 VCKYCY1HB103KY J 0.01
C432 VCKYCY1EF104ZY J 0.1
C433 VCKYCY1HB103KY J 0.01
C434 VCKYTV1CB474KY J 0.47
C435 VCKYCY1EF104ZY J 0.1
C436 VCKYCY1EF104ZY J 0.1
C437 VCKYCY1HB103KY J 0.01
C438 VCEASW1CN107MY J 100
C439 VCKYCY1EF104ZY J 0.1
C440 VCKYCY1HB103KY J 0.01
C441 VCKYCY1EF104ZY J 0.1
C442 VCKYCY1HB681KY J 680p
C443 VCKYCY1EF104ZY J 0.1
C444 VCKYCY1HB103KY J 0.01
C445 VCKYCY1HB103KY J 0.01
C447 VCCCCY1HH101JY J 100p
C453 VCKYTV1CB105KY J 1
C454 VCKYTV1EB104KY J 0.1
C455 VCEASX1CN107MY J 100
C456 VCKYCY1EF104ZY J 0.1
C457 VCCCCY1HH270JY J 27p
C458 VCCCCY1HH560JY J 56p
C459 VCKYCY1CB104KY J 0.1
C460 VCEASX1CN476MY J 47
C614 VCKYTV1CB105KY J 1
C615 VCKYCY1HB103KY J 0.01
C616 VCKYTV1CB105KY J 1
C617 VCKYCY1EF104ZY J 0.1
C618 VCEASW1CN337MY J 330
C623 VCEASX1CN476MY J 47
C646 VCKYTV1CB105KY J 1
C802 VCKYCY1EF104ZY J 0.1
C803 VCKYCY1HB103KY J 0.01
C804 VCEASW1CN107MY J 100
C805 VCKYCY1HB103KY J 0.01
C806 VCCCCY1HH470JY J 47p
C807 VCKYTV1EB104KY J 0.1
C808 VCKYTV1EB104KY J 0.1
C809 VCKYTV1EB104KY J 0.1
C810 RC-KZ0117TAZZY
C811 VCKYTV1EB104KY J 0.1
C812 VCKYTV1EB104KY J 0.1
220
Description Code
J Filter AD
AF
AF
AM
AG
J Ceramic Filter AD
J Filter AF
J Coil AH
J Coil AG
AB
AC
AB
AB
AB
AC
AC
AC
AB
AC
AC
25V Ceramic AA
16V Electrolytic AC
50V Ceramic AA
50V Ceramic AA
50V Ceramic AA
25V Ceramic AA
50V Ceramic AA
50V Ceramic AA
50V Ceramic AA
25V Ceramic AA
50V Ceramic AA
16V Ceramic AC
25V Ceramic AA
25V Ceramic AA
50V Ceramic AA
16V Electrolytic AC
25V Ceramic AA
50V Ceramic AA
25V Ceramic AA
50V Ceramic AA
25V Ceramic AA
50V Ceramic AA
50V Ceramic AA
50V Ceramic AA
16V Ceramic AC
25V Ceramic AB
16V Electrolytic AC
25V Ceramic AA
50V Ceramic AA
50V Ceramic AB
16V Ceramic AB
16V Electrolytic AC
16V Ceramic AC
50V Ceramic AA
16V Ceramic AC
25V Ceramic AA
16V Electrolytic AD
16V Electrolytic AC
16V Ceramic AC
25V Ceramic AA
50V Ceramic AA
16V Electrolytic AC
50V Ceramic AA
50V Ceramic AA
25V Ceramic AB
25V Ceramic AB
25V Ceramic AB
J 4.7 50V Ceramic AD
25V Ceramic AB
25V Ceramic AB
