HIKVISION iVMS-2000 Installation Manual

Hybrid pc-dvr software
Hide thumbs Also See for iVMS-2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
iVMS-2000
Hybrid PC-DVR Software

Installation Guide

V2.0.1
Hangzhou Hikvision Digital Technology Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION iVMS-2000

Summary of Contents for HIKVISION iVMS-2000

  • Page 1: Installation Guide

    Hybrid PC-DVR Software Installation Guide V2.0.1 Hangzhou Hikvision Digital Technology Co., Ltd.
  • Page 2 Thank you for purchasing our product. If there is any question or request, please feel free to contact us. This Manual is for iVMS-2000 Hybrid PC-DVR Software. This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice. The updates will be added into the new version of this manual, and we will readily improve or update the product or procedure described in the manual.

  • Page 3: Table Of Contents

    Hardware Installation ....................19 GSM Modem Description ................19 3.1.1 3.1.2 GSM Modem Connection Guide..............21 Driver Installation ....................... 24 Alarm Box Installation ......................27 Install and Uninstall ........................ 30 Installation ........................30 Uninstall ........................37 © 2006-2010 by HIKVISION. All rights reserved.

  • Page 4: Compression Card Installation

    Installation Guide 1 Compression Card Installation 1.1 Hardware Installation Take HIKVISION DS-42xxHCI/HFVI series audio/video compression card as example. For the other HIKVISION compression card models, the hardware installation steps are similar as DS-42xxHCI/HFVI series. 1.1.1 Product Description  DS-4216HFVI (Figure 1-1)
  • Page 5 Installation Guide Figure 1-2 DS-4208HFVI  DS-4216HCI (Figure 1-3) Support 16 channel CIF/QCIF real time encoding Support up to 16ch CIF (main stream) +16ch CIF(sub stream) encoding on dual stream mode Figure 1-3 DS-4216HCI © 2006-2010 by HIKVISION. All rights reserved.

  • Page 6: Technical Specification

    Audio Compression OggVorbis Audio Input 16ch, mono 8ch, mono 16ch, mono BNC (2Vp-p, 1kΩ, volume adjust range: 83DB) Audio Input Interface Sampling Rate 8KHz Audio Recording Bit Rate 64kbps Power Consumption <8.5w <7w <14w © 2006-2010 by HIKVISION. All rights reserved.

  • Page 7: Compression Card Installation

    The audio cable connects between DS-40xxHCI/HIS and PC motherboard (Figure 1-5). Card Installation: Shut down the PC and make sure the power-supply is disconnected (Figure 1-6). Figure 1-6 Unplug PC Power Supply Loosen the screws (Figure 1-7). © 2006-2010 by HIKVISION. All rights reserved.
  • Page 8 Installation Guide Figure 1-7 Loosen the screws Open the PC chassis (Figure 1-8). Figure 1-8 Open PC Chassis Put Down the PC chassis (Figure 1-9). © 2006-2010 by HIKVISION. All rights reserved.
  • Page 9 Figure 1-10 PCI slots on the PC motherboard Figure 1-11 Covering Pieces on the PC back panel Figure 1-11 Plug the card into the PCI slot Fix the compression card with a screw (Figure 1-12). © 2006-2010 by HIKVISION. All rights reserved.
  • Page 10 Connect the last audio output of HCI/HSI card with the CD_IN interface of PC motherboard or PC sound card. Figure 1-13 Live Audio Cable Connection (For DS-40xx Series Card) Connect external video/audio cables, the red cables are for video connection and white cables are for audio connection. © 2006-2010 by HIKVISION. All rights reserved.

  • Page 11: Cable Connection

    DB2; AID1, AID2 stand for “audio 1~audio 2” when connected to DB1, or “audio 3~audio 4” when connected to DB2. 12ch audio connection cable and installation adapter (1 unit for each card) © 2006-2010 by HIKVISION. All rights reserved.
  • Page 12 DB1 video 1~video 8; audio 1, audio 2 DB2 video 9~video 16; audio 3, audio 4 audio 5~audio 16  DS-4208HFVI Accessory and Connection 4ch video /4ch audio connection cable (2 units for each card) © 2006-2010 by HIKVISION. All rights reserved.
  • Page 13 AID1~AID4 stand for “audio 1~audio 4” when connected to DB1, and “audio 5~audio 8” when connected to DB2. DS-4208HFVI Connection DB4 DB3 Figure 1-19 DS-4208HFVI Connection video 1~video 4; audio 1~audio 4 video 5~video 8; audio 5~audio 8 © 2006-2010 by HIKVISION. All rights reserved.
  • Page 14 AID1, AID2 stand for “audio 1~audio 2” or “audio 3~audio 4” 12ch audio connection cable and installation adapter (1 unit for each card) Figure 1-21 12ch audio connection cable and installation adapter Description: AID5~AID16 stand for “audio 5~audio 16” DS-4216HCI Connection © 2006-2010 by HIKVISION. All rights reserved.
  • Page 15 Installation Guide DB4 DB3 Figure 1-22 DS-4216HCI Connection DB1 video 1~video 8; audio 1, audio 2 DB2 video 9~video 16; audio 3, audio 4 audio 5~audio 16 © 2006-2010 by HIKVISION. All rights reserved.

  • Page 16: Driver Installation

    PC or more than one DSP in one card, the operation system will remind you of repeating the above process. Figure 1-24 Hardware Installation Warning Message When the installation is done, the “Driver Installed Successfully!” message will be displayed on the screen. © 2006-2010 by HIKVISION. All rights reserved.
  • Page 17 After “Driver install success” message popup during driver installation, there will be “Hikvision DS42xx Series” displayed in the list “Sound, Video and Game Controller” of Windows Device Manager as below. The total number of this item is equal to the total DSP number on the cards installed inside the PC.

  • Page 18: Ip Camera Installation

    Figure 2-2 Connect IP Camera to a Wireless Access Point 2.1.2 Network Connection via Cables  Connect IPC to the LAN via Ethernet Interface IP camera can be connected to the LAN via a network switch or Hub (Figure 2-3). © 2006-2010 by HIKVISION. All rights reserved.

  • Page 19: Modify Ip Camera Configuration

    2.2 Modify IP Camera Configuration The default IP for HIKVISION IP camera is 192.0.0.64, with 8000 as port number and admin / 12345 as default user name / password. The administrator can create up to 15 operators with separate privilege settings.
  • Page 20 If the IP address is not in the required IP section, users can modify the network parameters in the SADP software. Click the device on the list and input administrator’s password (12345 by default) a nd click [Modify]. © 2006-2010 by HIKVISION. All rights reserved.

  • Page 21: Gsm Modem Installation

    The sample GSM modem is displayed as below (Figure 3-1). Figure 3-1 GSM Modem And the power supply cable is displayed as below (Some GSM modems also support USB power supply) (Figure 3-2). © 2006-2010 by HIKVISION. All rights reserved.
  • Page 22 Installation Guide Figure 3-2 Power Cable Serial cable for PC connection (some GSM modems support USB connection) (Figure 3-3). Figure 3-3 Serial Cable External antenna for sending signal (Figure 3-4). © 2006-2010 by HIKVISION. All rights reserved.

  • Page 23: Gsm Modem Connection Guide

    Installation Guide Figure 3-4 External Antenna Connection Guide 3.1.2 GSM Modem 1. Insert SIM card into the GSM modem. (Figure 3-5, Figure 3-6. Figure 3-7). Press Here Figure 3-5 Press the SIM card button © 2006-2010 by HIKVISION. All rights reserved.
  • Page 24 Figure 3-6 Insert the SIM card Figure 3-7 Push the SIM card platfrom back to the device Notes: it is suggested to keep the antenna’s in vertical up 2. Install the antenna (Figure 3-8). direction. © 2006-2010 by HIKVISION. All rights reserved.
  • Page 25 PC (Figure 3-9, Figure 3-10). Note: Please make sure the connectors are fixed to the devices. Figure 3-9 Connect the round pin to the GSM Modem Figure 3-10 Connect 9 pin DB connector to the PC © 2006-2010 by HIKVISION. All rights reserved.

  • Page 26: Driver Installation

    Inset the CD attached with GSM Modem into the PC, and click [Automatic] in Figure 3-11, and the system will automatically detect and install the driver as Figure3-12. Figure 3-12 Install Shield Wizard Click [Next] to install driver (Figure 3-13). © 2006-2010 by HIKVISION. All rights reserved.
  • Page 27 Installation Guide Figure 3-13 GSM Modem Installation Click [Finish] after driver installation finished (Figure 3-13). Figure 3-14 Driver Install Complete After driver installation, we can see the GSM modem in the Windows Device © 2006-2010 by HIKVISION. All rights reserved.
  • Page 28 Manager with an assigned port number (Figure 3-15). Note: The GSM modem’s port number in iVMS-2000 should be set as same as the GSM Modem. Figure 3-15 GSM Modem port number displayed in Windows Device Manager Note: Right click “My Computer” and select “Properties” and select “Hardware Management” to enter Device Manager.

  • Page 29: Alarm Box Installation

    Installation Guide 4 Alarm Box Installation Alarm box converts between alarm data and electronic level signals and trigger alarm devices. This Document gives example of alarm box installation and connection with iVMS-2000 software. RS232 Alarm In Power Alarm Out...
  • Page 30 Installation Guide Figure 4-2 Back Panel Connect the alarm box into the PC via RS232 interface. (Figure 4-3, Figure 4-4) Figure 4-3 Serial Port on PC’s Back Panel © 2006-2010 by HIKVISION. All rights reserved.
  • Page 31 Installation Guide Figure 4-4 Connect alarm box to the PC © 2006-2010 by HIKVISION. All rights reserved.

  • Page 32: Install And Uninstall

    5.1 Installation Please refer to the following steps during iVMS-2000 installation. Step1: Insert the iVMS-2000 installation CD into the PC CD-ROM, and run on the CD. The install shield dialog box will be displayed (Figure 2-1), and dialog box as Figure 2-2 will be displayed a few seconds later (the time interval depends on the PC configuration).
  • Page 33 Step3: Click “Change(C)…” to modify software installed location (Figure 2-3), and click “Next” to continue (Figure 2-4), or click “Back” to return to Welcome Interface, or click “Cancel” to exit the Installation. Figure 2-3 Select Installation Path © 2006-2010 by HIKVISION. All rights reserved.
  • Page 34 Installation Guide Step4: Click “Install (I)” in the dialog box as Figure 2-4 to start iVMS-2000 installation (Figure 2-5), or click “Back (B)” to return to Select Installation Path (Figure 2-3). Click “Cancel” to exit the Installation. Figure 2-4 Ready to Install...
  • Page 35 Step6: In Figure 2-8, click “Next” to enter the license agreement interface (Figure 2-9). Click “Back” to return to Figure 2-6, or click “Cancel” to skip WinPcap Installation and go to Installation Complete Interface directly (Figure 2-12). © 2006-2010 by HIKVISION. All rights reserved.
  • Page 36 Step7: In Figure 2-9, click “I Agree” and start WinPcap installation if you accept the license agreement, or click “Back” to return to Figure 2-8. Click “Cancel” to skip WinPcap installation and go to Installation Complete Interface directly (Figure 2-12). Figure 2-9 WinPcap license agreement © 2006-2010 by HIKVISION. All rights reserved.
  • Page 37 Installation Guide Figure 2-10 Installing WinPcap Step8: After WinPcap is installed, an Installation Complete Interface (Figure2-11) will pop up. Click “Finish” to complete the installation. Figure 2-11 WinPcap Installation Complete © 2006-2010 by HIKVISION. All rights reserved.
  • Page 38 Installation Guide Step9: After WinPcap installation finished, iVMS-2000 Installation Complete Interface will pop up (Figure 2-12), click “Finish” to complete the iVMS-2000 installation process. Figure 2-12 iVMS-2000 Installation Complete Interface Note:For Windows Operating System below Vista, users need to install Windows updates before using CD/DVD backup function (Install the file in CD: WindowsXP-KB932716-v2-x86-ENU.exe).

  • Page 39: Uninstall

    Installation Guide 5.2 Uninstall Please refer to the following steps before removing iVMS-2000 systems from personal computers. Step1: Select “All programs” -> “WinPcap” -> “Uninstall WinPcap” in the start menu of the Windows operating system, and click “Uninstall” in the prompt dialog box (Figure 2-13) to uninstall the WinPcap.
  • Page 40 ” iVMS -2000” ”Uninstall iVMS -2000” in the start menu of Windows OS, and click “Uninstall” in the prompt dialog box (Figure 2-15) to start to uninstall the iVMS-2000. Figure 2-15 iVMS-2000 Un-install Prompt Step4: As shown in Figure 2-16, WinPcap un-installation process will takes some tens of seconds.
