1 View List: Show the customized view and you can also create new view.
2 Camera List: Show the added devices.
3 PTZ Control Panel: Show the panel for PTZ control.
4 Display Window of Live View: The window for playing the live video of the camera(s).
5 Live View Toolbar: The buttons shown are used for controlling the live view.
Camera Status:
The camera is online and works properly.
The camera is in live view.
The camera is in recording status.
The camera is offline.
Live View Toolbar:
On the Main View page, the following buttons are available:
Save View
Save View As
Stop Live View
Mute/Audio On
Resume/Pause
Auto-switch
Show /Hide the Menu
Previous
Next
Screen Layout
Full Screen
Right-click on the display window in live view to open the Live View Management Menu:
The following items are available on the right-click Live View Management Menu:
Stop Live View
Capture
User Manual of iVMS-5200 Control Client
Save the new settings for the current view.
Save the current view as another new view.
Stop the live view of all cameras.
Turn off/on the audio in live view.
Click to resume/pause the auto-switch in live view.
Show/Hide the configuration menu of auto-switch. Click again to
hide.
Go for live view of the previous page.
Go for live view of the next page.
Set the screen layout.
Display the live view in full-screen mode. Press ESC key to exit.
Stop the live view in the display window.
Capture the picture in the live view process.
