12.3 Playback

Purpose:
The record files stored on the storage devices such as the HDDs, Net HDDs and SD/SDHC cards on the
local device or the storage server can be searched and played back remotely through the web
browser.
Click the Playback tab to open the Playback page.
Playback Toolbar:
On the Playback page, the following toolbar buttons are available:
Set Layout
Stop Playback
Capture
Start/Stop Clipping
Download
Audio on/Mute
Full Screen
Searching Record Files
Steps:
1. Open the Playback page.
2. Select the camera(s) to be searched from the list.
3. Click to select a day for the search.
4. Optionally, click
start time and end time, and select the query type.
5. Click Search. The record files of the selected cameras will be displayed on the Search Result list.
You can filter the results through the Search text field.
Note: Up to 16 cameras can be searched simultaneously.
User Manual of iVMS-5200 Control Client
Set the screen layout mode. 4 types of screen layout modes are
selectable: 1-Screen, 4-Screen, 9-Screen and 16-Screen.
Stop the playback of all cameras.
Capture the picture in the playback process.
Start/Stop clipping the record files.
Open the download window. Select the record file(s) and click
Download to save the file(s) to the local PC.
Turn on/off the audio in playback.
Display the playback in full-screen mode. Press ESC to exit.
to activate the More Search Options panel. Click the icon to specify the
64
