11.2 Logical View

Steps:
1. Open the Status Detection page.
2. Click the Logical View tab. You can check the online status of the cameras, the signal status of
the cameras, the recording schedule of the cameras and the recording status of the cameras that
are configured with recording schedule.
3. Optionally, you can click Refresh to get the latest status.
4. On the area tree panel, click to select an area, and the information of cameras belonging to the
area displays. You can also click
Address/Domain Name: The IP address or domain name of the device that the camera belongs
to.
Device Serial No.: The serial No. of the device that the camera belongs to.
Connection: Connection number refers to the number of the streams gotten from the device for
live view, playback or record via network. If the connection number is 4, it means 4 streams are
gotten from the device for remote live view, playback or record. If Stream Media Server displays
in the field, it means the streams gotten from the device via the stream media server.
5. Optionally, you can check the checkbox of Exception Only to display the cameras in exceptional
status only. You can also enter the key words in the Filter field to search the camera.
User Manual of iVMS-5200 Control Client
to get the latest status of the device.
